INSTRUCTION MANUAL
Type C / N
DIGITAL TTL MACRO FLASH
Nissin Japan Ltd., Tokyo
http://www.nissin-japan.com
Nissin Marketing Ltd., Hong Kong
http://www.nissindigital.com
MF0611 REV. 1.2
Design and Specifications are subject to change without prior notice.
1
Thank you for purchasing a Nissin product
UNIQUE FUNCTION
Before using this flash unit, please read this instruction manual and refer
your camera owner’s manual carefully to get a better understanding of
proper operation to enjoy flash photography.
The color display automatically rotates to allow
for easy operation in both the horizontal and
vertical positions.
Nissin Macro Flash MF18 is a flash system for taking close-up photos of small
subjects using a flash to eliminate shadows, allowing you to enjoy photography.
This instruction manual is intended mainly for Canon or Nikon digital SLR, with
the latest TTL flash control system, and features Nissin’s original rotating color
display, easily guiding its operations.
It works automatically with Canon ETTL / ETTL II or Nikon i-TTL auto-flash
systems. The provided adapter rings make it available for use with different
lens. Please note that MF18 is not usable with other branded cameras for TTL
operation.
2
m
m
These safety instructions refer to important information on how to use this
product safely and properly. Please read the following instructions before using
the product.
3
SAFETY INSTRUCTIONS
WARNING
The flash unit contains high voltage electric parts. Do not try to open or repair the flash unit. Return it back
to the repair service station or the store you bought it from.
Do not touch the inside parts from the opening when the unit was dropped or broken.
Do not shoot the flash directly to the eye at short distance. It may damage the eye.
When taking a flash picture, especially toward a baby, it is recommended to keep the flash unit at least 1
meter (3.3feet) away from the subject. Or use diffuser or bounce the light to the ceiling or to the wall to
soften its intensity.
Do not place the flash unit near any flammable gas, chemical or such liquids. It may cause fire or electric
shock.
Do not touch the flash unit with wet hands or use in the water. The flash unit carries high voltage inside and
it may cause an electric shock.
Do not shoot the flash unit directly at the driver of automobiles or such vehicles.
Do not set the flash window close to the human body and shoot, which may get burned.
Place the batteries correctly in position. Placing the batteries in wrong polarity may cause leakage,
exothermic heat or explosion.
CAUTIONS
Do not leave or store the flash unit in the temperature over 40ºC, such as in the automobile.
The flash unit is not water resistance. Keep the unit away from rain, snow and humidity.
Do not use benzene, thinner or other alcoholic agents to clean the unit.
Do not use this flash unit with the cameras which are not recommended in compatibility list at official
website, otherwise it may damage the camera’s circuitry.
Remove the batteries when not in use for a longer period of time.
Do not have a heavy impact to the flash unit, nor throw it onto a hard surface floor.
When using the external power pack, read the safety instructions carefully and follow the operation manual.
This sign refers the danger or serious damage.
This sign refers the damage or defect.
4
Nomenclature
Display screen
Extra battery magazine
Lock ring
Hotshoe contacts
Foot lock pin
Adapter Rings x 6
52 / 58 / 62 / 67 / 72 / 77 mm
X-terminal
USB service port
Power Pack socket
External service box
Flash tube
Battery magazine
Set button
Select button
Select button
On/Off switch / Lock button
Pilot button
Mounting tabs
LED lamp (4x)
Expansion button
Release button
Release button
*49 / 55 / 82 mm (optional for purchase)
(optional for purchase)
MF18 Flash Modes and Functions - to be set on the flash unit.
For Canon: Functions by Flash setting
MENU SCREEN FOR MAIN MODES
5
6
Flash light is fully controlled by the camera for the most proper exposure.
ADVANCED FUNCTIONS
Full Automatic Mode
TTL Program Mode
Wireless Mode (Master)
Fine Macro Mode
Manual Mode
Custom Setting Mode
Full Automatic Mode
…
…
…
…
…
…
page 11
Flash light is automatically controlled by the camera but the flash exposure
TTL Program Mode
page 13
Master Mode - Selecting the desired manual power on the ring flash
Wireless Mode (Master)
page 15
Setting the flash power from 1/128 to 1/1024 with 1/6 Ev steps.
Fine Macro Mode
page 18
Setting the flash power from 1/1 (Full) to 1/64 with 1/3 Ev steps.
Manual Flash Mode
page 19
Variety of custom settings is available for own default value.
Custom Setting Mode
page 20
Flash exposure can be locked at the main subject while moving the framing.
FE. Lock
page 21
FE.
Lock
value can be compensated.
(Group A and B) and controlling the slave flashes (Group A or C).
m
m
m
Flash synchronizes to the faster shutter speed than regular synchronization speed.
High speed shutter synchronization
page 22
The flash fires just before the rear curtain closes. A moving subject will appear with
Rear curtain synchronization
page 23
Flash exposure can be locked at the main subject while moving the framing.
Fv. Lock
page 21
Fv.
Lock
The flash fires immediately after the first curtain has fully opened.
1st curtain synchronization
page 22
For Nikon: Functions by Camera setting
Flash synchronizes to the faster shutter speed than regular synchronization speed.
High speed shutter synchronization (FP)
page 23
The flash fires immediately after the first curtain has fully opened.
1st curtain synchronization
page 23
such moving marks behind.
The flash fires just before the rear curtain closes. A moving subject will appear with
Rear curtain synchronization
such moving marks behind.
A
B
page 23
