Manual

Instruction booklet

TUMBLE DRYER

Step 1

Open the door of your dryer

Step 2

Pull out the ﬁ lter (using the

two ﬁ nger grips)

Step 3

Clean the ﬂ uff off the ﬁ lter

and replace it correctly.

Ensure that the ﬁ lter is

pushed fully home.

Step 4

Make sure the ﬁ lter is pushed fully home

NEVER run the dryer without the ﬁ lter in position

Failure to clean the ﬁ lter after EVERY drying

cycle will affect the drying performance of your

machine. It will take longer to dry and as a result

will use more electricity during drying.

At least every two or three months you MUST

clean ﬂ uff build up around the ﬁ lter housing and

the vent tube.

IDV 75 UK

IDV 75 S UK

IDV 75B K UK

WHERE TO INSTALL THE TUMBLE DRYER

15 mm

If you are going to install the

appliance under a work

counter be sure to leave a

10 mm space between the

top and any other objects on

or above the machine and a

15 mm space between the

sides and any kitchen units

or walls to ensure proper air circulation. The

dryer must never be installed behind a lockable

door, a sliding door or a door with a hinge on the

opposite side to that of the dryer door.

The appliance must be installed with the rear

surface placed against a wall.

VENTILATION

When the dryer is in use there has to be adequate

ventilation to avoid the back ﬂ ow of gases into

the room from appliances burning other fuels,

including open ﬁ res. The vent tube should not exceed 2.4

metres in length. The tube should be kept clear of the air intake

vent and kinks or ‘U’ bends must be avoided as these will obstruct

the tube and trap condensation.

VENTING

Wall mounting

Keep the tube as short and as straight

as possible to prevent condensation

forming in the vent pipe.

The duct in the wall should slope

slightly downwards.

Window mounting

The hole in the window should be as

low down as possible and the tube should be kept as short as

possible.Depending on how often you use your tumble dryer, it is

essential that areas

A and B are checked periodically to remove

lint or debris.

This symbol reminds you to read this booklet.

Open window venting

The end of the tube should be

directed downwards, to prevent

warm moist air from condensing in

the room or dryer.

Do not discharge exhaust

air into a ﬂ ue which is used

for exhaust fumes from

other appliances that burn gas or other fuels.

Do not discharge exhaust air into an extraction system or any duct

with an extractor fan. This will affect the way the thermal controls

operate and can result in a ﬁ re hazard.

ELECTRICAL CONNECTIONS

The socket must be grounded. The power supply

cord should be checked periodically. If the

supply cord is damaged, it must be replaced by

the manufacturer, its service agent or similarly

qualiﬁ ed persons in order to avoid a hazar

LEVELLING YOUR DRYER

The dryer must be installed level for

correct operation. When you have

installed your dryer in its ﬁ nal location

check that it is ﬁ rst level side to side and

then back to front.

If the dryer is not level use a wooden

block to support it while adjusting the

two front legs up or down until your dryer is level.

BEFORE YOU START USING YOUR DRYER

Once you have installed your dryer and before you

use it clean the inside of the drum to remove any

dust that could have accumulated during transport.

Air intake vent

Do not block or obstruct

Caution: Hot!

Vent Tube ﬁ tted here
