Manual Logik L800BLS21 Blender

Manual

Locking the Jug to the Base Unit

• Place the jug on the base. The

jug will t only one way round.

• Turn the jug clockwise to lock,

the triangle on the handle

bottom should be aligned with

the lock symbol marked on

the base. You will hear a “click”

to indicate the jug is locked to

the base.

• To unlock, turn the jug anti-

clockwise.

The jug must be secured and locked to the base,

otherwise the blender will not operate!

Operation

1. Make sure the jug and the lid are secure and locked in place.

2. Set the Speed Selector to ‘0’.

3. Plug your blender into the mains socket.

Operation Mode

Continuous

(Normal)

operation

• Select the desired operating speed.

There are 2 speeds.

• Move the Speed Selector progressively

to the right to increase the speed.

• When you start blending use a low

speed to begin with and gradually

increase the speed if necessary.

• To stop the operation, turn the Speed

Selector back to ‘0’.

Pulsed operation Use this mode when ingredients need to

be blended in small repeated bursts.

• Turn the Speed Selector to ‘P’ and hold

it there for a short period of time.

• To stop the operation, release the Speed

Selector which will then automatically

return to ‘0’.

Specications

Maximum Operation

Time

3 minutes ON and 1 minute REST

Product Rating 220-240VAC, 50Hz, 800W

Features and specications are subject to change without prior

notice.

Cleaning the blade assembly

1. Hold the jug handle with one hand and with the other hand

rotate the blade assembly to detach it from the jug.

2. Wash it under running water. You can also remove the rubber

seal ring from the blade assembly to clean (if applicable).

• Handle blades with care especially during cleaning as

they are extremely sharp!

• If the rubber seal ring in the blade assembly is also

taken out to clean, make sure to re-assemble it back

properly in place to avoid leakage (if applicable).

Cleaning the base

• Ensure the blender is unplugged from the mains socket.

• Wipe the outer surface of the base with a damp cloth. Never

use abrasive cleaners or scouring creams.

Never immerse the base in water when cleaning.

Storage

After all the components have been washed and dried, re-

assemble the blender and store it out of direct sunlight and out of

the reach of children.

Always unplug the appliance and let it cool down

before cleaning.

After Use

After you have nished blending:

1. Set the Speed Selector to ‘0’.

2. Unplug the blender from the mains socket.

3. Hold the jug by the handle and carefully turn it anti-clockwise

to release it. (This may be easier with one hand on the base and

one hand holding the jug handle).

4. To pour out the contents, rotate the lid of the jug anti-

clockwise to free it and then lift o the lid. Pour or spoon out

the contents carefully.

Cleaning and Storage

Cleaning the jug

1. Pour about 500ml of warm soapy water into the jug and place

the jug on the base.

2. Turn and hold the Speed Selector to ‘P’ for a few seconds to

loosen any food particles and free them from the blades.

• Remove the jug, pour away the water and rinse in fresh

running water. Repeat steps 1 and 2 with fresh water.

• Alternatively the jug may be immersed in warm soapy

water and cleaned using a long handled brush.

DO NOT wash the jug or attachments in a dishwasher.

• Do not run the appliance continuously for more

than 3 minutes. After a full 3 minute cycle allow the

blender to rest for 1 minute before using it again.

• Never blend very hot liquids in the blender. This is

dangerous as the contents may erupt.

• If you spill liquid on the base immediately switch o

and wipe dry.

During blending, you can feed in small amounts of food or liquid

through the lid. To do this:

1. Hold the lid.

2. Turn the stopper slowly to free it and then lift it out.

3. Gradually feed pieces of food or liquids into the jug.

4. Fit the stopper back when you have nished.

IB-L800BLS21-210608V1

• Wash the lid and stopper separately in warm soapy water,

rinse and allow to dry.

L800BLS21_IB_Final210608.indd 4-6L800BLS21_IB_Final210608.indd 4-6 8/6/2021 3:23 PM8/6/2021 3:23 PM
