Manual

Rover Mowers Limited Model 45 Rover Mowers Limited Model 45

ASSEMBLY

MAINTENANCE

TMTM TMTM

1.1 UNPACKING

1. Lift the top off the carton base and place to one

side.

2. Pivot the upper handlebars into the upright

position, and secure with the clamp screw and

nut. Do not damage the clutch and throttle cables.

Refer to separate sheet for details.

3. Roll the mower off the timber base of the

carton.

4. To adjust the height of the handlebars:-

a.Loosenthelowerhandlebarsecuringbolts(A)

on both sides of the mower. Figure 1.

b. Adjust the height of the handle bars, by pivoting

them up or down, to suit the operator.

c.Re-tightenthenuts(A)Figure1.

1.2 BEFORE OPERATING

1. Place the mower on a level surface in a well

ventilated area.

2. Fill the engine crankcase with 10W-30 or SAE 30

oiltothetopoftheoilllerport.Refertoengine

manufacturers instructions.

3. Fill the fuel tank with UNLEADED petrol.

4. Ensure the spark plug lead is connected to the

spark plug.

1.3 GRASS CATCHER

1. Totthecatcher. Hold the grass catcher by the

top edge, hook the catcher on to the two locating

pegs on the front of the mower, positioning the

catcher on the two rubber stops on either side of

the mower.

2. To remove the catcher. Disengage the cutter

drive and move the throttle control lever to stop

position. When the engine has stopped, hold the

catcher by the top edge and lift it off the locating

pegs.

Figure 1. Rear View

WARNING

StoptheengineBEFOREttingor

removing the grass catcher.

WARNING

Read and understand the safety

i n st ru c ti o ns a n d t h e e n gi ne

manufactuers operating instructions

BEFORE using the mower.

5.1 LUBRICATION

To gain the optimum performance from your

mower, the following areas need to be oiled every

vehoursofoperation.Thesamegradeoilasused

in the engine is suitable.

1. ClutchThrustPad(1)-lookingthroughthe

left hand oil port hole in the clutch cover apply

three drops of oil in the thrust pad oil hole.

Figure 13.

2. Clutchinnercone(2)-lookingthroughthe

right hand oil port hole in the clutch cover

apply three drops of oil in the clutch inner cone

oil hole. Figure 13. Note: in may be necessary

to engage the clutch and slowly pull on the

engine starter cord to align the inner cone oil

hole with the clutch cover hole.

3. Frontroller(3)-applysixdropsofoiltoeach

side of the shaft. Figure 14.

4. Heightadjustmentknob(4)-removethe

plastic cover plug to gain access, and apply six

drops of oil. Figure 14.

5. Drivechains(5)-every10hoursofoperation

remove the chain case side cover and apply

a ‘chain oil’ to the drive chains. Replace side

cover. Figure 14.

Figure 14. Lubrication points

5.2 ENGINE

For detailed cleaning and maintenance instruc-

tions, refer to the engine manufacturers operating

manual.

5.3 GENERAL

1. Keep the mower free of grass and debris

build up.

2. Clean any spilt oil or fuel from around the

engine.

3. Regularly check that all nuts and bolts are

secure.

4. After use and cleaning, lubricate the blade

edges with oil to prevent rust build up on the

cutting edges.

CAUTION

Bearings are sealed for life and do not require

lubrication.

NOTES

Figure 13. Clutch lubrication points. Clutch thrust

pad and clutch inner cone points.

2892 Reel Mower IMPOSED.indd 4 9/11/2005 9:12:49 AM
