Specifications

■

General

Power supply

DC 5 V, 0.6 W

(Internal battery: 3.7 V (Li-polymer))

Operating time*

1

Approx. 4 hours 20 minutes

Charging time*

2

(25 ºC (77 ºF)) Approx. 2 hours

Charging temperature range 10 ºC to 35 ºC (50 ºF to 95 ºF)

Operating temperature range 0 ºC to 40 ºC (32 ºF to 104 ºF)

Operating humidity range 35%RH to 80%RH (no condensation)

Mass (Weight) Approx. 12 g (0.4 oz)

*

1

It may be shorter depending on the operating conditions.

*

2

Time taken to recharge from empty to full.

■

Bluetooth

®

section

Bluetooth

®

system specification Ver. 4.1

Wireless equipment classification Class 2 (2.5 mW)

Frequency band 2402 MHz to 2480 MHz

Max RF power 4 dBm (EIRP)

Supported profiles A2DP, AVRCP, HSP, HFP

Supported codec SBC

Operating distance Up to 10 m (33 ft.)

■

Speaker section

Driver units 9 mm (3/8 in.)

■

Terminal section

DC IN DC 5 V, 0.6 W

■

Microphone section

Type Mono

■

Accessory section

USB charging cord 0.1 m (0.3 ft.)

Earpieces set L, S

●

Specifications are subject to change without notice.

Useful information

(For Latin American Countries Only)

Customer Service

Customer Service Directory

Obtain products information and operative assistant; localize the closer

distributor or Service Center; buy spare parts and accessories by our

Web Site to Latin American:

COUNTRY WEB SITE CONTACT CENTER

Panama www.panasonic.com/pa/soporte/ 800-7262

Colombia www.panasonic.com/co/soporte/ 01-8000-947262

Ecuador www.panasonic.com/ec/soporte/ 1-800-726276

Costa Rica www.panasonic.com/cr/soporte/ 800-7262737

El Salvador www.panasonic.com/sv/soporte/ 800-7262

Guatemala www.panasonic.com/gt/soporte/ 1-801-811-7262

Uruguay www.panasonic.com/uy/soporte/ 0-800-7262

Paraguay www.panasonic.com/uy/soporte/ 0-800-11-7262

Chile www.panasonic.com/cl/soporte/ 800-390-602

022-797-5000

Peru www.panasonic.com/pe/soporte/ 0800-00726

Venezuela www.panasonic.com/ve/soporte/ 800-7262-800

Mexico www.panasonic.com/mx/soporte/ 01800-847-7262

55-5000-1200

Argentina www.panasonic.com/ar/soporte/ 0800-333-7262

0810-321-7262

Dominican Republic

www.panasonic.com/do/soporte/ 809-200-8000

The serial number of this product can be found on the tag.

Please note them in the space provided below and keep for future reference.

MODEL NUMBER RP-HJE120B

SERIAL NUMBER

To remove the battery when disposing

of this unit

The following instructions are not intended for repairing purposes but for

the disposal of this unit. This unit is not restorable once disassembled.

When disposing of this unit, take out the battery installed in this unit and recycle it.

Danger

As the rechargeable battery is specifically for this product, do not use it for any other

device.

Do not charge the removed battery.

• Do not heat or expose to flame.

• Do not leave the battery(ies) in a car exposed to direct sunlight for a long period of time with

doors and windows closed.

• Do not pierce the battery with a nail, subject it to an impact, or dismantle or modify it.

• Do not let the wires touch any other metal or each other.

• Do not carry or store the battery with a necklace, hair pin, or the like.

Doing so may cause the battery to generate heat, ignite, or rupture.

Warning

Do not place the removed battery, and other items within reach of infants.

Accidental swallowing of such an item may have an adverse effect on the body.

• In the event that you think such an item has been swallowed, consult a doctor immediately.

In the event of fluid leaking from the battery, take the following measure, and do not touch

the fluid with bare hands.

Fluid entering into an eye may cause loss of eyesight.

• Wash the eye with water immediately without rubbing it, and then consult a doctor.

Fluid getting on your body or clothes may cause inflammation of the skin or injury.

• Sufficiently rinse with clean water, and then consult a doctor.

A lithium-ion polymer rechargeable battery is built in to the battery case. Please

discard according to local regulations.

When disposing this product, disassemble properly by following the procedure, and

remove the internal rechargeable battery.

• Disassemble after the battery runs out.

• When disposing of the battery, please contact your local authorities or dealer and ask for the

correct method of disposal.

1

Battery case

2

Battery

3 4

1

Put a straight-slot screwdriver (commercially available) into the battery

case.

• Make sure to keep fingers away from the tip of the screwdriver.

• Select a screwdriver to be large enough for a space under the joint part.

2

Use the screwdriver for leverage, push and open the battery case.

• Be careful not to touch the battery with the screwdriver.

3

Hold the battery and remove it.

4

Pull off the battery and separate it from the battery case by cutting off the

wires, one by one, with scissors.

• Insulate the wire parts of the removed battery with cellophane tape.

• Do not damage or dismantle the battery.

(For US and Canada only)

A lithium ion battery that is recyclable powers the product you

have purchased. Please call 1-800-8-BATTERY for information

on how to recycle this battery.

Limited Warranty (ONLY FOR U.S.A.)

Panasonic Products Limited Warranty

Limited Warranty Coverage (For USA Only)

If your product does not work properly because of a defect in materials or workmanship,

Panasonic Corporation of North America (referred to as “the warrantor”) will, for the length

of the period indicated on the chart below, which starts with the date of original purchase

(“warranty period”), at its option either (a) repair your product with new or refurbished parts,

(b) replace it with a new or a refurbished equivalent value product, or (c) refund your purchase

price. The decision to repair, replace or refund will be made by the warrantor.

Product or Part Name Parts Labor

Headphones/Earphones/Headset 120 days Not Applicable

All Included Accessories 90 days Not Applicable

During the “Labor” warranty period there will be no charge for labor. During the “Parts” warranty

period, there will be no charge for parts. This Limited Warranty excludes both parts and labor

for non-rechargeable batteries, antennas, and cosmetic parts (cabinet). This warranty only

applies to products purchased and serviced in the United States. This warranty is extended

only to the original purchaser of a new product which was not sold “as is”.

Mail-In Service--Online Repair Request

Online Repair Request

To submit a new repair request and for quick repair status visit our Web Site at

http://shop.panasonic.com/support

When shipping the unit, carefully pack, include all supplied accessories listed in the Owner’s

Manual, and send it prepaid, adequately insured and packed well in a carton box. When

shipping Lithium Ion batteries please visit our Web Site at http://shop.panasonic.com/support

as Panasonic is committed to providing the most up to date information. Include a letter

detailing the complaint, a return address and provide a daytime phone number where you can

be reached. A valid registered receipt is required under the Limited Warranty.

IF REPAIR IS NEEDED DURING THE WARRANTY PERIOD, THE PURCHASER WILL

BE REQUIRED TO FURNISH A SALES RECEIPT/PROOF OF PURCHASE INDICATING

DATE OF PURCHASE, AMOUNT PAID AND PLACE OF PURCHASE. CUSTOMER WILL

BE CHARGED FOR THE REPAIR OF ANY UNIT RECEIVED WITHOUT SUCH PROOF OF

PURCHASE.

Limited Warranty Limits and Exclusions

This warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES

NOT COVER normal wear and tear or cosmetic damage. The warranty ALSO DOES NOT

COVER damages which occurred in shipment, or failures which are caused by products not

supplied by the warrantor, or failures which result from accidents, misuse, abuse, neglect,

mishandling, misapplication, alteration, faulty installation, set-up adjustments, misadjustment of

consumer controls, improper maintenance, power line surge, lightning damage, modification,

introduction of sand, humidity or liquids, commercial use such as hotel, office, restaurant, or

other business or rental use of the product, or service by anyone other than a Factory Service

Center or other Authorized Servicer, or damage that is attributable to acts of God.

THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER “LIMITED

WARRANTY COVERAGE”.

THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES

RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF

THIS WARRANTY.

(As examples, this excludes damages for lost time, travel to and from the servicer, loss of or

damage to media or images, data or other memory or recorded content. The items listed are

not exclusive, but for illustration only.)

ALL EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE WARRANTY OF

MERCHANTABILITY, ARE LIMITED TO THE PERIOD OF THE LIMITED WARRANTY.

Some states do not allow the exclusion or limitation of incidental or consequential damages, or

limitations on how long an implied warranty lasts, so the exclusions may not apply to you.

This warranty gives you specific legal rights and you may also have other rights which vary

from state to state. If a problem with this product develops during or after the warranty

period, you may contact your dealer or Service Center. If the problem is not handled to your

satisfaction, then write to:

Panasonic Corporation of North America

Consumer Affairs Department 8th Fl.

Two Riverfront Plaza

Newark NJ 07102-5490

PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED WARRANTY, ARE

YOUR RESPONSIBILITY.

for all your Panasonic gear

Go to

http://shop.panasonic.com/support

Get everything you need to get the most out of your Panasonic products

Accessories & Parts for your Camera, Phone, A/V products, TV,

Computers & Networking, Personal Care, Home Appliances, Headphones,

Batteries, Backup Chargers & more…

Customer Services Directory

For Product Information, Operating Assistance, Parts, Owner’s Manuals,

Dealer and Service info go to http://shop.panasonic.com/support

For the hearing or speech impaired TTY: 1- 877-833-8855

2004

Limited Warranty (ONLY FOR CANADA)

Panasonic Canada Inc.

5770 Ambler Drive, Mississauga, Ontario L4W 2T3

PANASONIC PRODUCT – LIMITED WARRANTY

EXCHANGE PROGRAM

Panasonic Canada Inc. warrants this product to be free from defects in material and

workmanship under normal use and for a period as stated below from the date of original

purchase agrees to, at its option either (a) repair your product with new or refurbished parts,

(b) replace it with a new or a refurbished equivalent value product, or (c) refund your purchase

price. The decision to repair, replace or refund will be made by Panasonic Canada Inc.

Accessories One hundred and twenty (120) days

This warranty is given only to the original purchaser, or the person for whom it was purchased

as a gift, of a Panasonic brand product mentioned above sold by an authorized Panasonic

dealer in Canada and purchased and used in Canada, which product was not sold “as is”, and

which product was delivered to you in new condition in the original packaging.

IN ORDER TO BE ELIGIBLE TO RECEIVE WARRANTY SERVICE HEREUNDER, A

PURCHASE RECEIPT OR OTHER PROOF OF DATE OF ORIGINAL PURCHASE,

SHOWING AMOUNT PAID AND PLACE OF PURCHASE IS REQUIRED

LIMITATIONS AND EXCLUSIONS

This warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES

NOT COVER normal wear and tear or cosmetic damage. The warranty ALSO DOES NOT

COVER damages which occurred in shipment, or failures which are caused by products not

supplied by Panasonic Canada Inc., or failures which result from accidents, misuse, abuse,

neglect, mishandling, misapplication, alteration, faulty installation, set-up adjustments,

misadjustment of consumer controls, improper maintenance, power line surge, lightning

damage, modification, introduction of sand, humidity or liquids, commercial use such as hotel,

office, restaurant, or other business or rental use of the product, or service by anyone other

than a Authorized Servicer, or damage that is attributable to acts of God.

Dry cell batteries are also excluded from coverage under this warranty.

THIS EXPRESS, LIMITED WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES,

EXPRESS OR IMPLIED, INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY

AND FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT WILL PANASONIC CANADA

INC. BE LIABLE FOR ANY SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES

RESULTING FROM THE USE OF THIS PRODUCT OR ARISING OUT OF ANY BREACH OF

ANY EXPRESS OR IMPLIED WARRANTY. (As examples, this warranty excludes damages

for lost time, travel to and from the Authorized Servicer, loss of or damage to media or

images, data or other memory or recorded content. This list of items is not exhaustive, but for

illustration only.)

In certain instances, some jurisdictions do not allow the exclusion or limitation of incidental or

consequential damages, or the exclusion of implied warranties, so the above limitations and

exclusions may not be applicable. This warranty gives you specific legal rights and you may

have other rights which vary depending on your province or territory.

CONTACT INFORMATION

For product operation and information assistance, please visit our Support page:

www.panasonic.ca/english/support

For defective product exchange within the warranty period, please contact the original dealer.

Avoid the use in the following conditions

• High or low extreme temperatures during use, storage or transportation.

• Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery,

that can result in an explosion.

• Extremely high temperature and/or extremely low air pressure that can result in an explosion

or the leakage of flammable liquid or gas.

Rating

More about this manual

We understand that it’s nice to have a paper manual for your Panasonic RP-HJE120B Headphone. You can always download the manual from our website and print it yourself. If you would like to have an original manual, we recommend you contact Panasonic. They might be able to provide an original manual. Are you looking for the manual of your Panasonic RP-HJE120B Headphone in a different language? Choose your preferred language on our homepage and search for the model number to see if we have it available.

Specifications

All manuals for Panasonic Headphones
More manuals of Headphones

Frequently Asked Questions about Panasonic RP-HJE120B Headphone

Our support team searches for useful product information and answers to frequently asked questions. If you find an inaccuracy in our frequently asked questions, please let us know by using our contact form.

Related products

Manual

Panasonic RP-HC101 Headphone

Manual

Panasonic RP-WF830EB Headphone

Manual

Panasonic RP-BTS35E Headphone

Manual

Panasonic RP-WF830WE Headphone

Manual

Panasonic RP-BTS10E Headphone

Manual

Panasonic RP-HD805 Headphone

Manual

Panasonic RP-BTS50E Headphone

Manual

Panasonic RZ-NJ320B Headphone

Related categories
