Manual

ENGLISH

7/8” Ballcock Thread

HAND TIGHTEN ONLY

Installation Procedures (continued)

5) Flush the water supply line for a few seconds

to remove any debris that may enter the

new ﬁll valve. (For new home constructions

and/or additions, ﬂush the water supply line

for more than a minute to help remove any

residual PVC adhesives, solder ﬂux, and/

or pipe sealants that were used for the new

plumbing.) Connect the water supply line to

the ﬁll valve threads as seen at the bottom

of toilet tank (see Illustration 7). Tighten this

connection ﬁnger tight.

CA UTION: Avoid using a wrench to tighten

the connection as you may damage the

plastic threads and/or cause the ﬁll valve

to rotate inside the tank.

NO TE: The water supply pressure should be

20 to 80 psi static.

6) No ballcock / ﬁll valve adjustments are

needed. The water will automatically stop at

proper level.

Flush the toilet several times. Check ﬂapper

valve for proper operation. Make sure that

chain is not tangled and that the ﬂapper arm

is in its proper position.

7) Install the toilet tank lid onto the toilet tank

top.

8) Install the toilet seat onto the toilet bowl

using the mounting hardware in the toilet

seat box. Place seat onto bowl and rotate the

hinge down. Position seat stoppers under

the seat hinge. Insert bolt into seat hinge

and through the toilet bowl. Install plastic nut

onto bolt from underneath. Tighten the bolt

securely. Install the seat bolt caps.

NO TE: Tighten the seat bolt until the hinge

is secure. The seat and lid will have slight

side to side movement, which is normal.

This freedom of movement allows the

seat to SoftClose® without binding.

Ill. 7

TOILET TANK FILL VALVE INSTRUCTIONS

Installation Procedure

Ill. 8

Seat

Hinge

Cap

Plastic

Bolt

Seat

Stopper

Bowl

Plastic Nut

1 - Cap

2 - Plastic Bolt

3 - Seat Hinge

4 - Seat Stopper

5 - Toilet Bowl

6 - Plastic Nut

MOUNTING HARDWARE

1) Shut off the water supply to the toilet.

2) Flush toilet and remove remaining water from tank with a sponge.

3) Remove the water supply connection at the ﬁll valve.

4) Remove old ﬁll valve and use damp sponge to clean hole in tank.
