PBLG 52 A1 GB

│

3 ■

Technical speciﬁcations

Engine

Displacement 52 cm

Max. motor output as per ISO 8893 1.6 kW

Nominal power 1.45 kW

Nominal speed 7500 rpm

Idle speed 3000 rpm

Spark plug L7RTC

Airﬂow velocity 290 km/h (with ﬂat nozzle)

Volumetric ﬂow 750 m

/hr (with ﬂat nozzle)

Volumes

Fuel tank approx. 1300 cm

(1.3 l)

Noise and vibration data

Information on the sound power level emitted by the machine, determined

according to the European Directives 2000/14/EC and 2005/88/EC.

Noise measurement value determined in accordance with EN

15503:2009 + A2:2015.

The A-rated noise level is typically as follows:

Sound pressure level L

in dB (A)

97.1 dB

Uncertainty K = 3 dB

Sound power level L

WA,m

in dB (A)

Measured: 109.1 dB

Guaranteed: 111 dB

Uncertainty K = 2.02 dB

Vibration value A

hv, eq

in m/s

ISO 22867

4.016 m/s

Uncertainty K = 1.5m/s

Wear ear muﬀs to prevent hearing damage!

NOTE

► The vibration level speciﬁed in these instructions has been measured in

accordance with the standardised measuring procedure speciﬁed in

EN 15503 and can be used to make equipment comparisons. The

speciﬁed vibration emission value can also be used to make an initial

exposure estimate.

WARNING!

► The vibration level varies in accordance with use and may be higher

than the value speciﬁed in these instructions in some cases. There is a

risk of underestimation of the vibration load if the appliance is used

regularly in this manner. To estimate the vibration load during a speciﬁc

working period accurately, periods during which the appliance is

switched oﬀ (or running, but not being used) must also be taken into

account. This can signiﬁcantly reduce the vibration load over the total

working period.

WARNING!

► You can reduce the vibration risk, for example, the risk of Raynaud's

phenomenon (circulatory problems), by taking regular breaks during

which you rub your hands together.

The following symbols are used in these original operating

instructions/on the appliance

Read these operating instructions thoroughly before using the

tool for the ﬁrst time, and retain them for future reference.

Warning! Read the operating instructions before use!

WARNING! Special safety precautions are required when

working with the appliance. Read and observe all warnings.

Wear ear muﬀs.

Wear safety goggles.

Wear protective gloves.

Pull the pull start with the choke in this position. When you

pull out the choke, the air ﬂap closes. When you push in the

choke, the air ﬂap opens.

Press the fuel pump (primer) 6x

Fuel tank; mixing ratio: 40 parts petrol to 1 part oil

Petrol: ROZ 95/ROZ 98

2-stroke motor oil: ISO-L-EGD/JASO FD

Open ﬂames and smoking in the vicinity of the appliance

are strictly prohibited!

Guaranteed sound power level of the appliance

The operator of the leaf blower must ensure that people and

animals keep a distance of at least 15 m. If several operators

are working in close proximity to each other, the safety

distance must be at least 15 m.

Caution! Poisonous CO vapours (carbon monoxide vapours)!

Do not use the appliance in closed rooms!

WARNING!

Hair can be sucked into the appliance!

Caution – petrol is highly ﬂammable!

Explosion hazard! Do not spill any fuel!

Turn the appliance oﬀ and remove the spark plug connector

before performing any maintenance work!

Attention! Risk of suﬀocation!

Attention, hot parts. Maintain a safe distance!

Watch out for ﬂung away parts!

Keep others away! Maintain a safe distance!

Do not ﬁll up on E10!

Pour the gasoline mixture in here!
