Manual

Reversibilidad de la puerta

Desconecte el enchufe antes de efectuar cualquier

tipo de operación.

Para cambiar la dirección de apertura de la puerta,

proceda de la manera siguiente:

1. Extraiga la rejilla de ventilación (D) encajada.

2. Desmonte el cubreagujero (G) y la bisagra

inferior (E) desenroscando los dos tornillos que

la fijan.

3. levante y saque la puerta del perno (G),

desenrosque el perno y colóquelo en el lado

opuesto;

4. Quite los dos tapones de las puertas (donde

están previstos), dejando descubiertos los

agujeros para los pernos de la bisagra y vuelva a

montarlos en el lado opuesto;

5. vuelva a montar la puerta;

6. Con una llave de 10 mm desenrosque el perno de

la bisagra (E) y vuelva a montarlo en el lado

opuesto de la bisagra.

7. Vuelva a montar la bisagra inferior (E) en el lado

opuesto utilizando los tornillos que se habían

quitado; introduzca los cubreagujeros (G) en la

bisagra inferior. Quite los cubreagujeros (F) de la

rejilla de ventilación (D) empujándolos en el

sentido de la flecha y móntelos nuevamente en el

lado opuesto.

8. Vuelva a montar la rejilla de ventilación (D)

encajándola.

9. Desenrosque la manilla. Colóquelas nuevamente

en el lado opuesto después de haber perforado

los tapones con un punzón. Cubra los agujeros

que han quedado descubiertos con los tapones

contenidos en la bolsita entregada junto con la

documentación.

Atención

Terminada la operación de reversibilidad de la

puerta, controlar que la empaquetadura magnética

esté adherida al mueble. Si la temperatura ambiente

es fría (por ejemplo en invierno), puede suceder que

la empaquetadura no adhiera perfectamente al

mueble. En este caso esperar que la

empaquetadura se recobre en forma natural o bien

acelerar dicho proceso calentando la parte

interesada con un normal secador de cabellos.

D594

Distanciadores posteriores

En la bolsita de la documentacion hay dos

distanciadores que deberàn ser montados como se

muestra en la figura.

Aflojar los tornillos, introducir el distanciador debajo

de la cabeza del tronillo y volver a atornillar.

Rear spacers

In the bag with the documentation, there are two

spacers which must be fitted in the two top

corners.

Slacken the screws and insert the spacer under the

screw head, then re-tighten the screws.

D594

Changing the opening direction of

the doors

Before carrying out any operations, remove the plug

from the power socket.

To change the opening direction of the door,

proceed as follows:

1. pull off the ventilation grille (D) which is clipped

into place;

2. remove the bottom hinge (E) by unscrewing its

three fixing screws;

3. remove the door, releasing it from the upper pin

(G);

4. unscrew the upper pin (G) and refit it on the

opposite side;

5. remove the two plugs of the door (where

available), discovering the holes for the hinge

pins, assemble them on the opposite side;

6. reassemble the door;

7. using a 10 mm spanner, unscrew the hinge pin

(E) and reassemble it on the opposite side of the

hinge;

8. reassemble the lower hinge (E) on the opposite

side, using the screws previously removed; insert

the hole cover (G) on the lower hinge. Slide the

hole cover (F) out of the ventilation grille (D) by

pushing it in the direction of the arrow and

reassemble it on the opposite side;

9. refit the ventilation grille (D), clipping it into

place.

10.Dismantle the handle and reassemble it on the

opposite side. Cover the holes left open with the

plugs contained in the documentation pack.

Warning:

After having reversed the opening direction of

the doors check that all the screws are properly

tightened and that the magnetic seal adheres to

the cabinet. If the ambient temperature is cold

(i.e. in Winter), the gasket may not fit perfectly to

the cabinet. In that case, wait for the natural

fitting of the gasket or accelerate this process by

heating up the part involved with a normal

hairdrier.
