The PetSafe

®

Manual-Locking Cat Flap is suitable to fit most doors or partitions

although additional materials and competent DIY skills may be required. This cat

flap is designed to adapt easily to cut-out sizes for Staywell

®

200, 300, 400, 500,

900 and Petporte smart flap

®

series cat flaps. Some simple DIY skills are required

and minor adjustments to the cut-out or additional accessories might be needed.

Installation

–

Measurement and Marking

Measure the belly height of

your cat. This is usually

100 mm –150 mm (Fig. A).

Mark this measurement on the

outside of your door and draw

a straight horizontal line

168 mm long (Fig. B).

Please keep in mind that this horizontal line will eventually be the bottom of the hole

you will cut in your door. The frame of the cat flap will be 25 mm lower. If necessary,

this line may have to be raised slightly to account for some door designs.

Installation

–

Doors

1. Attach the supplied Cutting Template to the outside of your door in the correct

position, ensuring that it is the right way up and level (Fig. C).

2. Drill four (4) corner holes with a 12 mm diameter drill bit as marked on the

Cutting Template through the door (Fig. D). Please ensure that the drill remains

straight and level.

3. Using a jig or key-

hole saw, cut along

the dashed line as

indicated on the Cutting

Template (Fig. E).

(x)

Fig. A

(x)

Fig. B

(X)

(X)

Fig. D

(X)

Fig. C

Fig. E

4. Temporarily place both frames into the cut-out (Fig. F).

5. Level the cat flap until it is in the proper position. On the

outside, use a pencil to mark screw holes through the holes

on the exterior frame (Fig. G).

6. Remove the cat flap and drill the screw holes with a

6 mm drill (Fig. H).

7. Clean the area from any dust, dirt or debris.

8. Place the interior frame (with attached tunnel) into

the hole from the inside. Align the exterior frame to

the outside of the door. Four (4) different lengths of

screws have been provided with this cat flap. Select the

appropriate length. Using a manual screw driver, screw

the exterior frame through the holes in your door to the

interior frame (Fig. I).

9. When the installation of the cat flap is completed,

place the two (2) blanking plugs over the screws on the

exterior frame (Fig. J).

10. The cat flap is ready to use (Fig. K).

Screw Selection Guide

Cut-Out Thickness Screw Length

12 mm – 21 mm

40 mm screw

22 mm – 31 mm

50 mm screw

32 mm – 41 mm

60 mm screw

42 mm – 51 mm

70 mm screw

Fig. H

Fig. J

Fig. K

Fig. F

Fig. G

Fig. I
