音訊:
eARC (Enhanced Audio Return Channel)模式
有關詳情,請參閱線上說明指南。
eARC 模式除外
5.1 聲道線性 PCM:32/44.1/48/88.2/96/176.4/
192 kHz 16/20/24 位元,Dolby Audio,Dolby
Atmos,DTS
eARC/ARC (Enhanced Audio Return Channel/Audio
Return Channel)(僅限 HDMI 輸入 3)*
5
eARC 模式
有關詳情,請參閱線上說明指南。
ARC 模式
雙聲道線性 PCM:48 kHz 16 位元,Dolby Audio,
Dolby Atmos,DTS
光纖數位聲音輸出
數位光纖插孔 (雙聲道線性 PCM:48 kHz 16 位元,
Dolby Audio,DTS)
(立體聲迷你插孔)
耳機
1, 2
USB 端子 1 支援高速 USB (USB 2.0)
USB 端子 2 支援超速 USB (USB 3.2 Gen 1)
LAN
10BASE-T/100BASE-TX 接頭 (視網路的作業環境而定,
連線速度可能不同。無法保證通訊率和通訊品質。
電源和其他規格
電源需求
110 V AC,60 Hz
螢幕尺寸 (對角測量)(大約)
KM-85X85K:85 英寸 / 214.8 公分
KM-75X85K:75 英寸 / 189.3 公分
KM-65X85K:65 英寸 / 163.9 公分
KM-55X85K:55 英寸 / 138.8 公分
KM-50X85K:50 英寸 / 125.7 公分
KM-43X85K:43 英寸 / 108.0 公分
耗電量
KM-85X85K:378 W
KM-75X85K:364 W
KM-65X85K:296 W
KM-55X85K:229 W
KM-50X85K:148 W
KM-43X85K:114 W
待機耗電量 *
6
*
7
0.5 W
顯示解析度 (水平 × 垂直) (畫素)
3840 × 2160
額定輸出
500 毫安培 (對於 USB 1),900 毫安培 (對於 USB
2)
尺寸 (大約)(寬 × 高 × 深)(毫米)
包含顯示器底座
KM-85X85K:1901 × 1178 × 457
KM-75X85K:1675 × 1041 × 412
KM-65X85K:1452 × 906 × 339
KM-55X85K:1233 × 783 × 339
KM-50X85K:1119 × 716 × 288
KM-43X85K:964 × 629 × 288
不含顯示器底座
KM-85X85K:1901 × 1090 × 73
KM-75X85K:1675 × 962 × 73
KM-65X85K:1452 × 836 × 72
KM-55X85K:1233 × 711 × 72
KM-50X85K:1119 × 649 × 70
KM-43X85K:964 × 563 × 69
重量 (大約)(公斤)
包含顯示器底座
KM-85X85K:46.2
KM-75X85K:33.8
KM-65X85K:23
KM-55X85K:18.1
KM-50X85K:13.3
KM-43X85K:10.7
不含顯示器底座
KM-85X85K:44.7
KM-75X85K:32.6
KM-65X85K:22
KM-55X85K:17.1
KM-50X85K:12.7
KM-43X85K:10.2
其他
選用的配件
壁掛式支架:SU-WL850 (僅限 KM-75X85K / 65X85K /
55X85K)
壁掛式支架:SU-WL450
攝影機與麥克風組件:CMU-BC1
操作溫度:0 ºC - 40 ºC
操作濕度:10 % - 80 % 相對濕度 (非冷凝)
*1 當輸4096 × 2160p 且 [ 寬螢幕模式 ] 設為 [ 正常模式 ]
時,解析度將顯示為 3840 × 2160p。要顯示 4096 ×
2160p,請將 [ 寬螢幕模式 ] 設定設為 [ 全螢幕模式 1 ]
[ 全螢幕模式 2 ]。
*2 請參閱屏幕菜單設定 [ HDMI 訊號格式 ]。
*3 有關詳情,請參閱線上說明指南。
*4 僅限 HDMI 輸入 3 & 4。使用 Ultra High Speed HDMI Cable
進行連接。
*5 將您的音訊系統連接至 HDMI 輸入 3 以傳送 LCD 顯示器音訊
至您的音訊系統。
*6 LCD 顯示器完成必要的內部處理程序之後會達到指定的待機電
力。
*7 在 LCD 顯示器連接網路時,待機耗電量會增加。
選購配件依各國家/地區/機型/庫存而定。
設計和規格如有變更,恕不另行通知。
使用 Google 助理時,可能需要訂購服務和應用程式,並可能新
增適用的條款、條件和 / 或費用。
可用功能或會因不同的連接設備而異。在某些情況下即使執行
了上述操作,也可能會以不同的方式工作或根本不工作。
商標資訊
HDMI、HDMI 高畫質多媒體介面及 HDMI 標誌為 HDMI
Licensing Administrator, Inc. 在美國及其他國家的
商標或註冊商標。
Dolby、杜比、Dolby Vision、Dolby Atmos、Dolby
Audio、和雙 D 符號是杜比實驗室特許公司的商標。本
產品經過杜比實驗室的許可而製造。 未公佈的機密作
品。版權所有 © 1992-2021 杜比實驗室。保留所有權
利。
Gracenote、Gracenote 標誌和標誌字型、“Powered
by Gracenote” 標誌是 Gracenote, Inc. 在美國和 /
或其他國家的註冊商標或商標。
Google TV 為得透過本裝置體驗之軟體名稱和 Google
LLC 的商標。Google、YouTube 和其他標記均為
Google LLC 的商標。
有關 DTS 專利,請參閱 http://patents.dts.com。
DTS, Inc. 授權製造。DTS、Digital Surround、以及
DTS 標誌是 DTS, Inc. 在美國和其他國家的註冊商標
或商標。 © 2020 DTS,Inc. 保留所有權利。
Netflix 是 Netflix, Inc. 的註冊商標。
TUXERA 是 Tuxera Inc. 在美國與其他國家的註冊商
標。
所有其他商標屬於其各自的所有者。
商品名稱: LCD 顯示器
型號: KM-85X85K
KM-75X85K
KM-65X85K
KM-55X85K
KM-50X85K
KM-43X85K
額定電壓: 110 V
額定頻率: 60 Hz
消耗功率: KM-85X85K
KM-75X85K
KM-65X85K
KM-55X85K
KM-50X85K
KM-43X85K
(378 W)
(364 W)
(296 W)
(229 W)
(148 W)
(114 W)
製造年份: 如機體上標示
製造號碼: 如機體上標示
商品原產地: 馬來西亞
委製廠商: Sony Corporation
進口商: 台灣索尼股份有限公司
地址: 台北市中山北路二段
42 號 5 樓
支援
https://www.sony-asia.com/support
iuuqt;00xxx/tpoz/dpn/ux0tfswjdf0
© 2022 Sony Corporation Printed in Malaysia
