When using your mig welder, basic safety precautions should always be followed to

reduce the risk of personal injury and / or damage to the mig welder.

Read all of these instructions before operating the mig welder and save this user man-

ual for future reference.

The mig welder should not be modified or used for any application other than that for

which it was designed.

This mig welder was designed to supply electric current for MIG welding.

If you are unsure of its relative applications do not hesitate to contact us and we will

be more than happy to advise you.

Before each use of the mig welder always check no parts are broken and that no

parts are missing.

Always operate the mig welder safely and correctly.

KNOW YOUR MIG WELDER: Read and understand the owner's manual and labels af-

fixed to the mig welder. Learn its applications and limitations, as well as the potential

hazards specific to it.

KEEP WORK AREA CLEAN AND WELL LIT: Cluttered work benches and dark areas invite

accidents. Floors must not be slippery due to oil, water or sawdust etc.

DO NOT USE THE MIG WELDER IN DANGEROUS ENVIRONMENTS: Do not use the mig

welder in damp or wet locations, or expose it to rain. Provide adequate space sur-

rounding the work area. Do not use in environments with a potentially explosive atmos-

phere.

KEEP CHILDREN AND UNTRAINED PERSONNEL AWAY FROM THE WORK AREA: All visitors

SAFETY SYMBOLS USED THROUGHOUT THIS MANUAL

SAFETY INSTRUCTIONS

IMPORTANT: Please read the following instructions carefully, failure to do

so could lead to serious personal injury and / or damage to the mig

welder.

Danger / Caution: Indicates risk of personal injury and/or the possibility of

damage.

Warning: Risk of electrical injury or damage!

Note: Supplementary information.

PARTS LIST WELDMATE T166 MIG

Ref. No. Description Sip Part No. Ref. No. Description Sip Part No.

1. Left side panel WE02-00035 21. Fan support WE02-00022

2. Hinge WE02-00051 22. Fan motor WE02-00023

3. Lock WE02-00002 23. Fan Blade WE02-00024

4. Wire feed motor WE02-00036 24. Right side panel WE02-00055

5. Front panel WE02-00003 25. Handle WE02-00015

6. Rotary switch 6pos WE02-00052 26. Mains lead WE02-00056

7. On/Off switch WE02-00004 27. Rear panel WE02-00057

8. Thermal overload light WE02-00053 28A. Gas hose connector WE02-00042

9. Potentiometer knob WE02-00007 28B. Gas valve connector WE02-00043

10. Welding torch 02741 29. Rectifier WE02-00058

11. Earth return lead WE02-00010 30. Rectifier support WE02-00059

12. Cable grommet WE02-00009 31. Breaker WE02-00020

13. Cable clamp WE02-00011 32. Auxiliary transformer WE02-00031

14. PCB holder WE02-00013 33. Centre panel WE02-00046

15. PCB WE02-00037 34. Positive terminal WE02-00047

16. Foot WE02-00019 35. Wire spool holder WE02-00030

17. Lower panel WE02-00038 36. Negative terminal WE02-00048

18. Mains filter WE02-00016 37. Fuse WE02-00032

19. Thermostat WE01-00039 N/A. Wire feed roller 0.6-0.8 WE02-00049

20. Transformer c/w choke WE02-00054
