The appliance should be connected to the main

gas supply or to gas cylinder in compliance with

the current National regulations. Before carry out

the connection, make sure that the appliance is

compatible with the gas supply you wish to use. If

this is not the case, follow the instructions indicated

in the paragraph “Adapting to dierent types of

gas”.

After connection to the gas supply, check for

leaks with soapy water. Light up the burners and

turn the knobs from max position 1* to minimum

position 2* to check ame stability.

ADAPTING TO DIFFERENT TYPES OF GAS

In order to adapt the appliance to a type of gas

other than the type for which it was manufactured

(indicated on the rating label), follow the dedicated

steps provided after installation drawings.

ELECTRICAL WARNINGS

IMPORTANT: The data relevant to the voltage an

power absorptions are indicated on the rating

plate.

The power cable must be long enough to

connect the appliance, once tted in its housing, to

the main power supply. Do not pull the power

supply cable.

It must be possible to disconnect the appliance

from the power supply by unplugging it if plug is

accessible, or by a multi-pole switch installed

upstream of the socket in accordance with the

wiring rules and the appliance must be earthed in

conformity with national electrical safety standards.

Do not use extension leads, multiple sockets or

adapters. The electrical components must not be

accessible to the user after installation. Do not use

the appliance when you are wet or barefoot. Do

not operate this appliance if it has a damaged

power cable or plug, if it is not working properly, or

if it has been damaged or dropped.

If the supply cord is damaged, it must be

replaced with an identical one by the manufacturer,

its service agent or similarly qualied persons in

order to avoid a hazard - risk of electrical shock.

CLEANING AND MAINTENANCE

WARNING: Ensure that the appliance is switched

o and disconnected from the power supply

before performing any maintenance operation;

never use steam cleaning equipment - risk of

electric shock.

Do not use abrasive or corrosive products,

chlorine-based cleaners or pan scourers.

DISPOSAL OF PACKAGING MATERIALS

The packaging material is 100% recyclable and is marked with the

recycle symbol .

The various parts of the packaging must therefore be disposed of

responsibly and in full compliance with local authority regulations

governing waste disposal.

DISPOSAL OF HOUSEHOLD APPLIANCES

This appliance is manufactured with recyclable or reusable materials.

Dispose of it in accordance with local waste disposal regulations.

For further information on the treatment, recovery and recycling of

household electrical appliances, contact your local authority, the

collection service for household waste or the store where you purchased

the appliance. This appliance is marked in compliance with European

Directive 2012/19/EU, Waste Electrical and Electronic Equipment (WEEE).

By ensuring this product is disposed of correctly, you will help prevent

negative consequences for the environment and human health.

The symbol on the product or on the accompanying documentation

indicates that it should not be treated as domestic waste but must be

taken to an appropriate collection center for the recycling of electrical

and electronic equipment.

ENERGY SAVING TIPS

Use pots and pans with bottom width equal to that of the cooking zone.

Only use at-bottomed pots and pans.

When possible, keep pot lids on during cooking.

Use a pressure cooker to save even more energy and time.

Place the pot in the middle of the cooking zone marked on the hob.

DECLARATION OF CONFORMITY

This appliance meets the Ecodesign requirements set out in European

Regulation n.66/2014, in conformity to the European standard EN 30-2-1.

INJECTORS TABLE CATEGORY I2H

Type of gas

used

Type of burner Injector

marking

Rated thermal

ow rate

kW

Rated

consumption

Reduced heat

capacity

kW

Gas pressure

mbar

min. rat. max.

NATURAL GAS

(Methane) G20

Rapid

Semi-rapid

Auxiliary

125

100

72

3,00

1,90

1,00

286 l/h

181 l/h

95 l/h

1,00

0,80

0,50

17 20 25

Type of gas used Model conguration

5 BURNERS

Rated thermal

owrate (kW)

Total rated

consumption

Air required (m) for

burning 1m of gas

G20 20 mbar 1 R - 2 SR - 2 AUX 8,80 838 l/h 9,52

ELECTRIC SUPPLY: 220-240 V ~ 50-60 Hz - 0,6W
