Manual Vornado Ultrasonic Humidifier

Manual

8 English English

9

Filling Water Tank

Before initial use, you must soak the Mineral Cartridge in water for

24 hours. You may use a separate container or Water Tank to do so.

If Tank is used, empty water and refill with fresh water prior to use.

Note: the unit may take several minutes to create mist with the

initial use of a new Mineral Cartridge.

This Humidifier has a 2 gallon capacity and 3.5 gallon output in 24

hours (if set to High output, Continuous Humidity setting).

To fill Water Tank:

Unplug Humidifier. Place on firm and level surface, such as the

floor.

Note: Spills can occur during cleaning, moving, or refilling

Water Tank, so be careful to avoid spills when doing these

activities. Do not touch the water inside the Base, as the water

temperature can reach 92 degrees F.

Remove Water Tank by grasping recessed handle on back (A).

Lift and pull outward.

Turn Water Tank upside down.

Remove Cap (B). Empty any remaining water inside Water Tank.

Rinse, wipe clean and dry with clean cloth or paper towel.

Place Water Tank in sink with opening at the top.

Fill Water Tank with cool tap water (C).

Ensure Gasket is properly positioned and secure Cap.

Lower Water Tank into Base, positioning Fill Port over raised

bump in Base. Once in nested position, the water outlet valve

inside Cap will open, releasing water into Base.

Getting Started

Read and understand this owners guide before operating this

product. Position unit to not blow directly on objects or plants. Plug

unit into a 110-120 volt AC outlet.

Power Button (A) - turns the unit On or Off. LCD Screen will

illuminate when powered On. Unit will default to Continuous Misting,

Cool Mist, and High Output. Adjust settings for desired operation.

Mist Condition (B) - select Cool or Warm Mist Output. The

temperature of the mist on the Warm Mist setting is approximately 94

-98 degrees at the Outlet. However, the mist will feel much cooler to

the touch, because it is immediately entrained in the Vortex beam of

air generated by the fan.

Humidity (C) - sets desired humidity level. Press Humidity Button

until desired humidification level is illuminated. The unit will operate

until the desired humidity level is reached, at this point, the mist

output will turn Off. The humidity level indicator light will remain on. If

the mist output does not turn on, the set humidity level may be lower

than the room humidity level. Increase the humidity set point until the

mist turns on. This is an indication of the level of humidity already

in the room. If moisture forms on walls or windows, lower humidity

settings or turn Off Humidifier.

How to Use Humidifier Controls

AUTO 1 Continuous misting, cool mist, low fan speed.

AUTO 2 Continuous misting, warm mist, high fan speed

40% - 60% Humidity level. Manually set Mist Condition and Fan Speed.

Fan Speed (D) - select desired Fan Speed - High or Low .

High - operation for fast humidification for larger rooms. High speed

operation will evaporate 3.5 gallons of water (+/- 10%) in 24 hours of

continuous operation. (This assumes room conditions of 70º F and 30%

relative humidity.)

Low - operation for quiet, nighttime use or smaller rooms. On Low

operation, your Humidifier may run without refilling for extended periods.

Notifications

Refill Tank - Notifies you when the Water Tank needs to be refilled. Will

automatically turn off after it has been refilled.

Clean Unit - Displays after 400 hours of operation. It is recommended to

clean your Humidifier at this time (see CLEANING INSTRUCTIONS). To

reset notification, press and hold the Power Button for 3 seconds.

Replace the Mineral Cartridge - Displays after 800 hours of operation.

It is recommended to replace the Mineral Cartridge at this time

(see REPLACING MINERAL CARTRIDGE for instructions). To reset

notification, press and hold the Power Button for 3 seconds.

Note: The rate of water dispensing from Water Tank into Base is

controlled by the Mineral Cartridge. The unit may take several

minutes to fill the Base.

1.

2.

3.

4.

5.

6.

7.

8.

C

A

B

CA

B D
