Manual

6 7

GENERAL APPLIANCE DESCRIPTION – GAS ELEVATED

(R.H VARIANT SHOWN)

Grill Door

Removable Grill Dish

Grill Burner Reflector

Removable Hotplate Burner

Removable Trivet

Grill Vent

Grill Burner

Oven Vent

Fan Cover

Anti-tilt Plate

Oven Fan

Oven Burner Cover

Removable Shelf

Removable Inner Glass

Oven Door

5 6

8 9

PRODUCT DESCRIPTION INSTALLING THE ELECTRIC ELEVATED COOKER

INSTALLING THE ELECTRIC ELEVATED COOKER

Safety Warnings about installation

WARNING

• The cooker MUST be installed and serviced by a

qualified technician.

• A Certificate of Compliance MUST be supplied to be

kept by the customer.

• The packing materials MUST be removed before you

install the cooker.

• You MUST follow the installation instructions in this

booklet.

• In order to avoid overheating, the cooker must not

be installed behind ta decorative door.

• The surrounding kitchen cabinets MUST be able

to withstand 85°C. Electrolux Products WILL

NOT accept responsibility for damage caused by

installation into kitchen cabinets which cannot

withstand 85°C.

• In order to avoid overheating of the cooker,

the cooker must not be installed behind a

decorative door

• The appliance MUST be installed using the flexible

hose supplied.

• The vents, openings and air spaces MUST NOT

be blocked.

• You MUST NOT pull the cooker by the door handles

or the splashback.

• The cooker MUST be checked every five years.

• The cooker MUST NOT be used as a space heater.

Locating the cooker

Study the diagrams below to be sure of the dimensions

required to locate the cooker safely.

Wiring connection

postion

320

1085

544

900

600

Locating V

1095 Minimum

740 L.H. Oven

200 R.H. Oven

620

300 Maximum

Dimension to centre

line of anti-tilt plate

762

WARNING

In order to avoid accidental tipping of the appliance

(for example, by a child climbing onto the open oven

door), the anti-tilt plate MUST be installed.

Position the anti-tilt plate to the rear wall and 762mm

from the left side of the wall. Dimension to the “v”

at the front of the anti-tilt plate and then securely fix

-with fasteners.

The following table outlines the distance between the

floor supporting the product and the surface supporting

cooking vessel;

Surface type

(Supporting vessel)

Distance (MM)

Solid Hob 321

Enamel Trivets 327

Ceramic Glass 305

Download manual in English (PDF, 2.23 MB)
