5
GB
The device is intended to be used by do-it-
yourselfers. It was not designed for heavy
commercial use.
The tool is to be used by adults. Children
under the age of 16 may not use the tool
except under supervision.
The manufacturer is not liable for damages
caused by an improper use or incorrect
operation of this device.
General description
See the front fold-out page for
illustrations.
Extent of the delivery
Carefully unpack the appliance and check
that it is complete:
- Device
- Handgrip
- Protective hood
- Chuck key
- Cutting disc
- Carbon brushes
- Translation of the original instructions
for use
Description of function
The angle grinder is made for cutting,
scrubbing or brushing metal. There is a
special disc for each of the separate ap-
plications. Please refer to the information
from the disc manufacturer.
Please refer to the descriptions below for
information about the operating devices.
Overview
1 Handgrip
2 Threads for handgrip
3 Speed regulator
4 Switch block
5 On/off switch
6 Maintenance coverage
7 Screw
8 Threads for handgrip
9 Spindle stop button
10 Power plug
11 Cutting disc
12 Carbon brushes
13 Chuck key
14 Protective hood
 
16 Clamping nut
17 Mounting spindle
18 Adjustment nut
19 Tightening lever
20 Compression spring
21 Carbon brush
22 Groove for compression spring
23 Connection
24 Contact shoe
25 Contact plug
Technical data
Angle Grinder PWS 125 B2:
Rated input voltage
............................... 230-240 V~, 50 Hz
Power input ............................ 1200 W
Idling speed (n) ............3000-12000 min
-1
Dimensions of the cutting/roughing discs
............................... Ø 125 x 22,23 mm
Thickness of the cutting/roughing discs
............................................max. 6 mm
Grinding spindle thread ...................M14
Thread length of the grinding spindle
..........................................max. 12 mm
Safety class .....................................
II
Protection category......................... IP 20
Sound pressure level
(L
pA
) ................... 92,1 dB(A); K
pA
= 3 dB
