English CONTROLS / POWER SUPPLY
1 2; ......................switches the player on, starts or pauses CD play
2 ............................display
3 9.........................stops CD play, clears a program or switches the player off
∞ .......................skips and searches CD tracks backwards
§ .......................skips and searches CD tracks forwards
4 DBB.....................switches the bass enhancement on and off. This button also
switches acoustic feedback (the beep) on/off when it is
pressed for more than 2 seconds
5 PROG...................programs tracks and reviews the program
6 MODE/ESP..........selects the different playing possibilities:
SHUFFLE,
SHUFFLE REPEAT ALL,
REPEAT, REPEAT ALL
and SCAN,
switch ESP on/off
7 VOLUME
+/- ......adjust the volume
8 p/LINE OUT........3.5 mm headphone socket, socket to connect the player to
another audio input of an additional appliance.
9 OPEN ç ............opens the CD lid
0 HOLD...................locks all buttons
RESUME .............stores the last position of a CD track played
OFF......................switches RESUME and HOLD off
! 4.5V DC...............socket for external power supply
@ ............................type plate
POWER SUPPLY / GENERAL INFORMATION
Use only the AY 3162 adapter (4.5 V / 300 mA direct
current, positive pole to the center pin). Any other product may damage the player.
1 Make sure the local voltage corresponds to the power adapter’s voltage.
2 Connect the power adapter to the 4.5V DC socket of
the player and to the wall socket.
Note: Always disconnect the adapter when you are not
using it.
Environmental information
• All redundant packing material has been omitted. We have done our utmost to
make the packaging easily separable into two materials: cardboard (box) and
polyethylene (bags, protective foam sheet).
•Your set consists of materials which can be recycled if disassembled by a
specialized company. Please observe the local regulations regarding the
disposal of packing materials, exhausted batteries and old equipment.
You can use the following batteries with this CD-player:
• normal batteries type LR6, UM3 or AA (preferably Philips), or
• alkaline batteries type LR6, UM3 or AA (preferably Philips).
Notes:–
Old and new or different types of batteries should not be combined.
– Remove batteries if they are empty or if the player is not going to be used for
a long time.
Inserting batteries
1 Push OPEN ç to open the CD lid.
2 Open the battery compartment and insert either 2
normal or alkaline batteries.
Battery indication
The approximate power level of your batteries is shown
in the display.
Battery full
Battery two-thirds full
Battery one-third full
Battery dead or empty.When the batteries are
dead or empty, the symbol A flashes,
bAtt is displayed, and the beep tone sounds repeatedly.
Batteries contain chemical substances, so they should be disposed
of properly.
• Do not touch the lens A of the CD player.
• Do not expose the unit, batteries or CDs to humidity,
rain, sand or excessive heat (caused by heating
equipment or direct sunlight).
•You can clean the CD player with a soft, slightly
dampened, lint-free cloth. Do not use any cleaning
agents as they may have a corrosive effect.
•To clean the CD, wipe it in a straight line from the
center toward the edge using a soft, lint-free cloth. A
cleaning agent may damage the disc! Never write on a CD or attach a sticker
to it.
• The lens may cloud over when the unit is moved suddenly from cold to warm
surroundings. Playing a CD is not possible then. Leave the CD player in a warm
environment until the moisture has evaporated.
• Active mobile phones in the vicinity of the CD player may cause malfunctions.
•Avoid dropping the unit as this may cause damage.
Headphones AY 3806
• Connect the supplied headphones to the p/LINE OUT
jack of the player.
Note: p / LINE OUTcan also be used for connecting
this set to your HiFi system.To adjust the sound
and volume, use the controls on the connected
audio equipment and on the CD player.
IMPORTANT!
Hearing safety: Do not play your headphones at a high volume. Hearing experts
advise that continuous use at high volume can permanently damage your hearing.
Traffic safety: Do not use headphones while driving a vehicle. It may create a hazard
and it is illegal in many countries. Even if your headphones are an open-air type
designed to let you hear outside sounds, do not turn up the volume so high that
you cannot hear what is going on around you.
CD player and CD handling
Batteries (supplied or optionally available)
