Manual

• Do not position

blinds behind the

cooker or less than 200

mm away from its

sides.

• Any hoods must be

installed according to

the instructions listed in

the relevant operating

manual.

Levelling

If it is necessary to level the

appliance, screw the

adjustable feet into the places

provided on each corner of the

base of the cooker (see

figure).

The legs* fit into the slots on

the underside of the base of

the cooker.

HOOD

900

Min. mm.

420

Min.

min.

650

mm. with hood

min.

700

mm. without hood

mm.

420

Min. mm.

Gas connection

Connection to the gas network or to the gas cylinder

may be carried out using a flexible rubber or steel hose,

in accordance with current national legislation and after

making sure that the appliance is suited to the type of

gas with which it will be supplied (see the rating sticker

on the cover: if this is not the case see below). When

using liquid gas from a cylinder, install a pressure

regulator which complies with current national

regulations. To make connection easier, the gas supply

may be turned sideways*: reverse the position of the

hose holder with that of the cap and replace the gasket

that is supplied with the appliance.

! Check that the pressure of the gas supply is

consistent with the values indicated in the Table of

burner and nozzle specifications (see below). This

will ensure the safe operation and durability of your

appliance while maintaining efficient energy

consumption.

Gas connection using a flexible rubber hose

Make sure that the hose complies with current

national legislation. The internal diameter of the hose

must measure: 8 mm for liquid gas supply; 13 mm for

methane gas supply.

Once the connection has been performed, make sure

Electrical connection

WARNING – THIS APPLIANCE MUST BE EARTHED.

Electrical connection

Electric cookers come without a power supply cable. The

cooker is designed to operate on an electricity supply which

conforms to the electrical data shown on the Rating Plate. The

cooker can be connected to the mains only after removing

the back panel of the cooker itself with a screwdriver.

N.B.: the following installation procedure must be carried out

by a qualified electrician. The electrical installation must comply

with the IEE Regulations, Building & local By-Lays.

For the installation of the feeding cable carry out the following

operations:

l Using a screwdriver, prise on the side tabs of the

terminal board cover (see fig. A);

l Pull and open the junction blok lid

Important: the wires in the mains lead are coloured in

accordance with the following code:

Green & Yellow -Earth

Blue -Neutral

Brown -Live

As the colours of the wires in the mains lead may not

correspond with the coloured markings identifying the

terminals in your plug, proceed as follows:

Green & Yellow wire to terminal marked “E” or

or coloured

Green or Green & Yellow.

Brown wire to terminal marked “L” or coloured Red.

Blue wire to terminal marked “N” or coloured Black (see fig.

B).

l fix the feeding cable in the special cable stop and

close the cover.

N.B.: the power supply cable must have these minimum

requirements:

Type: H05RR-F

Section: 3x2.5 mm

Ensure that the mains cable is routed away from any brackets

affixed to the rear panel and is not trapped to the rear wall

when pushing the cooker into position between cabinets.

Fig. A

Fig. B
