Camcorders, VCRs 15 Watts 12 Hours
Electrical Tools 24 Watts 7 Hours
Electrical Coolers 48 Watts 3 Hours
Car Vacuum,
Air Compressors 80 Watts 1.5 Hours
The DC socket has a 15 amp automatic overload protection circuit
breaker. Reset the breaker by pushing the breaker button located
on the back of IP-1825FL.
110 Volt ac power source chart
(Inverter {Not Included} is Necessary)
Appliance Type Estimated Wattage Estimated Time*
Spot Lights,
Sump Pumps 100 Watts 1.5 Hours
VCRs 100 Watts 1.5 Hours
Faxes, TVs 150 Watts 1 Hour
Small Power Tools 150 Watts 1 Hour
When the IP-1825FL is used with an inverter, it can operate
appliances normally powered by 110V AC. (Inverter not included;
must be purchased separately.)
*NOTE: Estimated time is conservatively reported. Actual time
may vary. Times are based on IP-1825FL having a full charge.
Requires the use of an inverter that is not included. Designed for
up to a 125 watt inverter.
flex-light
To use the ex-light, insert the light’s plug into the 12V accessory
outlet. The ON/OFF control is on the back of the light.
light replacement
The bulb used in the IP-1825FL light is a 12 volt, 5 watt halogen
bayonet type. Since the bulb needing replacement is not working
and the switch may be in the ON position, the lamp circuit could
be “live”. Use caution while changing the bulb.
To replace the bulb, unscrew the cover on the lamp back, remove the
old bulb, then replace with a new 12 volt, 5 watt halogen bulb.
Finally screw the cover onto the lamp housing.
storage
The IP-1825FL can be stored in any position. The clamps are live
and will produce arcing or sparking if they come in contact with
each other. To prevent accidental arcing, always keep the clamps
on the side ears when not using it to jump start a vehicle.
All batteries are affected by temperature. The ideal storage
temperature is at 70 degrees Fahrenheit. Performance varies based
on battery temperature conditions.
limited warranty
Schumacher Electric Corporation warrants your unit to be free from defects in material and workmanship, excepting abuse or misuse, for a period of
one year from the date of sale to the original user or consumer purchaser. If your unit fails or malfunctions within the rst 30 days of the warranty, we
will replace it with a new unit. If your unit malfunctions or fails within the 12 month warranty period because of a defect in material or workmanship, we
will repair without charge.
The internal battery, excluding units with swollen batteries or melted battery terminals, carries a 90-day warranty from the date of purchase. Proof of
purchase required. All battery replacements will be at the sole discretion of the manufacturer or his designated agents.
This warranty is in lieu of all other express warranties. The duration of any implied warranty, including but not limited to any implied warranty of merchantability
or tness for a particular purpose, made in respect to your unit is limited to the period of the express warranty set forth above.
For warranty service, return your product, with proof of purchase, to the factory or a designated agent: Schumacher Electric Corporation Warranty Service
Department, 1025 E. Thompson Street, PO Box 280, Hoopeston, IL 60942. Phone 1-800-621-5485, Customer Service hours: 7 AM to 4:30 PM CST.
You will be responsible for all insurance and freight or other transportation charges to the factory or point of repair. We will return your unit freight
prepaid if repair is covered under warranty. Your unit should be properly packed to avoid damage in transit, since we will not be responsible for any such
damage.
In no event shall Schumacher Electric Corporation be liable for consequential or incidental damages. Some states do not allow limitations on the length
of the implied warranty or the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you.
This warranty gives you specic legal rights and you may also have other rights which vary from state to state.
CONTAINS SEALED NON-SPILLABLE LEAD-ACID BATTERY. MUST
BE DISPOSED OF PROPERLY.
WARNING: Possible explosion hazard. Contact with battery acid may
cause severe burns and blindness. Keep out of reach of children.
Send Warranty Product Repairs to: Schumacher Electric Corporation
1025 East Thompson, Hoopeston, IL 60942-0280
Call Customer Service if you have questions: 1-800-621-5485 (Hours: 7 a.m. – 4:30 p.m. CST)
801 Business Center Drive, Mount Prospect, IL 60056-2179
