Manual Toshiba TDP-T98 Projector

Manual

25

Operations

24

■ Using auto setting

This function sets up the projector to the optimum state for

each type of the input signal by using simple operations.

1

Press the SET UP button.

The Set up menu appears.

2

Press the SET UP button again.

The displayed menu item is automatically adjusted/set.

For computer input, the

icon will appear during

processing.

For manual adjustment and setting, see the following table

p.26

.

Note

• The image may not be projected or auto adjustment/setting may not be performed

correctly for input signals other than those supported by the projector

p.39

,

p.40

.

● Correcting the keystone distortion

When the foot adjuster

p.24

is used to change the projector placement angle while

projecting the image, the picture will undergo keystone (trapezoidal) distortion.

This projector is capable of correcting this keystone distortion

.

1

Press the SET UP button.

2

Press the button.

The keystone distortion is automatically corrected. The icon appears during this

correction.

● Manual adjustment

Press the SET UP button to display the Set up menu and select [Keystone]. Use

the

buttons for keystone adjustment. When the adjustment is finished, press

the RETURN button. The menu disappears.

Notes

• Depending on the amount of keystone adjustment and the content of images, some

information may be lost, or the picture quality may suffer.

•Keystone adjustment is available for the keystone distortion in a slant angle of ±15

degrees.

•Keystone adjustment will not change the shape of the menus, the start-up screen,

and the background (with no signal input).

Using handy features

Control panel

Remote

Control

Before correction

After correction

5

Projector placement angle adjustments

The placement angle and the height of the projected image can be adjusted by the foot

adjuster.

q Lift up the front of the projector to

the desired angle, then press the

foot adjuster release button.

The foot adjuster extends. Release the

button to lock the position.

w To adjust the horizontal angle, use

the tilt adjuster.

To stow the foot adjuster, hold up the projector

while pressing the foot adjuster release button,

then slowly lower the projector.

6

Adjusting the screen size and focus

q

Use the zooming lever to adjust the screen size.

w Use the focusing lever to adjust the focus.

Readjusting the projection size with the

zooming lever after focusing will cause the

projected image to be out of focus. In that case,

perform focusing again.

7

Adjusting the volume with the buttons

The speaker volume can be adjusted when an audio signal is being input.

Notes

• Note that a lamp characteristics may rarely cause the brightness to fluctuate slightly.

•A lamp is consumable item. If used for extended periods, images will appear dark, and

the lamp could burn out. This is characteristic of a lamp, and is not malfunction. (The

lifetime of the lamp depends on conditions of use.)

• The DMD

TM

is made using extremely advanced technology, but there may be black spots

(pixels that do not light) or bright spots (pixels that are constantly lit) on the panel. Please

note that these are not malfunctions.

• Although this projector supports a wide range of RGB signals

p.39

, any resolutions not

supported by this projector (XGA) will be expanded or shrunk, which will affect image

quality slightly. To view high-quality images, it is recommended that the computer’s

external output should be set to XGA resolution.

• With some models of computer having LCD displays or the like, displaying images

simultaneously on the projector and the monitor’s display may prevent the images from

displaying properly. If this happens, turn off the computer’s LCD display. For information

on how to turn off the LCD display, see the owner’s manual of your computer.

• If a signal not supported by the projector is input, the “Unsupported signal” will appear.

• If no signal is being input from the connected device, the “No signal” will appear.

• If an unavailable operation button is pressed, the

icon will appear.

1

2

1

2

Basic operations (Continued)
