IMPORTANT SAFETY INSTRUCTIONS

This manual explains the proper use of your new

Westinghouse canopy rangehood. Please read this manual

carefully before using the product. This manual should be

kept in a safe place for handy reference.

This canopy rangehood is a domestic appliance which has

been manufactured and tested to comply with Australian

and New Zealand Standard AS/NZS 60335.2.31.

Meanings of symbols used in this manual are shown below:

CAUTION

This symbol indicates the possibility of injury or damage to property

This symbol indicates never to do this

This symbol indicates always do this

TIPS & INFORMATION

This symbol indicates tips and information about use of the appliance

ENVIRONMENTAL TIPS

This symbol indicates tips and information about economical and

ecological use of the appliance

CAUTION

Read the following carefully to avoid an electric shock or re.

GENERAL WARNINGS

The appliance must be plugged into its own

dedicated 220-240V, 50Hz AC electrical outlet.

This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision

or instruction concerning the use of the appliance by

a person responsible for their safety.

Ensure the canopy rangehood is switched off before

carrying out maintenance, to avoid any possibility of

electric shock.

Never carry out flambé cooking under the canopy

rangehood.

This canopy rangehood is not recommended for

barbecues and cannot be installed for external use.

Grease filters must be removed every four weeks

(maximum) for cleaning to reduce the risk of fire.

The exhaust from the canopy rangehood must not

be discharged into any heating flue, which may

carry combustion products from other sources. (Fig1)

Exhaust air must not be discharged into a wall cavity,

unless the cavity is designed for the purpose.

There must be adequate ventilation of the room when

the canopy rangehood is used at the same time as

appliances burning gas or other fuels.

Always cover lit gas burners with pots or pans when

canopy rangehood is in use.

Always switch off gas burners before you remove pots

or pans.

Do not leave lit gas burners exposed due to the risk

of fire. (Fig 2)

ELECTRICAL CONNECTION

Check that the mains voltage matches with the voltage on

the data plate inside the canopy rangehood. Check that the

installation complies with standards of local building, gas

and electrical authorities. Before connecting to the mains

supply ensure that the mains voltage corresponds to the

voltage on the rating plate inside the cooker hood.

If the supply cord is damaged, it must be replaced by

the manufacturer or its service agent or similarly qualified

person in order to avoid a hazard.

SAFETY WARNINGS – FOR THE INSTALLER

When installing the cooker hood, make sure you adhere to

the minimum and maximum distances from the cooker hood

base to the hob surface (refer to page 7).

Exhaust flue installation: The following rules must be

strictly followed to obtain optimal air extraction.

• Keep exhaust flue short and straight

• Do not reduce the size or restrict exhaust flue.

• Keep bends in the exhaust flue to a minimum.

• When using flexible flue always install duct with helix

pulled taut to minimise pressure loss.

• Failure to observe these basic instructions will drastically

reduce the performance and increase the noise levels of

the cooker hood.

Exhaust air must not be discharged into a wall cavity, unless

the cavity is designed for that purpose.

The exhaust from the cooker hood must not be discharged

into any heating flue, which may carry combustion products

from other sources.

NOTE: Some installations may require the telescopic

exhaust cover to be cut to length. Cut with sharp tin snips

or a fine-tooth hack saw blade, taking care not to distort or

dent the exhaust cover.

Fig. 1

Fig. 2

3
