Instructions
Instrucciones
使用說明書
Sony Corporation 2003 Printed in Thailand
XS-GT6946
XS-GT6936
XS-GT6036
XS-GT6026
4-way Speaker
3-way Speaker
3-249-343-11 (1)
Specifications
XS-GT6946
Speaker Coaxial 4-way:
Woofer 16 × 24 cm cone type
Midrange 6.6 cm cone type
Tweeter 2.5 cm balance dome
type
Super tweeter 2.5 cm balance
dome type
Peak power 300 watts
Rated power 80 watts
Impedance 4 ohms
Sensitivity 90 dB/W/m
Frequency response 25 – 32,000 Hz
Mass Approx. 1.3 kg per speaker
Supplied accessories Parts for installation
XS-GT6936
Speaker Coaxial 3-way:
Woofer 16 × 24 cm cone type
Midrange 6.6 cm cone type
Tweeter 2.5 cm balance dome
type
Peak power 230 watts
Rated power 60 watts
Impedance 4 ohms
Sensitivity 91 dB/W/m
Frequency response 28 – 28,000 Hz
Mass Approx. 1.2 kg per speaker
Supplied accessories Parts for installation
XS-GT6036
Speaker Coaxial 3-way:
Woofer 16 cm cone type
Midrange 4.5 cm cone type
Tweeter 1.1 cm dome type
Peak power 210 watts
Rated power 50 watts
Impedance 4 ohms
Sensitivity 91 dB/W/m
Frequency response 30 – 30,000 Hz
Mass Approx. 870 g per speaker
Supplied accessories Parts for installation
XS-GT6026
Speaker Coaxial 3-way:
Woofer 16 cm cone type
Midrange 4.5 cm cone type
Tweeter 1.1 cm dome type
Peak power 190 watts
Rated power 50 watts
Impedance 4 ohms
Sensitivity 90 dB/W/m
Frequency response 30 – 30,000 Hz
Mass Approx. 750 g per speaker
Supplied accessories Parts for installation
Design and specifications are subject to change without
notice.
Especificaciones
XS-GT6946
Altavoz Coaxial de 4 vías
Graves: 16 × 24 cm, tipo
cónico
Gama media: 6,6 cm, tipo
cónico
Agudos: 2,5 cm, balanceado
tipo cúpula
Supertweeter: 2,5 cm,
balanceado tipo cúpula
Corriente máxima 300 vatios
Corriente nominal 80 vatios
Impedancia 4 ohmios
Sensibilidad 90 dB/W/m
Respuesta en frecuencia 25 – 32.000 Hz
Peso Aprox. 1,3 kg por altavoz
Accesorios suministrados
Componentes para instalación
XS-GT6936
Altavoz Coaxial de 3 vías
Graves: 16 × 24 cm, tipo
cónico
Gama media: 6,6 cm, tipo
cónico
Agudos: 2,5 cm, balanceado
tipo cúpula
Corriente máxima 230 vatios
Corriente nominal 60 vatios
Impedancia 4 ohmios
Sensibilidad 91 dB/W/m
Respuesta en frecuencia 28 – 28.000 Hz
Peso Aprox. 1,2 kg por altavoz
Accesorios suministrados
Componentes para instalación
XS-GT6036
Altavoz Coaxial de 3 vías
Graves: 16 cm, tipo cónico
Gama media: 4,5 cm, tipo
cónico
Agudos: 1,1 cm, tipo cúpula
Corriente máxima 210 vatios
Corriente nominal 50 vatios
Impedancia 4 ohmios
Sensibilidad 91 dB/W/m
Respuesta en frecuencia 30 – 30.000 Hz
Peso Aprox. 870 g por altavoz
Accesorios suministrados
Componentes para instalación
XS-GT6026
Altavoz Coaxial de 3 vías
Graves: 16 cm, tipo cónico
Gama media: 4,5 cm, tipo
cónico
Agudos: 1,1 cm, tipo cúpula
Corriente máxima 190 vatios
Corriente nominal 50 vatios
Impedancia 4 ohmios
Sensibilidad 90 dB/W/m
Respuesta en frecuencia 30 – 30.000 Hz
Peso Aprox. 750 g por altavoz
Accesorios suministrados
Componentes para instalación
Diseño y especificaciones sujetos a cambio sin previo
aviso.
規格
XS-GT6946
揚聲器 同軸型，4 聲道
低音揚聲器 16 × 24 cm 錐型
中音揚聲器 6.6 cm 錐型
高音揚聲器 2.5 cm B.D.型
超高音揚聲器 2.5 cm B.D.型
峰值功率 300 W
額定功率 80 W
阻抗 4 Ω
靈敏度 90 dB/W/m
頻率響應 25 - 32,000 Hz
重量 大約 1.3 kg 每個揚聲器
提供的附件 安裝用部件
XS-GT6936
揚聲器 同軸型，3 聲道
低音揚聲器 16 × 24 cm 錐型
中音揚聲器 6.6 cm 錐型
高音揚聲器 2.5 cm B.D.型
峰值功率 230 W
額定功率 60 W
阻抗 4 Ω
靈敏度 91 dB/W/m
頻率響應 28 - 28,000 Hz
重量 大約 1.2 kg 每個揚聲器
提供的附件 安裝用部件
XS-GT6036
揚聲器 同軸型，3 聲道
低音揚聲器 16 cm 錐型
中音揚聲器 4.5 cm 錐型
高音揚聲器 1.1 cm 圓頂型
峰值功率 210 W
額定功率 50 W
阻抗 4 Ω
靈敏度 91 dB/W/m
頻率響應 30 - 30,000 Hz
重量 大約 870 g 每個揚聲器
提供的附件 安裝用部件
XS-GT6026
揚聲器 同軸型，3 聲道
低音揚聲器 16 cm 錐型
中音揚聲器 4.5 cm 錐型
高音揚聲器 1.1 cm 圓頂型
峰值功率 190 W
額定功率 50 W
阻抗 4 Ω
靈敏度 90 dB/W/m
頻率響應 30 - 30,000 Hz
重量 大約 750 g 每個揚聲器
提供的附件 安裝用部件
設計和規格有所變更時，恕不另行奉告
。
1
Parts list
Lista de las piezas
零件一覽表
2
34
ø 4 × 30 ( × 8)
XS-GT6946/GT6936: 4 m ( × 2)
XS-GT6036/GT6026: 2 m ( × 2)
XS-GT6946/GT6936
( × 2)
XS-GT6036/GT6026
Dimensions
Dimensiones
尺寸
Unit: mm
Unidad: mm
單位：mm
ø 106
234
216
4.5 × 7
147
166
38
34
22 53
ø 80
ø 127
ø 4.5
XS-GT6946 XS-GT6036
XS-GT6026
117
252
166
25
71
XS-GT6936
ø 102
216
4.5 × 7
166
38
117
252
166
25 71
159
XS-GT6946/GT6936
XS-GT6036/GT6026
147
234
177
ø 142
ø 158
34 21 45
ø 75
ø 127
ø 4.5
159
177
ø 142
ø 158
169
181
181
169
Precautions
•Do not continuously use the speaker system
beyond the peak power handling capacity.
•Keep recorded tapes, watches, and personal
credit cards using magnetic coding away from
the speaker system to protect them from
damage caused by the magnets in the
speakers.
If you cannot find an appropriate mounting
location, consult your car dealer or your
nearest Sony dealer before mounting.
Precauciones
•Procure no activar el sistema de altavoces de
forma continua con una potencia que
sobrepase la potencia admisible.
•Mantenga alejados del sistema de altavoces las
cintas grabadas, relojes o tarjetas de crédito
con codificación magnética para evitar daños
que posiblemente causaría el imán de los
altavoces.
Si no encuentra un emplazamiento
apropiado para el montaje, consulte al
distribuidor de su automóvil o al proveedor
de Sony más próximo.
使用前須注意
•請勿超過峰值功率處理能力連續使用揚聲器系
統。
•將錄製的磁帶、手錶、和使用磁碼的個人信用
卡遠離揚聲器系統放置，以免被揚聲器中的磁
鐵損壞。
如果您找不到適當的安裝位置，即請洽詢您購
入車輛的商店或附近的 Sony 銷售店，然後才
進行安裝。
