Manual

The Painting People

™

English

TROUBLESHOOTING

PROBLEM

There is paint leakage on the

roller arm assembly

Plunger is difficult to pull/push

The fill tube will not fill with paint

or paint leaks from fill valve

CAUSE

The seal on the arm is backwards

The seal and cap were not properly cleaned

The O-ring and the connecting area were not

cleaned properly

Paint residue on connecting areas

The O-rings are damaged or missing

The roller cover is worn or damaged

The core or cap is worn or damaged

The bearing areas are worn

O-rings are not lubricated

Paint residue on fill valve components

SOLUTION

Turn the seal around

Clean and properly lubricate

Clean connecting areas

Replace the O-rings*

Replace the roller cover*

Replace the core or cap*

Call Customer Service

Lubricate the O-rings on the plunger

A) Insert fill tube firmly into fill valve and

twist fill tube several times to break up

paint residue

B) If the problem persists, refer to the

steps below to clean the fill valve

components

Have you tried the recommendations above and are still having problems? In the United States, to speak to a

customer service representative, call our Customer Service at 1-763-519-3555 Monday through Friday between 8:00

AM and 4:30 PM Central time. An automated Self-Help option is also available at 1-800-328-8251, seven days a week,

twenty-four hours a day.

PRODUCT REGISTRATION CARD

Send in your product registration card or register online at www.wagnerspraytech.com. Proper registration will serve as proof of

purchase in the event your original receipt becomes misplaced or lost. Returning this card will expedite the processing of your

warranty. Be sure you write your unit’s date code on the card before sending it. The date code is located on the Power Trigger

your unit (for example, T087A). The additional information will also help us to develop new products that best meet your needs and

desires. If you have any questions or concerns regarding your registration card, please call our registration card center at 1-303-394-

9077.

* Replacement parts available by calling customer service

Retaining disk

Locking cap

Duckbill valve

Valve housing

Connecting

area

1. Unscrew the locking cap on the valve housing by turning it

counterclockwise.

2. Remove the retaining disk and the duckbill from the valve

housing.

3. Clean these parts thoroughly using the appropriate cleaning

solution.

4. Replace the duckbill valve and retainer disk.

5. Screw the locking cap on the valve housing by turning it

clockwise.
