Manual

Your SentrySafe Product

Your SentrySafe product has a number of features to keep your

important documents and valuables protected including:

Water Protection UL Classiﬁed

Fire Protection

Digital Media

Protection

Loud Audible Alarm

THE LOUD AUDIBLE ALARM ALERTS YOU WHEN:

The safe is picked up

or moved

There is an attempt

to pry the door open

The wrong combination

is entered 5 times

Using Your SentrySafe

Alarm Safe

Preparing Your Safe for First Time Use

Remove lock out screw indicated by the

yellow tag on the inside of the door

of the safe.

Remove battery compartment from

inside door and insert 4 AAA alkaline

batteries. DO NOT use rechargeable

batteries or any other type of non-

alkaline battery. Do not mix old and

new batteries. Do not mix alkaline and

standard batteries.

Replace battery compartment.

Using Your Safe

Touch the keypad to wake up the safe.

Enter the 5 digit factory code found on

the back of this owner’s manual.

Turn handle to open safe.

IMPORTANT: Test your code several times before putting

valuables inside.

IMPORTANT: A dual key lock option may be included

in your safe. Using this key can disable/enable entry into

the safe.

IMPORTANT: If you exert too much force on the handle,

the handle will move without moving the bolts. When this

happens, you will hear a ’click.’ DO NOT be alarmed.

This feature is designed to protect the bolts from being

over powered by force. Simply exert force in the opposite

direction (lifting up) until the handle clicks back

into place.

Close and lock the door of your safe.

Touch the keypad to wake up the safe.

Press: “0” – “PROG” – “9”

The alarm indicator will blink every

10 seconds to indicate the alarm has

been activated.

IMPORTANT: Like a home alarm system, the alarm must

be set each time you lock your safe to activate the

audible alert. In the event your alarm is not activated

and 5 wrong code attempts are entered, the safe will

go into delay mode for 2 minutes. No alarm will go off

when moved, jarred or with attempted forced entry.

Thank you for choosing SentrySafe to store all your important documents and valuables.

We hope that this product will help you stay organized and provide you with the peace-of-mind of knowing the things most important to you are protected.

Water/Fire Resistant Alarm Safe

Setting the Alarm

Turning off the Alarm

If the loud audible alarm on your safe has been triggered:

Touch the keypad to wake up the safe.

Enter a valid code.

NOTE: You will need to enter your code again to open the safe.

NOTE: The Factory Code (FC) or User Code (UC) must be

entered to program safe settings. A secondary code cannot

be used.

Changing Alarm Sensitivity

You can change the level of sensitivity on your safe alarm from a scale

of zero “0” to “5”. Zero “0” being the least sensitive only responding

to incorrect codes and “5” being the most sensitive to slight

movement of the safe.

Touch the keypad to wake up the safe.

Press: “0” – “PROG” – “PROG” – “(FC)” OR “(UC)” – “3”

Then press “0”, “1”, “2”, “3”, “4” OR “5” to program your

desired sensitivity.

Changing Length of Alarm

You may also change the length of which your alarm will sound once

triggered from 01 to 99 minutes.

Touch the keypad to wake up the safe.

Press: “0” – “PROG” – “PROG” – “(FC)” OR “(UC)” – “4”

Then press any number between 01 and 99 to indicate the

number of minutes you would like your alarm to sound

once triggered.

Audible Alarm

Features

The safe is jolted,

hit or jarred

FACTORY CODE (FC): The safe will ALWAYS unlock using this 5

digit code (found on the back of this owner’s manual). This code

cannot be deleted or changed.

USER CODE (UC): A 5 digit programmable code of your choosing

that can be changed or deleted.

SECONDARY CODE (SC): A 5 digit programmable code of your

choosing that can be changed or deleted. Can only be

programmed after a user code has been activated.

Programmable Codes

Your SentrySafe comes with 3 types of codes for accessing

your safe. For more information on programming these codes

see the “Programming Safe Features” section of this

owner’s manual.
