Manual Philips QC5530 Hair Clipper

Need a manual for your Philips QC5530 Hair Clipper? Below you can view and download the PDF manual for free in English. This product currently has 2 frequently asked questions, 0 comments and has 0 votes. If this is not the manual you want, please contact us.

Is your product defective and the manual offers no solution? Go to a Repair Café for free repair services.

Manual

ENGLISH

Introduction

Congratulations on your purchase and welcome to

Philips! To fully benet from the support that Philips

offers, register your product at www.philips.com/

welcome.

Your new Philips hair clipper with new ergonomic

design and 180° adjustable cutting element allows

you to clip your own hair easily. You can move

the clipper over all areas of your head as easily as

running your ngers through your hair. To enjoy

using the hair clipper, we advise you to read the

following information.

General description (Fig. 1)

1 Cutting element

2 Swivel head

3 Length setting adjustment ring

4 On/off button

5 Charging light

6 Large comb attachment

7 Length setting indicator

8 Small comb attachment

9 Precision comb attachment

10 Adapter

11 Cleaning brush

12 Oil

Important

Read this user manual carefully before you use the

appliance and save it for future reference.

Danger

- Make sure the adapter does not get wet.

Warning

- The adapter contains a transformer. Do not cut

off the adapter to replace it with another plug,

as this causes a hazardous situation.

- This appliance is not intended for use by

persons (including children) with reduced

physical, sensory or mental capabilities, or lack

of experience and knowledge, unless they

have been given supervision or instruction

concerning use of the appliance by a person

responsible for their safety.

- Children should be supervised to ensure that

they do not play with the appliance.

Caution

- Do not use the appliance in the bath or in the

shower.

- Use, charge and store the appliance at a

temperature between 5°C and 35°C.

- Only use the adapter supplied to charge the

appliance.

- If the adapter is damaged, always have it

replaced with one of the original type in order

to avoid a hazard.

- Do not use the appliance when the cutting

element or one of the comb attachments is

damaged or broken, as this may cause injury.

- This appliance is only intended for clipping

head hair. Do not use it for any other purpose.

- If the appliance is subjected to a major change

in temperature, pressure or humidity, let the

appliance acclimatise for 30 minutes before

you use it.

Compliance with standards

- The appliance complies with the internationally

approved IEC safety regulations and can be

safely cleaned under the tap (Fig. 2).

- This Philips appliance complies with all

standards regarding electromagnetic elds

(EMF). If handled properly and according to the

instructions in this user manual, the appliance

is safe to use based on scientic evidence

available today.

Before first use

1 Lubricate the cutting element with 3 drops of

the included oil (Fig. 3).

Charging

Charge the appliance for at least 1 hour before

you use it for the rst time or after a long period

of disuse.

When the appliance is fully charged, it has a

cordless clipping time of up to 1 hour.

When the charging light ashes orange, the battery

is running low (approx. 7 minutes of operating time

left) and you need to recharge the appliance.

1 Make sure the appliance is switched off.

2 Insert the appliance plug into the appliance

and insert the adapter into the wall

socket (Fig. 4).

, The charging light starts to ash white to

indicate that the appliance is charging (Fig. 5).

, When the battery is fully charged, the

charging light lights up white continuously.

, After approx. 30 minutes the charging light

goes out to save energy.

Corded clipping

1 Switch off the appliance.

2 Connect the appliance to the mains and wait

a few seconds before you switch it on.

Note: If the battery is completely empty, wait a few

minutes before you switch on the appliance.

www.philips.com/welcome

QC5530

4222.002.8255.3

2 3 4

5 6 7

8 9 10

11 12 13

14 15 16

17 18 19

20 21 22

23 24 25
