• To make the most of your new appliances read the

users instructions carefully and keep them on

hand for consultation in the future.

Cooktop

• The cooktop must be set into a worktop

between 20 mm and 50 mm thick.

• Insert a separator panel at a minimum distance

of 90mm from the bottom of the hob so that it

is inaccessible to the user.

• If the cooktop is to be installed next to a

column unit, leave a distance of at least 100

mm from the edge of the cooktop to the side of

the column unit.

• Cut an opening in the worktop of the dimensions

shown in the Product Description Sheet supplied

separately.

• If not already present, fit the supplied seal to the

cooktop flange after cleaning the contact area as

shown in the figure.

N.B.: Remove the protective film before installing the

cooktop.

• If the worktop is made of wood, use the supplied

spring clips and screws.

1. Position the 4 clips (D) as shown and at the

specified dimensions.

2. Secure the clips using screws (E).

3. Fit the cooktop into the worktop.

• If the worktop is made of marble, plastic,

ceramics, natural stone, etc., the cooktop must

be secured with brackets (F) code 4819 404 78697

(to be requested from After-Sales Service).

1. Fit the cooktop into the worktop.

2. Position the 4 brackets (F) as shown in the figure,

in accordance with the thickness of the worktop.

3. Fix the 4 screws (G) in holes (H).

BEFORE USING THE GLASS CERAMIC HOB

INSTALLATION

1gb58913.fm Page 10 Friday, March 5, 2004 12:29 PM
