1 2 3 4 5 6
Display panel/buttonsProgramme selector/Stop
Empty the condensate container
Empty the container after each drying cycle.
1. Remove the container, holding it level.
2. Pour out the condensate.
3. Push the container back in until it clicks
into place.
If s(condensate container) flashes in the
display panel aWhat to do if..., page 11.
Clean fluff filter
Do not operate the dryer without a fluff filter or with
a defective fluff filter. A clean fluff filter minimises
energy consumption.
Clean the fluff filter after each drying cycle.
1. Open the door. Remove any fluff from
the door/around the door and pull out
the fluff filter.
2. Remove the fluff from the shaft of the
fluff filter.
3. Open the fluff filter and remove the fluff
(sweep your hand over the fluff filter). If
the fluff filter is very dirty or blocked,
rinse with warm water and dry
thoroughly.
4. Close and reinsert the fluff filter.
7
6
Programmes/fabrics
Detailed overview of the programmes and fabrics
aProgramme overview, page 7.
Observe the care instructions on the care label.
algodón/algodão
(cottons)
Hard-wearing fabrics.
sintéticos
(synthetics)
Fabrics made from synthetic or
blended fabrics.
Dryness levels to select with the cottons and synthetics
programmes:
seco +
(cupboard dry +)
Thick and multi-layered fabrics.
seco armario
(cupboard dry)
Single-layered laundry.
seco
(iron dry)
Laundry suitable for ironing after
drying.
microfibras
(outdoor)
Functional clothing made of
microfibre.
antialergias
(anti-allergy)
Cotton fabrics for drying in higher
temperatures.
mix A mixed load of fabrics made of
cotton and synthetic fabrics.
I (warm)
All types of fabric; time
programme.
:c(cold)
15min camisas
(shirts 15 min.)
Cotton or linen fabrics that are still
damp and easy-care fabrics.
40min super rápido
(super 40’)
Synthetics, cotton or blended fabrics.
acab. lana/lãs
(woollen finish)
Woollen fabrics that are suitable for
use in washers.
lenceria/lingerie
(lingerie)
Lingerie made of synthetic fibres,
cotton or blended fabric.
Your new dryer
Congratulations - You have chosen a modern, high-quality Balay
domestic appliance.
The condensation dryer is distinguished by its economical energy
consumption.
Every dryer which leaves our factory is carefully checked to ensure
that it functions correctly and is in perfect condition.
Should you have any questions, our after-sales service
will be pleased to help.
Disposal in an environmentally-responsible manner
This appliance is labelled in accordance with European Directive
2012/19/EU concerning used electrical and electronic appliances
(waste electrical and electronic equipment - WEEE). The guideline
determines the framework for the return and recycling of used
appliances as applicable throughout the EU
For further information about our products, accessories,
spare parts and services, please visit: www.balay.es
Intended use
Preparation
Set and adjust the
programme individually
1
2
Drying
ʋexclusively for domestic use,
ʋonly for drying fabrics which have been washed using
water.
Keep children younger than 3 years old away from
the dryer.
Do not let children make the cleaning and
maintenance work on the dryer without supervision.
Do not leave children unsupervised near the dryer.
Keep pets away from the dryer.
The dryer can be operated by children 8 years old
and older, by persons with reduced physical,
sensory or mental abilities and by persons with
insufficient experience or knowledge if they are
supervised or have been instructed in its use by
a responsible adult.
This appliance is intended for use up to a
maximum height of 4000 metres above sea level.
Drying
Display panel and settings
ʑ
Display panel (status indicators)
r
(fluff filter/
heat exchanger)
Clean the fluff filter apage 4/11
or clean the heat exchanger apage 8.
s÷
(condensate
container)
Empty the condensate container apage 4/11.
«]+
-Æ-§Ê
(programme
sequence)
These indicators show the programme progress in the next steps
of the drying cycle:
« Drying;
] Iron Dry;
+Cupboard Dry;
- Æ- Programme pause aif required;
§ÊProgramme end.
#
(childproof lock)
You can lock the dryer to prevent the functions you have set from being
changed inadvertently. To activate/deactivate #(childproof lock) start
the programme and then press and hold the Ø inicio/pausa (start/pause)
button for 5 seconds until a long acoustic signal is heard. The option
activated/deactivated a#(childproof lock) indicator light on/off.
[h:min]
(remaining time)
When a programme is selected, the anticipated drying time (remaining time)
for the recommended load is displayed. While drying, the moisture sensors
detect the actual load and correct the programme length. This is shown by
jumps in the remaining time in the display panel.
ʑ
Settings (indicators lights and buttons)
Selected option activated/deactivated aindicator light on/off.
See the separate Energy-saving mode instructions.
(drying time)
Drying time, available only for timed programmes, can be selected
from min. 0:20 h to max. 3:00 h, in 10-minute steps.
~
auto ajuste
(fine adjust)
The dryness levels (e.g. Cupboard Dry) can be increased in three levels.
The laundry is made drier. Default = 0. Selectable values: 0, 1, 2, 3. After
setting the level of the fine adjustment for a programme, it is also retained
for other programmes, until ~auto ajuste (fine adjust) is changed again.
³¤- ¤
diferida
(finished in)
The time when the programme has to end can be set by selecting
the diferida (finished in) time. The diferida (finished in) time can be selected
in one-hour steps, up to a maximum of 24 hours. Select the diferida (finished
in)button repeatedly until the required number of hours is displayed. Then
press the Ø inicio/pausa (start/pause) button to activate the diferida
(finished in) option. The programme ends after the selected number of
hours.
Several minutes after activating diferida (finished in) option the display
switches off to save energy. To switch it on select any button, close/open
the door or turn the programme selector.
delicado
(gentle dry)
Reduced temperature for delicate fabrics, e.g. polyacrylic, polyamide
or elastane, with a longer drying time.
é
menos
(wrinkle guard+)
After the programme finishes, the drum moves at regular intervals to prevent
creases. Laundry remains loose and fluffy.
The standard setting for each programme is 60 min. Automatic anti-crease
function can be extended by up to 60 min.
êü
senãl/sinal (signal)
For switching the buzzer on and off. êüsenãl/sinal (signal) indicates program
end if it is activated. Other sounds are not influenced by this option.
Close the door
3
Contents Page
ʋPreparation . . . . . . . . . . . . . . . . . . . . . . 2
ʋControl panel . . . . . . . . . . . . . . . . . . . . . 2
ʋDrying . . . . . . . . . . . . . . . . . . . . . . . . .3/4
ʋDisplay panel and settings . . . . . . . . . . . 5
ʋNotes on laundry . . . . . . . . . . . . . . . . . . 6
ʋOverview of programmes . . . . . . . . . . . . 7
ʋCare and cleaning . . . . . . . . . . . . . . . . . 8
ʋInstallation . . . . . . . . . . . . . . . . . . . . . . . 9
ʋFrost protection/Transport . . . . . . . . . . . 9
ʋOptional accessories . . . . . . . . . . . . . . 10
ʋTechnical data . . . . . . . . . . . . . . . . . . . 10
ʋConsumption rates . . . . . . . . . . . . . . . . 10
ʋAfter-sales service . . . . . . . . . . . . . . . 11
ʋWhat to do if ... . . . . . . . . . . . . . . . . 11/12
ʋSafety instructions. . . . . . . . . . . . . . . . . 13
Never start the dryer if it is damaged!
Inform your after-sales service!
Inspect the dryer
Sort the laundry
Remove all items from pockets,
especially cigarette lighters.
The drum must be empty prior to loading.
See programme overview on page 7.
See also separate instructions for “Woollens basket”
(depending on model).
Make sure your hands are dry.
Only grasp the plug by the plug
body.
Connect the
mains plug
End of the programme...
Interrupt the programme
1. Open the door or press the Øinicio/pausa
(start/pause)übutton; the drying cycle is interrupted.
2. Add or remove laundry and close the door.
3. If required, select a new programme and additional
functions. Select the Ø inicio/pausa (start/pause)
button. The remaining time is updated after a few
minutes.
The drum and door may be hot!
Notes on laundry ...
Labelling of fabrics
Follow the manufacturer's care instructions.
hcSuitable for tumble drying.
(cDry at normal temperature.
'cDry at low temperature a in addition, select delicado (gentle dry).
)cDo not tumble dry.
Do not tumble dry the following fabrics:
– Non-breathable fabrics (e.g. rubber-coated).
– Delicate materials (silk, curtains made from synthetic material) a these may crease.
– Oil-stained laundry.
Drying tips
– To ensure a consistent drying result, sort the laundry by fabric type and drying programme.
– Always dry very small fabrics (e.g. baby socks) together with large items of laundry
(e.g. towels).
– Close zips, hooks and eyelets, and button up covers. Tie cloth belts, apron strings, etc.
together or use a laundry bag.
– Do not over-dry easy-care laundry a risk of creasing. Allow laundry to finish drying
in the air.
– Do not dry woollens in the dryer. They may, however, be refreshed in the dryer
apage 7, acab. lana/lãs (woollen finish) programme (depending on model).
– Do not iron laundry immediately after drying; fold items up and leave for a while
a residual moisture will then be distributed evenly.
– Knitted fabrics (e.g. T-shirts, jerseys) often shrink slightly the first time they are tumble-dried.
a Do not use the seco + (cupboard dry +) programme.
– Starched laundry is not always suitable for dryers a starch leaves behind a coating that
reduces the drying effect.
– When washing laundry that is to be tumble dried afterwards, use the correct amount of
fabric softener as specified in the manufacturer's instructions.
– For pre-dried, multi-layered fabrics or small, individual items of laundry, use the timed
programme. Also suitable for subsequent drying.
Environmental protection/energy-saving tips
– Before drying, spin the laundry in the washing machine a higher spin speeds minimise
the drying time and reduce energy consumption.
– Use the maximum recommended capacity, but do not exceed it a Programme overview,
page 7.
– Make sure the room is well ventilated during drying.
– Clean the fluff filter after every drying cycle a Clean the fluff filter, page 4/11.
– Do not cover or seal the air inlet on the dryer.
Remove the laundry and switch off
the dryer
5
4
Control panel
Fluff filter
Select
Øinicio/pausa
(start/pause)
Door
Installation a page 9.
Condensate
container
Air inlet
Programme selector for setting
the programme and switching the appliance
on/off. Can be turned in both directions.
Maintenance flap
`
Programme sequence «]+(drying time) Setting the drying time available only for timed programmes.
- Æ-§Ê~auto ajuste (fine adjust) Fine adjustment of dryness level.
Childproof lock #³¤- ¤diferida (finished in) Setting the programme end.
Condensate container sdelicado (gentle dry) Low-heat drying reduced temperature.
Fluff filter/Heat exchanger rémenos (wrinkle guard+) Extends the anti-crease function.
êsenãl/sinal (signal) Buzzer on/off.
Øinicio/pausa (start/pause) Starts, pauses and continues the programme;
activates or deactivates #(childproof lock).
Further information
can be found
on Page 5
7
Programme overview see also page 6.
Sort the laundry according to type of textile and fabric. Fabrics must be suitable for tumble drying.
After drying, laundry is to be ...
cironed lightly ironed @cnot ironed cmangled
PROGRAMMES TEXTILE TYPE AND INFORMATION
*algodón/algodão (cottons) max. 8 kg Hard-wearing fabrics, boil-proof fabrics made of cotton or linen.
*sintéticos (synthetics)
max. 3.5 kg Non-iron laundry made of synthetic fibres and mixed fabric, easy-care cotton.
seco (iron dry) c÷@c
The condition of the laundry means it is suitable for ironing (iron clothes in order to avoid creases).
seco armario
(cupboard dry)
@
Single-layered laundry.
seco + (cupboard dry +) @
Laundry with thick, multi-layered parts.
microfibras (outdoor)
max. 1.5 kg
Fabrics with membrane coating, water-repellent fabrics, functional clothing, fleece fabrics (dry jackets/trousers with removable
internal lining separately).
antialergias (anti-allergy)
max. 6 kg Cotton fabrics for drying in higher temperatures to keep them more hygienic .
mix
max. 3 kg Mixed items of laundry made of cotton and synthetics (Mix).
I (warm)
max. 3 kg
Suitable for pre-dried or slightly damp laundry and for drying off multi-layered, thick laundry.
Only dry wool, sports shoes and soft toys with the basket for woollens aOptional Accessories, page 10.
In the time programme, the laundry's residual moisture is not automatically detected. If the laundry is still too damp after
the drying programme, repeat the programme and, if required, extend the programme length.
:c(cold)
max. 3 kg All types of fabrics. For freshening up or airing of items of laundry that have been worn for a short period of time.
15min camisas
(shirts 15 min.)
max. 1 kg
For optimal drying result dry a maximum of 5 business shirts together. After drying, iron clothes or hang them out and leave for
a while. The remaining moisture will be distributed evenly.
40min super rápido
(super 40’)
max. 2 kg
Laundry made of synthetic fibres, cotton or blended fabrics (for example) that needs to be dried quickly. The values may differ
from the those specified depending on the type of fabric, mixture of laundry to be dried, residual moisture in the fabric and loading
capacity.
acab. lana/lãs (woollen finish)
max. 3 kg
Woollen fabrics suitable for washing machines. Fabrics become fluffier but not dry. Remove fabrics once the programme has
ended and allow to dry.
lenceria/lingerie (lingerie)
max. 1 kg Lingerie made of synthetic fibres, cotton or blended fabric.
*Dryness levels can be selected individually a cupboard dry +, cupboard dry and iron dry (depending on the model).
Degree of dryness can be finely adjusted; multi-layered textiles require a longer drying time than single-layered items of clothing. Recommendation: Dry separately.
9508 / 9001064439
*1064439*
BSH Electrodomésticos España S.A.
Ronda del Canal Imperial de Aragón 18-20
(Parque empresarial Pla-Za)
50197 Zaragoza, ESPAÑA
3SC885B
Loading…
Rating
Let us know what you think about the Balay 3SC885B Dryer by leaving a product rating. Want to share your experiences with this product or ask a question? Please leave a comment at the bottom of the page.More about this manual
We understand that it’s nice to have a paper manual for your Balay 3SC885B Dryer. You can always download the manual from our website and print it yourself. If you would like to have an original manual, we recommend you contact Balay. They might be able to provide an original manual. Are you looking for the manual of your Balay 3SC885B Dryer in a different language? Choose your preferred language on our homepage and search for the model number to see if we have it available.
Specifications
| Brand | Balay |
| Model | 3SC885B |
| Category | Dryers |
| File type | |
| File size | 3.55 MB |
All manuals for Balay Dryers
More manuals of Dryers
Frequently Asked Questions about Balay 3SC885B Dryer
Our support team searches for useful product information and answers to frequently asked questions. If you find an inaccuracy in our frequently asked questions, please let us know by using our contact form.
Why is de drum of my dryer larger than that of my washing machine, even though they have the same capacity? Verified
To properly dry laundry, a dryer needs to have air. This needs space and that's why the drum needs to be larger.
This was helpful (2994) Read moreWhat is the difference between a condenser dryer and a vented dryer? Verified
In a condenser dryer the condensed water vapour is drained and collected in an internal reservoir. In a vented dryer the hot, moist air is drained through a hose, for example out of a window. A vented dryer is cheaper to use than a condenser dryer
This was helpful (857) Read moreCan I stack my dryer and washing machine? Verified
In general it is possible to directly stack a dryer and washing machine directly on top of each other. This only works with front loading models. However, it is advisable to use a fitting accessory to do so. This will prevent the machines from vibrating and falling off and also prevents damage to the bottom machine.
This was helpful (689) Read moreCan I connect a dryer to an extension cord? Verified
Appliances that require large amounts of power, like a dryer, can not be connected to all extension cords. See what the power usage of the dryer is, which is indicated in Watt, and check if the extension cord can handle this. There are extension cords with thicker cables that are made to handle larger appliances.
This was helpful (534) Read moreWhat is the difference in usage between a washer-dryer and a separate washing machine and dryer? Verified
The biggest advantage of a washer-dryer is that it takes less space. However, a separate dryer will be able to dry more than a washer-dryer. A washer-dryer also uses relatively more energy and requires more time.
This was helpful (523) Read more
Join the conversation about this product
Here you can share what you think about the Balay 3SC885B Dryer. If you have a question, first carefully read the manual. Requesting a manual can be done by using our contact form.
