Manual

PBLG 52 A1■ 8

│

Starting when the engine is hot

(The appliance has been turned oﬀ for less than 15–20 minutes)

♦ Set the On/Oﬀ switch0 to “I”.

♦ The choket does not need to be pulled out to start a warm motor.

♦ Press the appliance against the ﬂoor with your left hand on the

frame1 (ATTENTION! Do not use your foot!). With your right hand

on the pull start z, pull it slowly until you feel resistance.

ATTENTION!

► Always pull the pull startz straight out. Hold the handle of the pull

startz ﬁrmly when the pull startz retracts. Do not allow the pull

startz to whip back.

♦ Now pull quickly on the pull startz. The appliance should start after

1–2 pulls. If the appliance has still not started after 6 pulls, repeat the

process as described in “Starting when the engine is cold”.

Parking throttle/throttle lever lock

♦ Press the throttle9 halfway down and then push down the throttle

lock .

♦ Now release the throttle9 and the throttle lock

The throttle9 is now locked.

NOTE

► When the throttle lever lock

is actuated, the unit does not run in full

throttle position!

Turning the engine oﬀ

Emergency stop sequence

If the appliance needs to be stopped immediately, turn the On/oﬀ

switch0 to “0”.

Normal sequence

♦ Release the throttle9. The engine idles. Then move the On/Oﬀ

switch0 to “0”.

Basic working techniques

■ Make sure that you are familiar with the appliance before starting work.

WARNING!

► WARNING! Risk of ﬂying objects. Always wear goggles. Flying

stones, debris, etc. could hit your eyes and cause serious injury or

blindness. Maintain a safe distance. Children, animals, spectators and

helpers should remain outside a safety zone of 15m. Switch oﬀ the

appliance immediately if anyone approaches.

► Do not use the appliance if the exhaust opening on the engine cover is

obstructed by a wall and/or other objects. Otherwise, the appliance

could be damaged. Ensure that a distance of at least 50 cm to other

objects is always maintained during operation.

■ The leaf blower is portable and is carried during operation on the

shoulders by means of a belt. It is controlled with the right hand using

the handle on the pipe.

■ The speed of the air jet is controlled with the throttle. Adjust the speed to

the respective application.

■ Make sure that the air inlet is not blocked, for example, by leaves or

dirt. A blocked air inlet reduces the blowing power and increases the

working temperature of the engine, which can lead to engine failure.

If necessary, switch oﬀ the engine and remove any foreign bodies.

■ Pay attention to the wind direction. It is easier to work with the wind

(at your back).

■ The leaf blower should not be used to move large piles of leaves, as

this is very time-consuming and causes unnecessary noise.

■ Assume a safe working position with a ﬁrm stand.

■ After ﬁnishing work, the machine must be stored upright.
