Manual

Operations

Using handy features (Continued)

■ Cutting off the picture and sound temporarily (Mute)

When you want to project the images of another projector, overhead

projector, etc. temporarily, this projector’s images and sound can be

turned off.

Press the remote control’s MUTE button.

The picture and sound are cut off. (The Mute function is released

when pressing the MUTE button again.)

Notes

• The icon will appear while mute is in effect.

• Operating any other functions will also cancel the muting.

■ Freezing the image (Freeze)

The image being projected can be made to be frozen. This function is to

be used to pause a video during a presentation, etc.

Press the remote control’s FREEZE button.

The picture pauses. (The Freeze function is released when pressing

the FREEZE button again.)

Notes

• The icon will appear while freeze is in effect.

• Other operation will also release the freeze.

•Even if an image is frozen on the projector, the pictures are running on the video or

other equipment.

• If you use this function on video software sold on the market, broadcast or

broadcast on cable except for the purpose of your private viewing and listening, it

may infringe the copyright protected by the copyright laws.

Remote

Control

Remote

Control

You can call up on-screen menus, and conduct a number of adjustments and settings using

the operation buttons

p.16

on the control panel (main unit side) and remote control.

■ How to use the menus

The menu shown below is for operation instructions purposes and might differ from the

actual display.

Using the menus

Note

• Menu adjustments and settings are saved when the power is turned off via the ON/

STANDBY button. If the power cable is disconnected before this, or the power goes out,

then the data will not be saved.

Display the Setting display menu

The menu disappears.

1. Press the MENU button

2. Select a Category

3. Adjustments & Settings

4. Back

5. End

Press the MENU

button

Select a category by using

There are following four

categories:

Displays the current

adjustments and settings of

selected category.

Item shown with gray cannot

be adjusted with the current

input source.

p.30

Image adjustment menu

p.31

Display setting menu

Default setting menu

p.32

Status display menu

p.33

The figure shows displays given for operation instructions purposes. As the display

may differ depending on the item, use the following pages as a reference.

Item

Adjustment/Setting Value

These marks signify the

items can be adjusted/set

by using .

These marks signify the items can

be selected from the list by using

After an item is selected, apply it

by pressing .

Press to open the menu.

This mark signfy that

there are options.

Press to display a

list of options.
