Manual Makita HTR7610 Hedgecutter

Need a manual for your Makita HTR7610 Hedgecutter? Below you can view and download the PDF manual for free in English. This product currently has 4 frequently asked questions, 0 comments and has 0 votes. If this is not the manual you want, please contact us.

Is your product defective and the manual offers no solution? Go to a Repair Café for free repair services.

Manual

EC-DECLARATION OF CONFORMITY

Hedge Trimmer: model HTR5600, HTR7610 (See TECHNICAL DATA for the specifications)

We declare under our sole responsibility that this product is in compliance with the following Directives, 2000/14/EC, 2006/42/EC.

The most important standards applied to properly meet the requirements of the adove Directives were: EN774.

Measured Sound Power: HTR5600 : 107 dB, HTR7610 : 110 dB

Guarantee Sound Power: HTR5600 : 109 dB, HTR7610 : 111 dB

These sound power levels wear measured in accordance with Council Directive, 2000/14/EC.

Conformity assessment procedure: Annex V.

3rd. NOV. 2009

Tomoyasu Kato

Director

Responsible Manufacturer:

Makita Corporation.

3-11-8,Sumiyoshi-cho, Anjo, Aichi, JAPAN

Authorized Representative in Europe:

Makita International Europe Ltd.

Michigan Drive, Tongwell, Milton kyenes, Bucks MK15 8JD, ENGLAND

SPECIFICATION

Model HTR7610 HTR5600

Dimensions (L x W x H) mm

1,041 x 280 x 258 840 x 246 x 225

Mass (with blade cover) kg

5.4 5.1

Volume (fuel tank) cm

600

Engine displacement cm

24.5

Cutting length mm 750 560

Maximum engine performance kw 0.88

Maximum blade speed m/s 1.88

Idling speed 1/min 2,600

Clutch engagement speed 1/min 3,600

Carburetor type type WALBRO WYL

Ignition system type Solid ignition system

Spark plug type NGK-BMR7A

Electrode gap mm 0.6 䌾 0.7

hv eq

m/s

6.1

11.1

Right handle

(Rear grip)

Uncertainty K m/s

0.5

0.6

hv eq

m/s

12.6

12.1

Vibration

per ISO

10517

Left handle

(Front grip)

Uncertainty K m/s

0.5

1.3

Sound pressure lever average dB(A)

according to EN774

95.7 89.4

Sound power level according to EN774 dB(A) 109.8 106.9

Mixture ratio (fuel : MAKITA 2-stroke engine oil) 50 : 1

Gear ratio 14 : 58

Download manual in English (PDF, 1.53 MB)

(Consider the environment and only print this manual if it is really necessary)

Rating

Let us know what you think about the Makita HTR7610 Hedgecutter by leaving a product rating. Want to share your experiences with this product or ask a question? Please leave a comment at the bottom of the page.

Are you satisfied with the Makita HTR7610 Hedgecutter?
Yes No

Be the first to rate this product

0 votes

Join the conversation about this product

Here you can share what you think about the Makita HTR7610 Hedgecutter. If you have a question, first carefully read the manual. Requesting a manual can be done by using our contact form.

More about this manual

We understand that it’s nice to have a paper manual for your Makita HTR7610 Hedgecutter. You can always download the manual from our website and print it yourself. If you would like to have an original manual, we recommend you contact Makita. They might be able to provide an original manual. Are you looking for the manual of your Makita HTR7610 Hedgecutter in a different language? Choose your preferred language on our homepage and search for the model number to see if we have it available.

Specifications

Brand	Makita
Model	HTR7610
Category	Hedgecutters
File type	PDF
File size	1.53 MB

All manuals for Makita Hedgecutters
More manuals of Hedgecutters

Frequently Asked Questions about Makita HTR7610 Hedgecutter

Our support team searches for useful product information and answers to frequently asked questions. If you find an inaccuracy in our frequently asked questions, please let us know by using our contact form.

How do I know my hedgecutter is blunt? Verified

When branches are being pulled instead of cut, the hedgecutter is blunt and needs to be sharpened.

This was helpful (345) Read more

How do I sharpen my hedgecutter blades? Verified

Sharpening your hedgecutter blades is important for maintaining the performance and efficiency of the tool. To sharpen the blades, you will need a file or sharpening stone specifically designed for the type of blade on your hedgecutter.

This was helpful (299) Read more

How do I lubricate my hedgecutter blades? Verified

Lubricating your hedgecutter blades will help to reduce friction and wear, prolonging the life of the tool. Use a high-quality lubricating oil specifically designed for hedgecutters and apply a small amount to the blades after each use.

This was helpful (147) Read more

How can I prevent rust from forming on my hedgecutter blades? Verified

Rust can cause damage to your hedgecutter blades, reducing their performance and lifespan. To prevent rust, clean and dry the blades thoroughly after each use and store them in a dry, clean place. You can also consider applying a protective coating, such as oil or a rust inhibitor, to the blades before storing them.

This was helpful (90) Read more
