Getting started

VQT3R83

≥ For a safety measure to prevent the speakers from falling, refer to page 16.

≥ To prevent damage or scratches, lay down a soft cloth and perform the assembly on it.

Insert the speaker cable through the base.

≥ Be sure to insert the speaker cable through the threading hole as indicated in the illustration.

Attach the speaker to the base.

≥ To make sure that the speaker cable is connected to the correct speaker, match the colour of the speaker connector with the

colour of the L/R indicator on the speaker label so as not to connect the speaker cable to the wrong speaker.

≥ Keep the screws out of reach of children to prevent swallowing.

(Continued on the next page)

Place the speakers using the base stands

∏ 1 Speaker (L) ∏ 1 Speaker (R) ∏ 2 Speaker cables

(L): WHITE

(R): RED

∏ 2 Bases ∏ 2 Screws B

(Small)

A Threading hole B Screw hole









Leave about 110 mm

Position the cable between the ridges.

Screw B (supplied)

≥ Tighten securely.

SC-HTB15EGEBGNGS_VQT3R83.book Page 15 Tuesday, June 28, 2011 2:34 PM
