1. Parts location

English

■ MODEL EBZ8001/EBZ8001RH/EBZ8001-CA/EBZ8001RH-CA

Dimensions (L x W x H) mm (in)

EBZ8001/EBZ8001-CA ················································································390x540x496 (15.4x21.3x19.5)

EBZ8001RH/EBZ8001RH-CA ······································································390x490x496 (15.4x19.3x19.5)

Dry Weight kg (lbs)····································································································································11.5 (25.4)

Fuel Tank Capacity liter (fl. oz)····················································································································2.3 (77.7)

Engine Type ··········································································································Air cooled 2-cycle gasoline engine

Piston Displacement cm

(cu. in)···············································································································71.9 (4.39)

Air Filter·······················································································································2-stage fresh flow filter system

Carburetor (Diaphragm) valve type··················································································································Rotary

Ignition System······································································································································Digital ignition

Spark Plug························································································································NGK CMR7H (Noise-proof)

Muffler ·································································································································Spark arrester equipped

Operating Engine Speed rpm ················································································································2000 to 6700

Fuel Consumption liter/h (fl. oz/h) ···············································································································1.9 (64.3)

Average Air Volume (w/std Pipe) cu. m/min (cfm)······················································································19.4 (685)

Max. Air Volume (w/o Pipe) cu. m/min (cfm) ······························································································25.9 (915)

Max. Air Velocity m/sec (mph)·······················································································································90 (201)

Durability Period hrs. ············································································································································300

Noise Level (50 Feet ANSI B175. 2-2000) dB(A) ····································································································77

Specifications are subject to change without notice.

[ EBZ8001RH ]

[ EBZ8001RH-CA ]

1. Frame

2. Shoulder Strap

3. Spark Plug Cap

4. Throttle Lever

5. Stop Switch (behind)

6. Net

7. Choke Lever

8. Air Cleaner

9. Volute Case

10. “CAUTION” Label

11. “CAUTION” Label (behind)

12. Elbow

13. Fuel Tank

14. Recoil Starter

15. Ignition Switch

15. Engine Cover

17. Intake Cup

2. Specifications
