Manual

Electrical connection

! Ovens equipped with a three-pole power supply

cable are designed to operate with alternating

current at the voltage and frequency indicated on

the data plate located on the appliance (see below).

Fitting the power supply cable

1. Open the terminal

board by inserting a

screwdriver into the

side tabs of the cover.

Use the screwdriver as

a lever by pushing it

down to open the cover

(see diagram).

2. Install the power

supply cable by

loosening the cable

clamp screw and the

three wire contact

screws L-N-

Connect the wires to the

corresponding

terminals: the Blue wire

to the terminal marked

(N), the Brown wire to

the terminal marked (L)

and the Yellow/Green wire to the terminal marked

(see diagram).

3. Secure the cable by fastening the clamp screw.

4. Close the cover of the terminal board.

Connecting the electricity supply cable to the

mains

Install a standardised plug corresponding to the

load indicated on the data plate (see table).

The appliance must be directly connected to the

mains using an omnipolar switch with a minimum

contact opening of 3 mm installed between the

appliance and the mains. The switch must be

suitable for the charge indicated and must comply

with current electrical regulations (the earthing wire

must not be interrupted by the switch). The supply

cable must be positioned so that it does not come

into contact with temperatures higher than 50°C at

any point (the back panel of the oven, for example).

! The installer must ensure that the correct electrical

connection has been performed and that it is fully

compliant with safety regulations.

Before connecting the appliance to the power

supply, make sure that:

• the appliance is earthed and the plug is compliant

with the law;

• the socket can withstand the maximum power of

the appliance, which is indicated on the data

plate (see below);

• the voltage is in the range between the values

indicated on the data plate (see below);

• the socket is compatible with the plug of the

appliance. If the socket is incompatible with the

plug, ask an authorised technician to replace it.

Do not use extension cords or multiple sockets.

! Once the appliance has been installed, the power

supply cable and the electrical socket must be

easily accessible.

! The cable must not be bent or compressed.

! The cable must be checked regularly and replaced

by authorised technicians only (see Assistance).

The manufacturer declines any liability shouldThe manufacturer declines any liability should

The manufacturer declines any liability should

these safety measures not be observed.these safety measures not be observed.

these safety measures not be observed.

* Without removable guide rails

APPLIANCE SPECIFICATIONS

Dimensions

width 43.5 cm

height 32 cm

depth 41.5 cm

Volume

58 l

Electrical

connections

voltage: 220 - 240 V~ 50/60 Hz

(see data plate)

maximum power absorbed

2800 W

ENERGY

LABEL*

Directive 2002/40/EC on the label

of electric ovens. Standard EN 50304

Declared energy consumption

for Forced convection Class –

heating mode:

ECO.

Download manual in English (PDF, 13.88 MB)
