TQBM0483

You can direct the audio signal from the

connected Blu-ray Disc player, DVD player, Set

Top Box, etc. to this system.

Preparation

≥ Connect the main unit to the TV. (> 8)

A HDMI cable

Depending on how the main unit is setup, it may

block the TV’s remote control signal sensor,

stopping the TV’s remote control from working.

Use the supplied Ir system cable if this occurs.

The TV remote control signals received by the

main unit are sent to the TV to operate it.

≥ For the operation range, refer to page 7.

≥ Do not use any other IR Blaster except the

supplied one.

1 Connect the jack plug to the main

unit’s Ir SYSTEM terminal.

A IR Blaster (supplied)

B Adhesive tape (supplied)

2 Place the infrared emitter in sight of

the TV’s remote control signal sensor.

Placement example

On the rear of the main unit:

C TV remote control signal sensor

D Infrared emitter

E Adhesive tape (supplied)

Connection from an HDMI

compatible device



≥ Refer to the operating instructions of the connected HDMI

compatible device for the necessary setting, to output the

video and audio signals.

HDMI OUT HDMI OUT



e.g.,

Blu-ray Disc player

e.g.,

Set top box

Using the IR Blaster

(When the remote control does not work

properly)











SC-HTB700-EGEBGNGW-TQBM0483_eng.book 10 ページ２０１９年６月６日　木曜日　午前１０時２１分
