Any shelf or unit of combustible material should be at least 660mm above the

hotplate. In addition an area of 75mm wide on either side and behind the hotplate

must be clear of any combustible materials to a height of 400mm. Units must not

overhang over the hob.

Kitchen cabinets may be fitted flush to the sides of the cooker, but to allow for

cleaning and servicing

It is recommended that a 2.5mm gap be allowed on each side so that the cooker

may be moved if necessary.

The worktop or kitchen cabinets must not protrude beyond the height of the cooker

hotplate frame.

Ventilation Your appliance is not connected to a combustion products evacuation device. Th

e room in which it is to be installed must have an air supply in accordance with

national standards. The room must have an opening window or equivalent, and

some rooms may require a permanent vent in addition to the opening window.

General guidelines: The cooker must not be installed in a bedsit room of 20m³

less. If the cooker is installed in a room with a volume of less than 5m³, then a vent

with an effective area of 100cm³ is required. If it is installed in a room with a volume

of between 5m³

and 10m³, then an air vent with an effective area 50cm³

necessary. If there are other fuel burning appliances in the room, please consult

national standards for guidance.

Gas connection Gas connection to the hob should be made by flexible connecting reinforced tube

. compliant with BS 669-1. A 1/2" BSP threaded male fitting is supplied with the

cooker so that the flexible tube can be connected to the gas inlet. Appropriate

coupling connector and gas hose need to be supplied by the installer

Before connecting the appliance to the gas network, make sure that the data on the

rating plate attached on the under-oven drawer or on the back of the cooker are

compatible with what is indicated for the gas distribution network.

A rating plate attached on the last page of this handbook and in the under-oven

drawer (or on the back) of the appliance indicates the appliance adjustment

conditions: type of gas and operating pressure.

IMPORTANT: This appliance must be installed in compliance with current national

standards in force and used only in a well-ventilated room.

WARNING: It should be recalled that the appliance utilises a threaded 1/2" gas

cylindrical male fitting according to UNI-ISO 228-1.

To connect the appliance to the gas network with a flexible rubber hose, a

supplemental hose nipple fitting is needed (Fig.3) which is supplied with the

appliance.The appropriate coupling connector and gas hose need to be supplied by

the installer.

fig.3

Electrical connection The electric connection must comply with the current legal standards and

regulations.

Before making the connection, check that:

- The system electrical rating and the current outlets are adequate for the maximum

power output of the appliance (see the rating plate applied to back of the cooker).

- The outlet or the system is equipped with an efficient ground connection in

accordance with the current legal standards and regulations. The company will not

be responsible for the non-compliance with these instructions.

letter L (phase) = brown wire;

letter N (neutral) = blue wire;

ground symbol

= green-yellow wire;
