٤
ﻞﻴﻐﺸﺘﻟا تﺎﻤﻴﻠﻌﺗ
.ﺮﺘﻣ ١ ﻦﻣ ﺮﺜﻛأ ﻞﻴﺻﻮﺘﻟا نﺎﻜﻣ ﻦﻋ ﺪﻌﺒﻳ ﻻ ﻰﺋﺎﺑﺮﻬﻛ رﺪﺼﻤﺑ دوﺰﻣ نﺎﺨﺴﻟا ﺐﻴﻛﺮﺘﻟ ﺐﺳﺎﻨﻤﻟا نﺎﻜﻤﻟا نﻮﻜﻳ نأ ﺐﺠﻳ •
.
٢
ﻢﻣ ١٫٥ * ٣ زﺎﻬﺠﻟﺎﺑ ﻖﺤﻠﻣ ﻞﺑﺎﻜﺑ ﺔﻳﺬﻐﺗ رﺪﺼﻤﻟ زﺎﻬﺠﻟا ﻞﻴﺻﻮﺘﺑ ﻢﻗ •
ﺲﺑﺎﻗ و ﺲﺒﻘﻤﺑ ةﺪﺋاﺰﻟا ﺔﻟﻮﻤﺤﻟا حﺎﺘﻔﻣ لاﺪﺒﺘﺳا ﻦﻜﻤﻳ , ﺔﻗﺎﻄﻟا رﺪﺼﻤﺑ كزﺎﻬﺟ ﻞﻴﺻﻮﺘﻟ ﺮﻴﺒﻣأ ١٦ ةﺪﺋاز ﺔﻟﻮﻤﺣ حﺎﺘﻔﻣ ماﺪﺨﺘﺳا •
ﻞﻴﻤﻌﻟا ﺔﻴﻟﻮﺌﺴﻣ ﻚﻟذ ﺢﺒﺼﻳ حﺎﺘﻔﻤﻟا ﺐﻴﻛﺮﺗ مﺪﻋ ﺔﻟﺎﺣ ﻰﻓ ,ﺮﻴﺒﻣأ ٢٠ - ١٦
ﻪﻟ ﺐﺳﺎﻨﻤﻟا حﺎﺘﻔﻤﻟا و ﻞﻤﺣ ﻞﻛ ﻰﻟﺎﺘﻟا لوﺪﺠﻟا ﻰﻓ حﺮﺘﻘﻣ
مﺎﻫ ﺮﻳﺬﺤﺗ
ﺔﻛﺮﺸﻟا و ﻞﻴﻤﻌﻟا ﺔﻴﻟﻮﺌﺴﻣ ﻚﻟذ ﺢﺒﺼﻳ ةرﻮﻛﺬﻤﻟا ﻰﺿرﻷا ﺔﻠﺻو نوﺪﺑ ءﺎﺑﺮﻬﻜﻟا ﺬﺧﺄﻣ ﻰﻠﻋ زﺎﻬﺠﻟا ﻞﻴﺻﻮﺗ ﺔﻟﺎﺣ ﻰﻓ •
. ﺊﻃﺎﺨﻟا ﻞﻴﺻﻮﺘﻟا اﺬﻫ ﺔﺠﻴﺘﻧ ثﺪﺤﺗ ﺪﻗ راﺮﺿا ىا ﻦﻋ ﺔﻟﻮﺌﺴﻣ ﺮﻴﻏ ﺔﺠﺘﻨﻤﻟا
. ةﺪﻤﺘﻌﻣ ﺔﻣﺪﺧ ﺰﻛاﺮﻣ ﻦﻣ ﺺﺼﺨﺘﻣ ﻰﻨﻓ لﻼﺧ ﻦﻣ ﻻا رﺎﻴﻏ ﻊﻄﻗ ىا وا ﻞﺑﺎﻜﻟا لاﺪﺒﺘﺳا ﻢﺘﻳ ﻻ •
مﺎﻫ ﺮﻳﺬﺤﺗ
. ءﺎﻤﻟﺎﺑ نﺎﺨﺴﻟا ءﻼﺘﻣا ﻦﻣ ﺪﻛﺄﺘﻟا ﺪﻌﺑ ﻻا ﺔﻗﺎﻄﻟا رﺪﺼﻤﺑ نﺎﺨﺴﻟا ﻞﻴﺻﻮﺗ ﻢﺘﻳ ﻻ •
ﺰﺗﺮﻫ ٦٠-٥٠ , لﺎﻜﻴﻧﺎﻜﻴﻤﻟا نﺎﺨﺴﻠﻟ ﺖﻟﻮﻓ ٢٢٠ , لﺎﺘﻴﺠﻳﺪﻟا نﺎﺨﺴﻠﻟ ﺖﻟﻮﻓ ٢٤٠ -٢٢٠ نﺎﺨﺴﻠﻟ ﻞﺻاﻮﻟا رﺎﻴﺘﻟا ﺪﻬﺟ نأ ﻦﻣ ﺪﻛﺄﺘﻟا •
(ةﺰﻳﺮﺑ) رﺎﻴﺗ ﺬﺧﺄﻣ ﻰﻠﻋ زﺎﻬﺠﻟا ءﺎﺑﺮﻬﻛ ﺔﺸﻴﻓ ﻞﻴﺻﻮﺗ و ﻰﻨﺒﻤﻟﺎﺑ ﻰﺿرأ ﺔﻠﻴﺻﻮﺗ دﻮﺟو ﺔﻟﺎﺣ ﻰﻓ ﻻا زﺎﻬﺠﻟا اﺬﻫ مﺪﺨﺘﺴﻳﻻ •
.ﺔﻴﺋﺎﻨﺜﻟا ةﺰﻳﺮﺒﻟا ﻊﻣ ﻰﻘﺒﺘﻤﻟا رﺎﻴﺘﻠﻟ ﻰﺿرأ ﺔﻠﺻو ﺔﻓﺎﺿإ مﺰﻠﻳ وا ﻰﺿرأ فﺮﻃ ﺎﻬﺑ ﺔﻴﺛﻼﺛ
.ﺪﻤﺘﻌﻤﻟا ﺔﻣﺪﺨﻟا ﺰﻛﺮﻣ ﻞﺒﻗ ﻦﻣ ﻪﻟاﺪﺒﺘﺳإ ﻢﺘﻳ ءﺎﺑﺮﻬﻜﻟا ﻞﺑﺎﻛ ﻰﻓ ﻒﻠﺗ ىا ثﺪﺣ اذإ •
(RCD)
لﺎﺘﻴﺠﻳﺪﻟا نﺎﺨﺴﻟا ﻢﻜﺤﺗ ﺔﺣﻮﻟ
لﺎﻜﻴﻧﺎﻜﻴﻤﻟا نﺎﺨﺴﻟا ﻢﻜﺤﺗ ﺔﺣﻮﻟ
نﺎﺨﺴﻟا فﺎﻘﻳا و ﻞﻴﻐﺸﺗ رز
نﺎﺨﺴﻠﻟ ﻞﻴﻐﺸﺘﻟا ﻊﺿو رﺎﻴﺘﺧا رز
ةراﺮﺤﻟا ﺔﺟرد ﻊﻓر رز
ةراﺮﺤﻟا ﺔﺟرد ﺾﻔﺧ رز
ﺔﺑﻮﻠﻄﻤﻟا ةراﺮﺤﻟا ﺔﺟرد ﻰﻟا نﺎﺨﺴﻟا لﻮﺻو و ﻦﻴﺨﺴﺘﻟا ﺔﻳﺎﻬﻧ ﻰﻨﻌﻳ و ﺮﻤﺣﻷا نﻮﻠﻟﺎﺑ ﺊﻀﻳ
ﻦﻴﺨﺴﺗ ﺔﻟﺎﺣ ﻰﻓ نﺎﺨﺴﻟا نأ ﻰﻨﻌﻳ و ﻰﻟﺎﻘﺗﺮﺒﻟا نﻮﻠﻟﺎﺑ ﺊﻀﻳ
ىدﺎﺼﺘﻗﻻا ﻊﺿﻮﻟا ﻲﻓ نﺎﺨﺴﻟا ﻞﺧﺪﻳ ﺎﻣﺪﻨﻋ ﺮﻀﺧﻻا نﻮﻠﻟﺎﺑ ﺊﻀﻳ
ﻒﻴﻈﻨﺘﻟا ﻊﺿو ﻲﻓ نﺎﺨﺴﻟا ﻞﺧﺪﻳ ﺎﻣﺪﻨﻋ ﺾﻴﺑﻷا نﻮﻠﻟﺎﺑ ﺊﻀﻳ
ECO Mode
Clean Mode
ﺔﻴﺑﺮﻬﻜﻟا تﻼﻴﺻﻮﺘﻟا ﺐﻴﻛﺮﺗ
Heating Element Power (W)
Rated Current
1500
10 A
1800
16 A
2000
16 A
رﺎﻄﺧإ نوﺪﺑ ﺮﻴﻴﻐﺘﻠﻟ ﺔﺿﺮﻋ
:
Heating
power on
ﻦﻴﺨﺴﺘﻟا ﺔﺟرﺪﻟ لﻮﺻﻮﻟا ﺪﻨﻋ ﻞﺼﻔﻳ و ﻦﻴﺨﺴﺘﻟا ﺪﻨﻋ ﻲﻟﺎﻘﺗﺮﺒﻟا نﻮﻠﻟﺎﺑ ﺊﻀﻳ
نﺎﺨﺴﻠﻟ ءﺎﺑﺮﻬﻜﻟا لﻮﺻو ﻲﻨﻌﺗ و ﻞﻴﻐﺸﺘﻟا ﺪﻨﻋ ﺮﻤﺣﻻا نﻮﻠﻟﺎﺑ ﺊﻀﻳ
POWER ON HEATING
