Manual

12/29/2004

ADJUSTMENTS

Tiller Angle Adjustment (Fig. 5)

On the left hand side at the base of the tiller

is a red lever. Push the lever to release the

pin and select the desired tiller angle. Refit

the pin into one of the five location holes to

lock tiller in place.

DO NOT DRIVE SCOOTER IF TILLER IS

NOT SECURED.

Seat Slide & Swivel Adjustment (Fig. 6)

Pulling up on the seat black slide lever

allows the seat position to be adjusted

forward or backward. Release the lever and

the seat will lock in that position. Under the

right side of the seat there is a spring loaded

red lever. Pulling up on the lever allows the

seat to swivel, when released the seat will

lock into one of four positions.

Seat Removal (Fig. 7)

Fold down the back of the seat. Pull up the

red swivel seat adjustment lever (fig. 6) and

lift seat off. Remove the hand knob and

locking pin that secures the seat adaptor.

Lift the seat adaptor out of the seat post.

Seat Height Adjustment (Fig. 7)

Remove seat as described above. Loosen

the seat tightening hand knob. The seat

height can be adjusted to 5 different settings

by inserting the steel locking pin in the

required hole. Retighten the hand knob and

replace the seat.

Armrest Width Adjustments (Fig. 8)

On the underside of the seat there are two

hand knobs, one either side. Loosening the

hand knob allows the arm rest to be adjusted

to the required width, or removed for

transportation.

DO NOT USE SCOOTER WITHOUT THE

ARM RESTS BEING FITTED & SECURED.

Figure 5

Tiller

Angle

Adjustment

Lever

Figure 6

Seat Slide

Lever

Swivel Seat

Adjustment

Lever

Figure 7

Seat

Adaptor

Seat

Tightening

Hand Knob

Seat

Locking

Figure 8

Armrest

Adjustment

Hand Knob

Download manual in English (PDF, 0.6 MB)
