Electrical connection

The following installation procedure must be carried

out by a qualified electrician.

 the cooker must be connected to the mains by a

switched (double pole) cooker outlet correctly fused

with a capacity appropriate to that shown on the hob

Rating Plate. All electrical wiring from the consumer

unit to the appliance, via the switched double pole

cooker outlet, must be of an acceptable type and

current rating as above. The supply cord, type H05

VV-F 3x2.5mm

, must be positioned so that it never

reaches at any point a temperature 50°C higher than

the room temperature. The electrical installation must

comply with the IEE Regulations, Building Regulation

& local By-Lays.

 THIS APPLIANCE MUST BE EARTHED.

In the case of installation over a built-in electric oven

the electrical hook-up of the stove top and that of the

oven should be separate, for reasons of safety as well

as for ease of eventual removal of the oven.

Supply cable installation

The electrcic hobs are supplied without cable. Use a

cable:

H05 VV-F 3x2.5mm

 Open the terminal box by removing the "V" screw

and taking off the cover.

 The wires in the mains lead are coloured in

accordance with the following code:

Green & Yellow - Earth E

Blue - Neutral N

Brown - Live L

Connect the wires in accordance with the following

diagram

32154

 Fix the cable in place with the "F" cable clamp,

close the lid and fasten it with the "V" screw (see

picture).
