Manual

Assembly & Set-Up

Thank you for purchasing this product. It was carefully engineered to

provide excellent performance when properly operated and maintained.

Please read this entire manual prior to operating the equipment. It instructs

you how to safely and easily set up, operate and maintain your machine.

Please be sure that you, and any other persons who will operate the

machine, carefully follow the recommended safety practices at all times.

Failure to do so could result in personal injury or property damage.

All information in this manual is relative to the most recent product

information available at the time of printing. Review this manual frequently

to familiarize yourself with the machine, its features and operation. Please

be aware that this Operator’s Manual may cover a range of product

specifications for various models. Characteristics and features discussed

and/or illustrated in this manual may not be applicable to all models. We

reserve the right to change product specifications, designs and equipment

without notice and without incurring obligation.

If applicable, the power testing information used to establish the power

rating of the engine equipped on this machine can be found at

www.opei.org or the engine manufacturer’s web site.

If you have any problems or questions concerning the machine, phone your

local authorized service dealer or contact us directly. We want to ensure

your complete satisfaction at all times.

Throughout this manual, all references to right and left side of the machine

are observed from the operating position.

The engine manufacturer is responsible for all engine-related issues with

regards to performance, power-rating, specifications, warranty and service.

Please refer to the engine manufacturer’s Owner’s/Operator’s Manual,

packed separately with your machine, for more information.

Thank You

Contents of Carton

• Lawn Mower (1) • Grass Catcher † (1) • Side Discharge Chute † (1)

• Cable Clips † (2) • Electric Start Push Key † (1) • Oil (1)

• Lawn Mower Operator’s Manual (1) • Engine Operator’s Manual (1) • Parts/Warranty Document (1)

• Fast Start Guide † (1) † If Equipped

NOTE: This Operator’s Manual covers several models. Features may vary by model. Not all features in this manual are applicable to all models and the

model depicted may differ from yours. Handle assembly is the same on all units, however, refer to Figure 3-1 in the Controls & Operation section to

determine the handle controls your model has and page 10 for instruction on how to use them.

NOTE: This unit is shipped without gasoline or

oil in the engine. Fill up with gasoline and oil

as instructed in the Engine Operator’s Manual

BEFORE operating your mower.

Handle Assembly

1. Remove any packing material which may

be between upper and lower handles

2. Remove wing knobs (a) and carriage

bolts (b) from handle as shown in Figure

2-1. Do not loosen or remove adjacent

hex head screws.

(a)

(b)

(a)

Figure 2-1

3. While stabilizing mower so it doesn’t

move, pivot upper handle up as shown

in Figure 2-2. Do not crimp cable while

lifting the handle up.

Figure 2-2

4. Remove the T-bolts (a) from the handle

brackets as shown in Figure 2-3.

(a)

Figure 2-3

5. Follow the proceeding steps to

complete handle assembly:

a. Pull upward on the handle until

holes in lower handle (shown in

Figure 2-3 deck cutaway) line up

with holes in handle bracket.

See Figure 2-4.

(a)

Figure 2-4

NOTE: When pulling upward on handle,

make sure to not pull handle all the way

out.

b. Insert the T-bolts (a) removed

in Step 4 through the handle

brackets and lower handle and

tighten securely to secure the

handle in place. See Figure 2-4.

c. Reattach wing knobs (a) and

carriage bolts (b) removed in

Step 2 into lower holes of handle

as shown in Figure 2-5.
