Manual Indesit KN3C62A(W)/U Range

Need a manual for your Indesit KN3C62A(W)/U Range? Below you can view and download the PDF manual for free in English. This product currently has 8 frequently asked questions, 0 comments and has 0 votes. If this is not the manual you want, please contact us.

Is your product defective and the manual offers no solution? Go to a Repair Café for free repair services.

Manual

! Before operating your new appliance please read

this instruction booklet carefully. It contains

important information concerning the safe installation

and operation of the appliance.

! Please keep these operating instructions for future

reference. Make sure that the instructions are kept

with the appliance if it is sold, given away or moved.

! The appliance must be installed by a qualified

professional according to the instructions provided.

! Any necessary adjustment or maintenance must be

performed after the cooker has been disconnected

from the electricity supply.

Positioning and levelling

! It is possible to install the appliance alongside

cupboards whose height does not exceed that of the

hob surface.

! Make sure that the wall in contact with the beck of

the appliance is made from a non-flammable, heat-

resistant material (T 90°C).

To install the appliance correctly:

• Place it in the kitchen, dining room or the bed-sit

(not in the bathroom).

• If the top of the hob is higher than the cupboards,

the appliance must be installed at least 200 mm

away from them.

• If the cooker is

installed underneath a

wall cabinet, there must

be a minimum distance

of 420 mm between this

cabinet and the top of

the hob.

This distance should be

increased to 700 mm if

the wall cabinets are

flammable (

see figure

• Do not position blinds behind the cooker or less

than 200 mm away from its sides.

• Any hoods must be installed according to the

instructions listed in the relevant operating manual.

Levelling

If it is necessary to level the

appliance, screw the

adjustable feet into the places

provided on each corner of the

base of the cooker (

see

figure

The legs* fit into the slots on

the underside of the base of

the cooker.

Electrical connection

Fitting the power supply cable

The cable should be suited to the type of electrical

connection used, according to the following

connection diagram:

To install the power supply cable correctly:

1. Loosen the screw V

in the terminal board

and pull the cover to

open it (

see figure

2. Position the

connection supports A

(

see figure

) according

to the connection

diagram shown above.

The terminal board is

designed for single-

phase 230 V

connection: terminals 1,

2 and 3 are connected

to each other; jumper 4-

5 is located in the lower

area of the terminal

board.

3. Position the wires N

and

6 as shown in the

Installation

HOOD

420

Min.

min.

650

mm. with hood

min.

700

mm. without hood

mm.

600

Min. mm.

420

Min. mm.

Only available in certain models.

1 2

12345

400V 3N~

H05RR-F 5x2.5 CEI-UNEL 35363

400V 2N

H05RR-F 4x4 CEI-UNEL 35363

230V

H05RR-F 3x4 CEI-UNEL 35363

Download manual in English (PDF, 3.07 MB)

(Consider the environment and only print this manual if it is really necessary)

Rating

Let us know what you think about the Indesit KN3C62A(W)/U Range by leaving a product rating. Want to share your experiences with this product or ask a question? Please leave a comment at the bottom of the page.

Are you satisfied with the Indesit KN3C62A(W)/U Range?
Yes No

Be the first to rate this product

0 votes

Join the conversation about this product

Here you can share what you think about the Indesit KN3C62A(W)/U Range. If you have a question, first carefully read the manual. Requesting a manual can be done by using our contact form.

More about this manual

We understand that it’s nice to have a paper manual for your Indesit KN3C62A(W)/U Range. You can always download the manual from our website and print it yourself. If you would like to have an original manual, we recommend you contact Indesit. They might be able to provide an original manual. Are you looking for the manual of your Indesit KN3C62A(W)/U Range in a different language? Choose your preferred language on our homepage and search for the model number to see if we have it available.

Specifications

Brand	Indesit
Model	KN3C62A(W)/U
Category	Ranges
File type	PDF
File size	3.07 MB

All manuals for Indesit Ranges
More manuals of Ranges

Frequently Asked Questions about Indesit KN3C62A(W)/U Range

Our support team searches for useful product information and answers to frequently asked questions. If you find an inaccuracy in our frequently asked questions, please let us know by using our contact form.

The oven in my range does not get warm enough, what should I do? Verified

The thermostat makes sure the ovens heats up to the designated temperature. It is likely that the thermostat is defective. Have it replaced. When in doubt, contact the manufacturer.

This was helpful (1209) Read more

Why does the ignition on my range make a clicking sound? Verified

If the range has ben cleaned with a lot of water, the knobs might have gotten wet, triggering the ignition. Let the knobs dry. If the problem persists you should contact the manufacturer.

This was helpful (1205) Read more

Which pans can be used on an induction range? Verified

In general all pans that are magnetic can be used on an induction range. Almost all new pans are suited for induction.

This was helpful (914) Read more

My range has a power plug that doesn't fit a regular socket, what should I do? Verified

Many electric ranges (both ceramic and induction) have a different plug. This is because these appliances require a lot of power. Have the installation of the appliance done by a professional.

This was helpful (542) Read more

What is pyrolysis? Verified

Some ovens are equipped with a pyrolysis function. This is a cleaning system that burns dirt and fat in the oven by using very high temperatures. After pyrolysis, all the dirt will have turned to ash and can be easily removed. If the oven has a pyrolysis function, it is advisable to use it 3 to 4 times a year to keep the oven clean.

This was helpful (478) Read more

Can I connect a range to an extension cord? Verified

Appliances that require large amounts of power, like a range, can not be connected to all extension cords. See what the power usage of the range is, which is indicated in Watt, and check if the extension cord can handle this. There are extension cords with thicker cables that are made to handle larger appliances.

This was helpful (247) Read more

When I use the oven there often food remains that fall on the bottom, causing smoke. How can I prevent this? Verified

Many ovens come with both a grid and a baking tray. When food is prepared on the grid, the baking tray can be placed on the bottom to prevent food remains from burning and causing smoke.

This was helpful (240) Read more

Can I prepare several items simultaneously by using more grill trays? Verified

Technically this is possible. However, it depends on the type of food if you need to adjust the preparation time or swap the trays halfway during the preparation.

This was helpful (239) Read more
