RQT8654

Simple Setup

∫ [HT545W] Avoiding interference

To avoid possible interference, do not place the wireless system near any of the following devices.

The wireless system uses the same radio frequencies as other devices that may be present in your home.

The wireless system will automatically seek a clear channel if any of these other devices interfere with its communication. When this happens, the

wireless link indicator (“ [W] ”) flashes on the main unit, and there is a brief interruption in audio coming from the surround speakers.

This is the normal operation of the product working to assure the best possible performance of your Home Theater System.

If the interference persists, try moving the other devices to another location outside the range of the wireless system.

∫ Attaching to a wall

You can attach all of the speakers (except subwoofer) to a wall.

≥

The wall or pillar on which the speakers are to be attached should

be capable of supporting over 10 k

per screw. Consult a qualified

building contractor when attaching the speakers to a wall. Improper

attachment may result in damage to the wall and speakers.

1 Drive a screw (not included) into the wall.

2 Fit the speaker securely onto the screw(s) with the hole(s).

∫ Fitting speaker stands (not included)

Ensure the stands meet these conditions before purchasing them.

Note the diameter and length of the screws and the distance

between screws as shown in the diagram.

≥ The stands must be able to support over 10 kg.

≥

The stands must be stable even if the speakers are in a high position.

2.4GHz-band microwave oven

2.4GHz-band cordless phone

personal computer with

2.4GHz-band wireless LAN

e.g.

Speaker installation options

‰7.5 to 9.5 mm

5.0 to 7.0 mm

Wall or pillar

‰4.0 mm

[HT545] Front speaker

[HT545] Center speaker

200 mm

[HT545W] Center speaker[HT545] Surround speaker

[HT545W] Front and surround

speakers

In this position, the

speaker will likely

fall if moved to the

left or right.

Move the speaker

so that the screw

is in this position.

e.g.

Speaker stand

(not included)

Plate thickness plus

7 mm to 10 mm

e.g. [HT545] Center speaker

5 mm, pitch 0.8 mm

Metal screw holes

For attaching to

speaker stands

60 mm

Positioning the speakers

8654En_p03-13.fm Page 5 Wednesday, April 12, 2006 12:36 PM
