Manual

Installation

! Before operating your new appliance please read

this instruction booklet carefully. It contains important

information concerning the safe operation, installation

and maintenance of the appliance.

! Please keep these operating instructions for future

reference. Pass them on to possible new owners of the

appliance.

The following instructions are provided for qualified

installers so that they may accomplish installation,

adjustment and technical maintenance operations

correctly and in compliance with current regulations

and standards.

Important: the appliance should be disconnected

from the mains electricity supply before any

adjustment, maintenance, etc. is carried out.

Maximum caution should be used should it be

necessary to keep the appliance connected to the

electricity supply.

The appliance has the following technical

specifications:

Category: II 2H3+

Positioning

The dimensions of the appliance are given in the

figure. For trouble-free operation of appliances

installed in housing units, the minimum distances

shown in figure should be observed. Adjacent

surfaces and the wall at the rear should also be able

to withstand an overheating temperature of 65 °C.

In the lower part of the cooker there are 4 height

adjustable screw-in feet with which it is possible to

level the cooker if necessary.

Important: this unit may be installed and used only in

permanently ventilated rooms according to the British

Standards Codes Of Practice: B.S. 6172/B.S. 5440,

Par. 2 and B.S. 6891 Current Editions. The following

requirements must be observed:

a) The cooker should not be installed in a bed sitting

room with a volume of less than 20m

. If it is

installed in a room of volume less than 5m

an air

vent of effective area of 110cm

is required, if it is

installed in a room of volume between 5m

and

10m

a supplementary airvent area of 50cm

required, if the volume exceeds 11m

no airvent is

required. However, if the room has a door or a

window which opens directly to the outside no air

vent is required even when the volume is between

and 11m

b) During prolonged use of the appliance you may

consider it necessary to open a window to the

outside to improve ventilation.

c) If there are other fuel burning appliances in the

same room, B.S.5440 Part 2 Current Edition, should,

be consulted to determine the requisite air vent

requirements.

Kitchen ventilation

The air flow into the room where the appliance is

installed must equal the quantity of air that is required

for regular combustion of the gas and for ventilating

the same room. Air must enter naturally through

permanent apertures made in the outside walls of the

room or through single or branching collective

ventilation ducts in compliance with the norms. The air

must be taken directly from the outside, from an area

far from sources of pollution. The ventilation aperture

must have the following characteristics:

• total free cross section of passage of at least 6 cm²

for every kW of rated heating capacity of the

appliance, with a minimum of 100 cm² (the heating

capacity is indicated on the rating plate);

• it must be made in such a way that the aperture,

both on the inside and outside of the wall, cannot

be obstructed;

• it must be protected, e.g. with grates, wire mesh,

etc. in such a way that the above-mentioned free

section is not reduced;

• it must be situated as near to floor level as possible.

Examples of ventilation holes

for comburant air.

Enlarging the ventilation slot

between window and floor.

Adjacent

Room

Room to be

Vented

The air inflow may also be obtained from an adjoining

room, provided the latter is not a bedroom or a room

where there is a risk of fire, such as warehouses,

garages, fuel stores, etc. and is ventilated in
