Manual

INSTALLER Section (en)

7679433.01 (3-06/17)

10. INSTALLING THE DUCTS

The boiler is easy and exible to install thanks to the extensive range of available accessories, as described below. The boiler

has been designed for connection to a vertical or horizontal coaxial ue-air duct. The boiler can also be used with separate ducts

using the accessory splitting kit.

WARNINGS

C13, C33 The terminals for separate ues must be tted inside a 50 cm square. Detailed

instructions are provided with the individual accessories.

C53 Do not t the ue and air duct terminals on opposite walls of the building.

C63 The pressure drop of the ducts must not exceed 100 Pa. The ducts must be certied for

this specic use and for a temperature in excess of 100°C. The ue terminal must be certied

to EN 1856-1.

C43, C83 The ue terminal or ue duct must be suitable for the purpose.

To optimise operating safety, make sure the ue ducts are rmly xed to the wall with

suitable brackets. The brackets must be positioned over the joints at a distance of

approximately 1 metre from one another.

Read carefully the venting instructions contained in this manual and the ones supplied by the vent manufacturer, in

case of discrepancies the venting instruction of this manual must be respected.

10.1 CONCENTRIC DUCTS

This type of duct is used to discharge exhaust fumes and draw

combustion air both outside the building and if a LAS ue is tted.

The 90° coaxial bend allows the boiler to be connected to a ue-

air duct in any direction as it can be rotated by 360° It can also

be used as a supplementary curve combined with a coaxial duct

or a 45° curve.

If fumes are discharged outside the building, the ue-air duct

must protrude at least 18 mm from the wall to allow an aluminium

weathering surround to be tted and sealed to avoid water

inltrations.

• A 90° bend reduces the total duct length by 1 metre.

• A 45° bend reduces the total duct length by 0.5 metres.

• The rst 90° bend is not included when calculating the maximum available length.

Fasten the suction pipes using two galvanised Ø 4,2 mm self tapping screws with minimum length 19 mm. If not

included with the supply, screws with the same characteristics must be sourced on the market separately.

Before securing the screws, make sure that at least 45 mm of the pipe is inserted into the gasket (see the gures in annex

"SECTION" D at the end of this manual).

Make sure there is a minimum downward slope of 5 cm per metre of duct towards the boiler.

SOME OUTLET DUCT INSTALLATION EXAMPLES AND THEIR RELATIVE MAXIMUM LENGTHS ARE SHOWN IN ANNEX

"SECTION" D AT THE END OF THIS MANUAL.










































