Manual Black and Decker IR03V Iron

Manual

Size: 19.685" x 17.5"

Customer Care Line:

USA 1-800-231-9786

Accessories/Parts (USA)

1-800-738-0245

For online customer service

and to register your product, go to

www.prodprotect.com/applica

Servicio para el cliente:

México 01-800 714-2503

Accesorios/Partes (EE.UU)

1-800-738-0245

Para servicio al cliente y para

registrar su garantía, visite

www.prodprotect.com/applica

Código de fecha / Date Code

Sello del Distribuidor:

Fecha de compra:

Modelo:

EASYSTEAM

IRON

PLANCHA EASYSTEAM

2011/7-5-10E/S

MODEL/MODEL

❍ IR03V

Please Read and Save this Use and Care Book.

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should

always be followed, including the following:

❍Read all instructions before using.

❍Use iron only for its intended use.

❍To protect against a risk of electric shock, do not immerse the

iron in water or other liquid.

❍The iron should always be turned off [0] (refer to HOW TO USE

section) before plugging into or unplugging from an outlet. Never

yank cord to disconnect from outlet; instead grasp plug and pull

to disconnect.

❍Do not allow cord to touch hot surfaces. Let iron cool completely

before putting away. Loop cord loosely around iron when storing.

❍Always disconnect iron from electrical outlet when filling with or

emptying of water and when not in use.

❍Do not operate iron with a damaged cord or if the iron has been

dropped or damaged. To avoid the risk of electric shock, do not

disassemble the iron, take it to a qualified serviceman for

examination and repair. Incorrect reassembly can cause a risk of

electric shock when the iron is used.

❍Close supervision is necessary for any appliance being used by

or near children. Do not leave iron unattended while connected

or on an ironing board.

❍Burns can occur from touching hot metal parts, hot water, or

steam. Use caution when you turn a steam iron upside down or

use the surge of steam—there may be hot water in the water

tank. Avoid rapid movement of iron to minimize hot water

spillage.

❍This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities, or

lack of experience and knowledge, unless they have been given

supervision or instruction concerning use of the appliance by a

person responsible for their safety.

❍Children should be supervised to ensure that they do not play with

the appliance.

❍The iron must be used and rested on a stable surface.

– When placing the iron on its stand, ensure that the surface on

which the stand is placed is stable.

– The iron is not to be used if it has been dropped, if there are

visible signs of damage or if it is leaking.

SPECIAL INSTRUCTIONS

❍To avoid a circuit overload, do not operate another high-wattage

appliance on the same circuit.

❍If an extension cord is absolutely necessary, a cord with an

ampere rating equal to or greater than the maximum rating of

the iron should be used. A cord rated for less amperage can

result in a risk of fire or electric shock due to overheating. Care

shall be taken to arrange the cord so that it cannot be pulled or

be tripped over.

SAVE THESE INSTRUCTIONS.

This product is for household use only.

POLARIZED PLUG

This appliance has a polarized plug (one blade is wider than the other).

To reduce the risk of electric shock, this plug is intended to fit into a

polarized outlet only one way. If the plug does not fit fully into the outlet,

reverse the plug. If it still does not fit, contact a qualified electrician.

Do not attempt to modify the plug in any way.

TAMPER-RESISTANT SCREW

Warning: This appliance is equipped with a tamper-resistant screw to

prevent removal of the outer cover. To reduce the risk of fire or electric

shock, do not attempt to remove the outer cover. There are no user-

serviceable parts inside. Repair should be done only by authorized

service personnel.

Note: If the power supply cord is damaged, it should be replaced by

qualified personnel; in Latin America, by an authorized service center.

How to Use

This product is for household use only.

GETTING STARTED

Remove any labels, stickers or tags attached to the body or soleplate of the

iron.

Note: Use ordinary tap water for ironing. Do not use water processed

through a home softening system.

Important: For optimum performance, let the iron stand for 90 seconds

before beginning to iron.

Tip: If unsure of a garment's fiber, test a small area (on an inside seam

or hem) before ironing.

Note: Use ordinary tap water for ironing. Do not use water processed

through a home softening system.

Important: For optimum performance, before you start ironing, plug iron

into electrical outlet and let it stand for 90 seconds.

FILLING WATER TANK

1. Tilt the iron and using a clean measuring cup, pour water into water-fill

opening until water reaches the MAX mark on the water tank. Refill as

needed.

2. Plug the iron.

IRONING WITH STEAM

Smart Steam® Technology

The Smart Steam® system automatically generates the right amount of

steam for the fabric type selected. Once you select the temperature, the

Smart Steam® technology detects the temperature and adjusts the steam

power accordingly.

Surge of Steam

1. With the water tank filled to the MAX mark, set fabric select dial to

appropriate setting (between 4 and 6) for your fabric. See fabric guide on

top of water tank and read the garment's label to help you determine

fabric type.

2. Be sure there is water in the tank. Steam is automatically turned off

between settings 0 and 3.

3. For best performance, press the steam button at 5-second Intervals.

4. When finished ironing, turn the fabric select dial to 0 and unplug the

iron.

Important: Always stand the iron on its heel rest when powered on but

not in use.

Vertical Steam

1. Be sure the water tank is filled to the MAX mark.

2. Hang the garment to be steamed on a clothes hanger. (Curtains or

drapes can be steamed once they are hung.)

3. Turn the fabric select dial to appropriate setting (between 4 and 6) for

your fabric.

4. Hold the iron close to (but not touching) the fabric.

5. Pull the fabric tight in your free hand and pump the steam button as you

move the iron over the fabric.

Important: Always stand the iron on its heel rest when powered on, but

Product may vary slightly from what is illustrated.

1. Spray nozzle

2. Water-fill opening

3. Fabric select dial

4. Spray button

5. Steam button

6. 360° pivoting cord

7. Heel rest

8. Fabric guide

9. Water tank

10. Soleplate

NEED HELP?

For service, repair or any questions regarding your appliance, call the

appropriate 800 number on the cover of this book. Please DO NOT return

the product to the place of purchase. Also, please DO NOT mail product

back to manufacturer, nor bring it to a service center. You may also want to

consult the website listed on the cover of this manual.

TWO-YEAR LIMITED WARRANTY

(Applies only in the United States and Canada)

What does it cover?

• Any defect in material or workmanship provided; however, Applica’s

liability will not exceed the purchase price of product.

For how long?

• Two years from the date of original purchase with proof of such

purchase.

What will we do to help you?

• Provide you with a reasonably similar replacement product that is either

new or factory refurbished.

How do you get service?

• Save your receipt as proof of date of sale.

• Visit the online service website at www.prodprotect.com/applica, or call

toll-free 1-800-231-9786, for general warranty service.

• If you need parts or accessories, please call 1-800-738-0245.

What does your warranty not cover?

• Damage from commercial use

• Damage from misuse, abuse or neglect

• Products that have been modified in any way

• Products used or serviced outside the country of purchase

• Glass parts and other accessory items that are packed with the unit

• Shipping and handling costs associated with the replacement of the unit

• Consequential or incidental damages (Please note, however, that some

states do not allow the exclusion or limitation of consequential or

incidental damages, so this limitation may not apply to you.)

How does state law relate to this warranty?

• This warranty gives you specific legal rights. You may also have other

rights that vary from state to state or province to province.

is a registered trademark of The Black & Decker Corporation,

Towson, Maryland, USA

Made and Printed in People’s Republic of China

not in use.

USING SPRAY

Use to dampen tough wrinkles at any setting.

1. Be sure the iron is filled with water.

2. On first use, pump the spray button several times.

ANTI DRIP SYSTEM

The anti drip system prevents water spotting at low temperatures.

DRY IRONING

1. Turn the fabric select dial to setting 1, 2 or 3 (DRY) to iron without steam.

The Smart Steam® system will automatically turn steam off.

2. To dry iron at higher settings, empty the water from the tank to prevent

steaming.

Care and Cleaning

This product contains no user serviceable parts. Refer service to qualified

service personnel.

CLEANING OUTSIDE SURFACES

• Make sure iron is unplugged and has cooled completely.

• Wipe soleplate and outer surfaces with a soft cloth dampened with

water. Add mild household detergent. Never use abrasives, heavy-duty

cleansers, vinegar or scouring pads that may scratch or discolor the

iron.

• After cleaning, steam iron over an old cloth to remove any residue from

the steam vents.

STORING YOUR IRON

1. Unplug iron and allow it to cool.

2. Check that fabric select dial is set to 0.

3. Store vertically on its heel to prevent water leaking from the soleplate.

When using your iron for the first time,

you may notice water residue inside the unit.

This is normal.

Cuando use su plancha por primera vez,

notará que hay agua adentro de la plancha.

Esto es normal.

5

7

6

9

10

2

3

4

1

8

1 200

W 120 V~ 60 Hz

© 2011 Applica Consumer Products, Inc.

Importado por / Imported by:

RAYOVAC ARGENTINA S.R.L.

Humboldt 2495 Piso# 3

(C1425FUG) C.A.B.A. Argentina.

C.U.I.T No. 30-70706168-1

Importado por / Imported by:

Rayovac de México SA de C.V

KM. 14.5 Carretera Puente de Vigas.

Col. Lechería, Tultitlán.

Estado de México.

C.P. 54940

México

Tel: (52) 5831-7070

Del interior marque sin costo

01 (800) 714 2503

Comercializado por:

Rayovac de México SA de C.V

KM. 14.5 Carretera Puente de Vigas.

Col. Lechería, Tultitlán.

Estado de México.

C.P. 54940

México

Tel: (52) 5831-7070

Servicio y Reparación

Art. 123 No. 95

Col. Centro, C.P. 06050

Deleg. Cuauhtemoc

Servicio al Consumidor,

Venta de Refacciones y Accesorios

01 800 714 2503

Rating

More about this manual

We understand that it’s nice to have a paper manual for your Black and Decker IR03V Iron. You can always download the manual from our website and print it yourself. If you would like to have an original manual, we recommend you contact Black and Decker. They might be able to provide an original manual. Are you looking for the manual of your Black and Decker IR03V Iron in a different language? Choose your preferred language on our homepage and search for the model number to see if we have it available.

Specifications

All manuals for Black and Decker Irons
More manuals of Irons

Frequently Asked Questions about Black and Decker IR03V Iron

Our support team searches for useful product information and answers to frequently asked questions. If you find an inaccuracy in our frequently asked questions, please let us know by using our contact form.

Related products

Manual

Black and Decker F975 Iron

Manual

Black and Decker F905 Iron

Manual

Black and Decker C520 Iron

Manual

Black and Decker IR1070SC Iron

Manual

Black and Decker IR05XC Iron

Manual

Black and Decker ICR505 Iron

Manual

Black and Decker IR0175W Iron

Manual

Black and Decker IR34V Iron

Related categories
