WASH CYCLES
Follow the instructions on the symbols of the garment’s wash
care label. The value indicated in the symbol is the maximum
recommended temperature for washing the garment.
Wash & Dry Mixed
Use this cycle to wash and dry mixed garments (cotton and synthetics) in
less than 4 hours. This cycle may be used to wash and dry loads of up to half
of the machine drying capacity; we recommend the use of liquid detergent.
Wash & Dry XL
This cycle is suitable for washing and drying without interruption cotton
bulky items, like bed linens and towels, with the possibility to fully load
the machine; we recommend using liquid detergent.
Cotton
Suitable for washing towels, underwear, table cloths, etc. made of
resistant linen and cotton that are moderately to heavily soiled.
Synthetics
Specic for synthetic items (e.g. polyester, polyacrylic, viscose, etc.). If the
dirt is dicult to remove, the temperature can be increased up to 60° and
powder detergent can be used too.
Wool - Woolmark Apparel Care - Green:
the wool wash cycle of this machine has been approved
by The Woolmark Company for the washing of wool
garments labelled as “hand wash” provided that the
products are washed according to the instructions on the
garment label and those issued by the manufacturer of
this washer-dryer. (M1318)
Delicates
For washing very delicate garments. For best results, turn the garments
inside out and use liquid detergent. If a time-based drying option is
added, a particularly delicate drying cycle is performed at the end of the
wash cycle, thanks to light handling and appropriate temperature control
of the water jet. The recommended durations are:
1 kg of synthetic garments --> 150 min
1 kg of synthetic and cotton garments --> 180 min
1 kg of cotton garments --> 180 min
The degree of dryness depends on the load and fabric composition.
Anti Allergy
Suitable for removing major allergens such as pollen, mites and cat or
dog hair.
Anti Stain
This program ensures stain removal at low temperatures, preserving
fabrics and colours. It is suitable to heavily-soiled garments with resistant
colours. When running the program, do not mix garments of dierent
colours. We recommend the use of powder detergent.
Steam Refresh
The garments will be damp once the cycle is completed, so we recommend
hanging them to dry (2 kg, roughly 3 items). This programme refreshes
garments by removing bad odours and relaxing the bres and it is meant
for dry, unsoiled items. Insert dry items only (that are not dirty) and select
programme “Steam Refresh”. The “Steam Refresh” programme makes
ironing easier.
! Do not add softeners or detergents.
! Not recommended for wool or silk garments.
Spin & Drain
Spins the load then empties the water. For resilient garments. If you
exclude the spin cycle, the machine will drain only.
Rinse & Spin
Rinses and then spins. For resilient garments.
Wash 20°C
For washing lightly soiled cotton garments, at a temperature of 20 °C.
Eco 40-60
For washing normally soiled cotton garments declared to be washable at 40 °C
or 60 °C, together in the same cycle. This is the standard cotton programme
and the most ecient in terms of water and energy consumption.
! The cycle runs only at 40°C as per regulation.
Intense 60-90°C
For heavily soiled whites and resistant colours.
Rapid Wash
For washing lightly soiled garments in a short time. Not suitable for wool,
silk and garments to be washed by hand.
Wash & Dry Rapid
This cycle is to wash and dry without interruption small garments or
T-shirts in dierent fabrics and colours up to 1kg in 45’. To achieve
optimum results, use liquid detergent.
DISPLAY
The display is useful when programming the washer-dryer and provides
plenty of information.
Section A displays the duration of the various available wash cycles and,
once the cycle starts, the time remaining to the latter’s end (the display will
show the maximum duration of the selected cycle which may decrease
after a few minutes, as the actual duration varies in relation to the laundry
load and the chosen settings); if the Delay option was set, the display will
show the time remaining to the start of the selected wash cycle.
Moreover, pressing the relative button allows for visualising the maximum
values for the temperature, spin speed or type of drying relative to the
selected programme or the most recently selected ones, if compatible
with the selected programme.
The “washing phases” relative to the selected cycle and the “washing
phase” of the running cycle appear in section B:
Main Wash
Rinse
Spin/Drain
Drying
Section C displays – starting from the left – the icons corresponding to
“temperature”, “spin” and “drying”.
The “temperature” bars indicate the maximum temperature level
that can be selected for the chosen cycle.
The “spin” bars indicate the maximum spin speed that can be
selected for the chosen cycle.
The symbol lights up while the drying settings are being adjusted.
LOCKED DOOR INDICATOR
When lit, the symbol indicates that the door is locked. To prevent any
damage, wait until the symbol turns o before attempting to open the door.
To open the door while a cycle is in progress, press the START/PAUSE
button ; if the symbol is o, the door can be opened.
FIRSTTIME USE
Once the appliance has been installed, and before it is used for the rst
time, run a wash cycle with detergent and no laundry, by setting the
“Auto-Clean” cycle.
DAILY USE
Prepare the laundry by following the suggestions appearing under the
“TIPS AND SUGGESTIONS” section.
- Press the ON/OFF button ; the indicator light relative to START/PAUSE
will ash slowly.
- Open the door. Load the laundry while making sure not to exceed the
maximum load quantity indicated in the wash cycle table.
- Pull out the detergent dispenser drawer and pour the detergent into the
relevant compartments, as described in the “DETERGENT DISPENSER
DRAWER” section.
- Close the door.
- The machine automatically displays the maximum temperature and spin
speed values for the selected cycle, or the most recently used settings if
they are compatible with the selected cycle. Pressing the button
gradually reduces the temperature down to the cold wash “OFF” setting.
Pressing the button gradually reduces the spin speed until it is
completely excluded (“OFF” setting). Pressing the buttons further restores
the maximum allowed values for the selected cycle.
- Select the desired wash cycle.
- Select the desired options.
STARTING CYCLE
Press the START/PAUSE button.
The machine will lock the door ( symbol on) and the drum will start to
rotate; the door will be unlocked ( symbol o) and then locked again
( symbol on) as preparation phase of each washing cycle. The
“Clicking” noise is part of the door locking mechanism. Water will enter
the drum and start the washing phase once the door is locked.
PAUSING A CYCLE
To pause the wash cycle, press the START/PAUSE button again; the
indicator light will ash. To start the wash cycle from the point at which it
was interrupted, press the START/PAUSE button again.
OPENING THE DOOR, IF NECESSARY
Once a cycle starts, the symbol turns on to signal that the door cannot
be opened. While a wash cycle is running, the door remains locked. To
open the door while a cycle is under way, for example, to add or remove
garments, press the START/PAUSE button to pause the cycle; the
indicator light will ash. If the symbol is not lit, the door may be
opened. Press the START/PAUSE button again to continue the cycle.
CHANGING A RUNNING WASH CYCLE
To change a wash cycle while it is in progress, pause the washer-dryer using
the START/PAUSE button (the relative indicator light will ash), then
select the desired cycle and press the START/PAUSE button again.
! To cancel a cycle that has already begun, press and hold the ON/OFF
button. The cycle will be stopped and the machine will switch o.
AT THE END OF THE WASH CYCLE
This will be indicated by the word “END” on the display; when the
symbol switches o, the door may be opened. Open the door and switch
o the machine. If you do not press ON/OFF button, the washing
machine will switch o automatically after about a 10 minutes. Close the
water tap and unload the washing machine. Leave the door ajar to allow
the drum to dry.
B
C
A
