Manual

2 108615 Rev. D

Hot label

Etiqueta roja

Étiquette rouge

CONNECT TO WATER SUPPLIES

RACCORDEMENT À LA TUYAUTERIE D’ALIMENTATION

CONECTE LOS SUMINISTROS DE AGUA

Make sure all ttings and end connections are free of debris. Faucet

connections (1) are 3/8" compression ttings. Secure metal nut on faucet

supply hoses (2) to supply valve connection (3) and hand tighten, then tighten

one additional revolution with wrench. DO NOT OVERTIGHTEN. Repeat for

other hose connection making sure the hose with the hot label is connected to

the hot supply valve and the other hose is connected to the cold supply valve.

WARNING: Do not use pipe dope or other sealants on water connections.

Asegúrese de que todos los accesorios y conexiones nales estén libres de

residuos. Los accesorios de grifo (1) son los accesorios de compresión 3/8".

Sujete la tuerca metálica en las mangueras de suministro de grifo (2) a la

conexión de la válvula de suministro (3) y apriétela manualmente, luego apriete

una vuelta adicional con la llave inglesa. NO LA APRIETE DEMASIADO.

Repita con la otra conexión de la manguera asegurándose de que la manguera

con la etiqueta de color rojo está conectado a la válvula de suministro de agua

caliente y la manguera con la se conecta a la válvula de suministro de agua

fría. ADVERTENCIA: No utilice el pegamento para tuberías u otros selladores

sobre las conexiones de agua.

Veillez à ce que les raccords et les terminaisons soient exempts de débris.

Les raccords de robinet (1) sont des raccords de compression de 3/8’’. Serrez

l’écrou en métal sur le tuyau d’alimentation du robinet (2) à la connexion

de la valve d’alimentation (3) et serrez à la main, ensuite serrez un tour

additionnel avec une clé. NE PAS TROP SERRER. Répéter pour l'autre

raccord de tuyau en s'assurant que le tuyau avec l'étiquette rouge est reliée

à la soupape d'alimentation en eau chaude et le tuyau avec est reliée à la

vanne d'alimentation en eau froide. AVERTISSEMENT : Ne pas utiliser de pâte

lubriante ou matériaux d’étanchéité sur les raccordements d’eau.

For Three Hole Mount

Para Las Instalaciones De Tres Agujeros

Montage Sur Trois Trous

For Single Hole Mount

Para Las Instalaciones De Un Agujero

Montage sur un trou

SHUT OFF WATER SUPPLIES. Position faucet (1) with ange if

included and gasket (2) or faucet (1) with three hole escutcheon (3)

and baseplate (4) on sink. Option: If surface of sink is uneven, use

silicone under the baseplate or gasket. Place metal bracket (5) over

mounting stud (6) under sink. Secure with mounting nut & wrench (7),

use Phillips screwdriver to rotate the wrench if the faucet is not tight

enough.

INTERROMPEZ L’ARRIVÉE D’EAU. Coloque el grifo (1) con la brida

si se incluye y la junta (2) o el grifo (1) con el escudo de tres agujeros

(3) y la placa base (4) en el fregadero. Opción: Si la supercie está

desnivelada, use silicón por debajo de la chapa base. Coloque el

soporte de metal (5) sobre la tuerca de instalación (6) por debajo del

lavamanos. Fije con la tuerca de instalación y llave de tuercas (7),

utilice el destornillador Phillips para girar la llave si el grifo no está

sucientemente apretado.

CIERRE LOS SUMINISTROS DE AGUA. Veuillez positionner le

robinet (1) avec bride (le cas échéant) et positionner le joint (2) ou le

robinet (1) avec une rosace à trois trous (3) et une plaque de base (4)

sur l'évier. Facultatif: si la surface de l’évier est inégale, appliquez

du composé d’étanchéité à la silicone sous la plaque de base.

Placez le support en métal (5) sur le goujon de montage (6) sous

l’appareil sanitaire. Fixez le robinet à l’aide de l’écrou de montage et

la clé (7), faites pivoter la clé avec un tournevis Phillips si le robinet

n'est pas assez serré.
