Manual Philips PQ192 Shaver

Manual

ENGLISH

Introduction

Congratulations on your purchase and

welcome to Philips! To fully benet from

the support that Philips offers, register your

product at www.philips.com/welcome.

General description (Fig. 1)

1 Protection cap

2 Shaving heads

3 Shaving unit

4 Hair chamber

5 On/off slide

6 Front panel

7 Charging light

8 Foldable plug

9 Release button of foldable plug

10 Retaining frame

11 Central spring of retaining frame

12 Cutter

13 Guard

14 Cleaning brush

15 Philips Cleaning spray (HQ110)

(optional)

Important

Read this user manual carefully before you

use the appliance and save it for future

reference.

Danger

- Keep the appliance dry.

- This symbol means: Forbidden to clean

under a running tap (Fig. 2).

Warning

- This appliance is not intended for use

by persons (including children) with

reduced physical, sensory or mental

capabilities, or lack of experience and

knowledge, unless they have been given

supervision or instruction concerning

use of the appliance by a person

responsible for their safety.

- Children should be supervised to

ensure that they do not play with the

appliance.

Caution

- Use and store the appliance at a

temperature between 5°C and 35°C.

- Only use the cleaning brush supplied.

- Make sure the cleaning brush

remains clean.

Electromagnetic elds (EMF)

This Philips appliance complies with all

standards regarding electromagnetic elds.

If handled properly and according to

the instructions in this user manual, the

appliance is safe to use based on scientic

evidence available today.

Charging

Charge the appliance when the motor

stops or starts running slower.

When you charge the shaver for the rst

time or after a long period of disuse, let it

charge continuously for 12 hours. Charging

normally takes approx. 10 hours.

Do not leave the appliance connected to

the mains for more than 24 hours.

1 Switch off the shaver before you start

charging it.

2 Press the release (1) button and

fold out the foldable plug (2)

(‘click’) (Fig. 3).

3 Insert the foldable plug unit into the

wall socket (Fig. 4).

, The charging light goes on to indicate

that the appliance is charging (Fig. 5).

4 Remove the shaver from the wall

socket when the battery is fully

charged.

5 Press the release button (1) and

fold the foldable plug back into the

appliance (2) (‘click’) (Fig. 6).

Note: The charging light does not go out or

change colour when the appliance is fully

charged.

Cordless shaving time

A fully charged shaver has a cordless shaving

time of approximately 30 minutes.

Using the appliance

The shaver cannot be used directly from

the mains.

1 Remove the protection cap.

2 Push the on/off slide upwards to

switch on the shaver (Fig. 7).

3 Move the shaving heads over your

skin. Make both straight and circular

movements (Fig. 8).

Note: Shave on a dry face only. Do not use the

shaver in combination with gel, foam or water.

PQ197, PQ192, PQ187, PQ182

Register your product and get support at

www.philips.com/welcome

4222.002.5443.1

31/10/2012

1

2 3 4

5 6 7

8 9 10

11 12 13

14 15 16

17 18 19

20 21 22

23 24 25

26 27 28

29 30
