Manual

BOUNCE FLASH

When you take a photo with flash in a room, sometimes a strong shadow will appear

behind the subject, if you point the flash head upwards or sideways to reflect the light

off the ceiling, wall etc. the subject will be illuminated softly. Press the lock button and

adjust the flash head to set the bounce angle (fig.7).

UP: 0°, 60°, 75°, 90° DOWN: 0°,7°

RIGHT: 0°, 60°, 75°, 90° LEFT: 0°, 60°, 75°,90°, 120°, 150°, 180°

■ The picture will receive the color from the reflecting surface. Please choose a white

surface for bouncing.

CLOSE-UP EXPOSURES

For bounce flash can be tilted 7° downward for close-ups. The Flash will be effective

only for the subjects 0.5 meter to 2 meters.

■ The Flash coverage angle display will blink (2 times / second), when you set the

flash head tilted downward by 7°

CATCH LIGHT PANEL

This flash is equipped with a built-in catch light panel, which can create a catch light in

the eyes of the subject when the bounce flash mode is activated. Slide out the wide

panel and catch light panel (fig.8-1), and then put wide panel back in its place (fig.8-2).

(Be careful to slide the panels out smoothly.)

■ To create a catch light effectively, tilt the flash head upward 90 degrees and take

pictures at a close distance (fig.9).

《表 1》《chart.1》《Tabelle 1》《Tableau 1》《tabel 1》《Tabla 1》 ft

17mm 24mm 28mm 35mm 50mm 70mm 105mm

1.4

1.5-16.4 2.1-24.3 2.2-25.0 2.3-25.7 2.9-32.9 3.3-37.1 3.9-43.6

4.9-53.8 6.9-79.7 7.2-82.0 7.5-84.3 9.5-107.9

10.8-121.7 12.8-143.0

2.0

1.0-11.5 1.5-17.0 1.5-17.5 1.6-18.0 2.0-23.0 2.3-26.0 2.7-30.5

3.3-37.7 4.9-55.8 4.9-57.4 5.2-59.1 6.6-75.5 7.5-85.3 8.9-100.1

2.8

0.7-8.2 1.1-12.1 1.1-12.5 1.1-12.9 1.5-16.4 1.6-18.6 1.9-21.8

2.3-26.9 3.6-39.7 3.6-41.0 3.6-42.3 4.9-53.8 5.2-61.0 6.2-71.5

4.0

0.7-5.8 0.8-8.5 0.8-8.8 0.8-9.0 1.0-11.5 1.1-13.0 1.3-15.3

2.3-19.0 2.6-27.9 2.6-28.9 2.6-29.5 3.3-37.7 3.6-42.7 4.3-50.2

5.6

0.7-4.1 0.7-6.1 0.7-6.3 0.7-6.4 0.7-8.2 0.8-9.3 1.0-10.9

2.3-13.5 2.3-20.0 2.3-20.7 2.3-21.0 2.3-26.9 2.6-30.5 3.3-35.8

8.0

0.7-2.9 0.7-4.3 0.7-4.4 0.7-4.5 0.7-5.8 0.7-6.5 0.7-7.6

2.3-9.5 2.3-14.1 2.3-14.4 2.3-14.6 2.3-19.0 2.3-21.3 2.3-24.9

11.0

0.7-2.1 0.7-3.1 0.7-3.2 0.7-3.3 0.7-4.2 0.7-4.7 0.7-5.5

2.3-6.9 2.3-10.2 2.3-10.5 2.3-10.8 2.3-13.8 2.3-15.4 2.3-18.0

16.0

0.7-1.4 0.7-2.1 0.7-2.2 0.7-2.3 0.7-2.9 0.7-3.3 0.7-3.8

2.3-4.6 2.3-6.9 2.3-7.2 2.3-7.5 2.3-9.5 2.3-10.8 2.3-12.5

22.0

0.7-1.0 0.7-1.5 0.7-1.6 0.7-1.6 0.7-2.1 0.7-2.4 0.7-2.8

2.3-3.3 2.3-4.9 2.3-5.2 2.3-5.2 2.3-6.9 2.3-7.9 2.3-9.2

32.0

0.7-1.1 0.7-1.1 0.7-1.1 0.7-1.4 0.7-1.6 0.7-1.9

2.3-3.6 2.3-3.6 2.3-3.6 2.3-4.6 2.3-5.2 2.3-6.2

《表 2》《chart.2》《Tabelle 2》《Tableau 2》《tabel 2》《Tabla 2》

17mm 24mm 28mm 35mm 50mm 70mm 105mm

MH 23.0 34.0 35.0 36.0 46.0 52.0 61.0

ML 5.8 8.5 8.8 9.0 11.5 13.0 15.3

《表 3》《chart.3》《Tabelle 3》《Tableau 3》《tabel 3》《Tabla 3》

ISO25 ISO50 ISO200 ISO400

ISO80

ISO1600

ISO320

X0.5 X0.71 X1.4 X2 X2.8 X4 X5.7
