Manual

 Before operating your new appliance please read this

instruction booklet carefully. It contains important

information for safe use, installation and care of the

appliance.

 Please keep these operating instructions for future

reference. Pass them on to possible new owners of the

appliance.

Positioning

 Keep packaging material out of the reach of children. It

can become a choking or suffocation hazard (see

Precautions and tips).

 The appliance must be installed by a qualified person

according to the instructions provided. Incorrect

installation may damage property or cause harm to

people or animals.

Built-in

It is possible to instal them next to furniture which is

higher than the working board. For a correct

installation of the cooking top the following

precautions must be followed:

 The hob may be located in a kitchen, a kitonen/

diner or bed sitting room, but no in a bathroom or

shower room.

 The hoods must be installed according to the

requirements in the hood handbook.

 The dimensions of the cutout for the appliance must

be those indicated in the figure. Clamps are

provided to fasten the cooktop to counters

measuring from 20 to 40 mm in thickness. To fasten

the cooktop securely, it is recommended that all the

clamps be used.

555 mm

55 m

475 mm

Fastening Clamps - Assembly Diagram

Clamp Position for Clamp Position for

H=20mm top H=30mm top

Front

Clamp Position for Back

H=40mm top

 Use the clamps contained in the "accessory kit."

 In case a wooden panel should be fitted under the

top for insulation, it will have be fitted at a minimum

distance of 20 mm from the inferior part of the top.

Ventilation

When installing the cooktop above a built-in oven, the

oven should be placed on two wooden strips; in the

case of a joining cabinet surface, remember to leave a

space of at least 45 x 560 mm at the back (see

picture).

When installing on a built-in oven without forced

ventilation, ensure that there are air inlets and outlets

for ventilating the interior of the cabinet adequately

(see picture).

Installation

560 mm.

45 mm.
