Manual

Basic Operations

14 15

Title Procedure Remarks, etc.

Using the Viewfinder

Before using the Viewfinder, adjust it to your eyesight

so that the indications in the Viewfinder are clear and

easy to read.

³Due to limitations in production technology, there may

be some tiny bright or dark spots on the Viewfinder,

however, these are not recorded on the tape.

Using the LCD Monitor

(NV-DS15, NV-DS150, NV-DS25 only)

It is also possible to record while viewing the picture on

the opened LCD Monitor.

Relationship between Viewfinder and LCD

Monitor

Opening the LCD Monitor turns off the Viewfinder.

Closing the LCD Monitor turns the Viewfinder on again.

However, turning the LCD Monitor forward also turns

on the Viewfinder again. (p. 28)

³Due to limitations in production technology, there may

be some tiny bright or dark spots on the LCD Monitor

screen, however, these are not recorded on the tape.

Set the [OFF/ON] Switch

to [ON].

Set the [OFF/ON] Switch

to [ON].

Tilt the Viewfinder

upward.

The angle of the

Viewfinder can be

adjusted upward.

Push the [3OPEN]

Button and turn out the

LCD Monitor

approximately 90x in the

direction of the arrow.

The Viewfinder turns off.

Adjust by sliding the Eyepiece Corrector Knob.

³Do not leave the Viewfinder exposed to direct

sunlight, as its magnifying glass could bundle the light

beams and seriously heat-damage the Viewfinder.

³The Viewfinder can be tilted upward by up to

approximately 70o.

Closing the LCD Monitor

Push the LCD Monitor close until the [3OPEN] Button

locks with a click.

Attach the shorter

loop to the Grip

Belt.

You can hook the

removed Lens Cap

onto the Grip Belt.

When not actually

recording, always

attach the Lens Cap

to the Lens to

protect it.

OFF

3OPEN

Eyepiece Corrector Knob

OFF

3OPEN

180˚

90˚

12:30:45

15.10.2000

12:30:45

15.10.2000

12:30:45

15.10.2000

12:30:45

15.10.2000

70˚

Adjust the angle of the LCD Monitor according to

the desired recording angle.

The LCD Monitor rotates upward a maximum of 180o

and downward a maximum of 90o from its normal

vertical position. Trying to forcefully rotate it beyond

this range could seriously damage the Movie

Camera.

OFF

Attaching the Lens Cap

Pass the longer

loop of the Lens

Cap Cord through

the attached eye

on the Lens Cap.

Then pass the

shorter loop of the

Lens Cap Cord

through the centre

of the longer loop

and pull tight.

³Do not leave the Lens exposed to direct sunlight, as it could bundle the light beams and seriously heat-

damage the CCD-Sensor.

³Before you start recording, remove the Lens Cap.
