GENERAL SAFETY RULES
GB
WARNING! When using gas tools, basic safety precautions, including the following, should always be followed to
reduce the risk of serious personal injury and/or damage to the unit.
Read all these instructions before operating this product and save these instructions.
1. DO NOT operate a chain saw with one hand! Serious
injury to the operator, helpers, bystanders, or any
combination of these persons may result from one-
handed operation. A chain saw is intended for two-
handed use.
2. DO NOT operate a chain saw when you are fatigued,
under the influence of drugs, alcohol or medication.
3. Use safety footwear, snug-fitting clothing, protective
gloves, and eye, hearing and head protection
devices.
4. Use caution when handling fuel. To avoide fire, move
the chain saw at least 10 feet (3m) from the fueling
point before starting the engine.
5. DO NOT allow other persons to be near when start-
ing or cutting with the chain saw. Keep bystanders
and animals out of the work area.
6. DO NOT start cutting until you have a clear work
area, secure footing, and a planned retreat path from
the falling tree.
7. Keep all parts of your body away from the saw chain
when the engine is running.
8. Before you start the engine, make sure that the saw
chain is not contacting anything.
9. Carry the chain saw with the engine stopped, the
guide bar and saw chain to the rear, and the muffler
away from your body.
10. DO NOT operate a chain saw that is damaged,
improperly adjusted, or not completely and securely
assembled. Be sure that the saw chain stops moving
when the throttle control trigger is released.
11. Shut off the engine before setting the chain saw
down.
12. Use extreme caution when cutting small size brush
and saplings because slender material may catch the
saw chain and be whipped toward you or pull you off
balance.
13. When cutting a limb that is under tension, be alert for
springback so that you will not be struck when the
tension in the wood fibers is released.
14. Keep the handles dry, clean, and free of oil or fuel
mixture.
15. Operate the chain saw only in well-ventilated areas.
16. DO NOT operate a chain saw in a tree unless you
have been specifically trained to do so.
17. All chain saw service, other than the items listed in
the user manual safety and maintenance instructions,
should be performed by competent chain saw service
personnel.
18. When transporting your chain saw, use the appropri-
ate guide bar scabbard.
19. DO NOT operate your chain saw near or around flam-
mable liquids or gases whether in or out of doors. An
explosion and/or fire may result.
20. Do not fill fuel tank, oil tank or lubricate when the
engine is running.
21. USE THE RIGHT TOOL: Cut wood only. Do not use
the chain saw for purposes for which it was not
intended. For example, do not use the chain saw for
cutting plastic, masonry, or nonbuilding materials.
22. The first time user should have practical instruction in
manual page 9 (barking Saw horse) in the use of
chainsaw and the protective equipment form an expe-
rienced operator.
23. Do not attempt to hold the saw with one hand only.
You cannot control reactive forces and you may lose
control of the saw, which can result in the skating or
bouncing of the bar and chain along the limb or log.
24. Never run the chainsaw indoors.
Your chainsaw produces poisonous exhaust as soon
as the combustible engine is started, which may be
colorless and odorless. To use this product can gen-
erate dust, mists and fumes containing chemicals
known to cause reproductive harm. Be aware of
harmful dust, mist (such as saw dust or oil mist from
chain lubrication) and protect your self properly.
25. Wear gloves and keep your hand warm.
Prolonged use of chainsaws exposing the operator to
vibrations may produce whitefinger disease. In order
to reduce the risk of whitefinger disease, please wear
gloves and keep your hand warm. If any of the
whitefinger symptoms appear, seek medical advice
immediately.
Meaning of symbols marked on the product
Read the user manual before using the machine
Whenever the machine is in use, safety goggles must
be worn to safeguard against flying objects, as must
ear protectors, such as a soundproof helmet, in order
to protect the operator’s hearing. If the operator is
working in an area where there is a risk of falling
objects, a safety helmet must also be worn.
Make Sure the Chain Brakeis disengaged! Pull Hand
Guard/Chain Brakeback to run.
Wear gloves to protect your hands
Primer Bulb
109
Acoustic power level LWA accordance with directive
2000/14/EC + 2005/88/EC
Warning! Danger
Wear safety boots to protect your feet
26. Drive in the spiked bumper of the chainsaw directly
behind the intended hinge and pivot the saw around
this point. The spiked bumper rolls against the trunk.
NOTE: This appendix is intended primarily for the con-
sumer or occasional user. These models are intended for
infrequent use by homeowners, cottagers, and campers,
and for such general applications as clearing, pruning,
cutting firewood, etc. They are not intended for prolonged
use. If the intended use involves prolonged periods of
operation, this may cause circulatory problems in the
user’s hands due to vibration.
KICKBACK may occur when the NOSE or TIP of the
guide bar touches an object, or when wood closes in and
pinches the saw chain in the cut.
Tip contact in some cases may cause a lightning-fast
reverse reaction, kicking the guide bar up and back
toward the operator.
PINCHING the saw chain along the BOTTOM of the
guide bar may PULL the saw forward away from the
operator. PINCHING the saw chain along the TOP of the
guide bar may PUSH the guide bar rapidly back toward
the operator.
Any of these reactions may cause you to lose control of
the saw, which could result in serious personal injury.
1. With a basic understanding of kickback, you can
reduce or eliminate the element of surprise. Sudden
surprise contributes to accidents.
2. Keep a good firm grip on the saw with both hands, the
right hand on the rear handle, and the left hand on
the front handle, when the engine is running. Use a
firm grip with thumbs and fingers encircling the chain
saw handles. A firm grip will help you reduce kickback
and maintain control of the saw. Don’t let go.
3. Make sure that the area in which you are cutting is
free from obstructions. Do not let the nose of the
guide bar contact a log, branch, or any other obstruc-
tion which could be hit while you are operating the
saw.
4. Cut at high engine speeds.
5. Do not overreach or cut above shoulder height.
6. Follow manufacturer’s sharpening and maintenance
instructions for the saw chain.
7. Only use replacement bars and chains specified by
the manufacturer or the equivalent.
NOTE: Low-kickback saw chain is chain that has met the
kickback performance.
Your Talon Chain Saw is provided with a safety label
located on the chain brake lever/hand guard. This label,
along with the safety instructions on these pages, should
be carefully read before attempting to operate this unit.
•HOW TO READ SYMBOLS AND COLORS
(FIG. 1)
GREEN RECOMMENDED
Recommended cutting procedure.
WARNING
1. Avoid bar nose contact.
2. Beware of kickback.
3. Do not attempt to hold saw with one hand.
RECOMMENDED
4. Hold saw properly with both hands.
•DANGER! BEWARE OF KICKBACK!
KICKBACK SAFETY PRECAUTIONS
WARNING: RED Used to warn that an
unsafe procedure should not be performed.
1234
Fig. 1
IMPORTANT SAFETY
WARNING: Kickback can lead to dangerous
loss of control of the chain saw and result in
serious or fatal injury to the saw operator or to
anyone standing close by. Always be alert.
Rotational kickback and pinch-kickback are
major chain saw operational dangers and the
leading cause of most accidents.
BEWARE OF:
ROTATIONAL KICK-
BACK (Fig. 2A)
A = Kickback path
B = Kickback reaction
zone
THE PUSH (PINCH
KICKBACK) AND PULL
REACTIONS (Fig. 2B)
A = Pull
B = Solid objects
C = Push
Fig. 2A
A
A
B
A
A
B
C
Fig. 2B
